Ethernet 10/100BASE-SX, 100BASE-FX ™ PCI Network Interface Cards N-FX-ST-01, N-FX-SC-01, N-FX-MT-01, N-SX-ST-01, N-SX-SC-01, N-SX-MT-01, ND-FX-ST-01, ND-FX-SC-01, ND-FX-MT-01, ND-SX-ST-01, ND-SX-SC-01, ND-SX-MT-01 USER’S GUIDE Adapter Hardware Installation ...2 PCI Network Interface Cards...3 Adapter Software Installation Note ...4 Microsoft Windows 95 - New Installation ...4 Microsoft Windows 95 - Software Upgrade ...6...
Page 2: Adapter Hardware Installation
Under “SYSTEM BOOT” (or equivalent) menu, enable ON LAN and ON PME. Save BIOS changes and exit. Technical Support In the event of difficulty in installing the PCI Network Interface Cards, c Technical Support at: (800) 260-1312 TRANSITION Networks ontact...
Page 3: Pci Network Interface Cards
PCI NETWORK INTERFACE CARDS TRANSITION Networks Fiber-Optic PCI Network Interface Cards (Adapters) are 32-bit bus-mastering PCI cards that support both half-duplex and full-duplex operation and that comply with PCI Specifications, revision 2.1 and 2.2, and with both IEEE 802.3 10BASE-FL,...
Page 4: Adapter Software Installation Note
If your computer is Plug and Play compatible, Windows 95 will recognize that new hardware has been installed.. Follow the steps below. Other wise, Skip to step 27 At the – Update Device Driver Wizard Screen - Insert the Transition Networks Driver Disk Click <Next>...
Page 5 When the system comes up open Netowok Neighborhood by right clicking Click on " Properties" Highlight "Transition \ LANart …." And , Click on "Properties" Click on Advanced Chose the properties as required by Network Administrator To access your network, protocols will need to be configured. Please see your network administrator for details.
Page 6: Microsoft Windows 95 - Software Upgrade
Power up the computer, and start Windows 95. The following instruction is to update the driver for LANart network card. Update the driver for Transition Networks / LANart (EFA020X) - open the control panel by clicking "Start," then "Settings," then "Control Panel."...
Page 7: Microsoft Windows 98 - New Installation
MICROSOFT WINDOWS 98 - NEW INSTALLATION Copy the appropriate device install script For NDIS3 MAC driver type copy A:\Win98\Nids3\Mac\Netamd.inf For NDIS4 MINIPORT driver type copy A:\Win98\Nids4\Mini\Netamd.inf Shutdown Windows 98 and power-off the machine. Install the Adapter card in accordance with your personal computer user's manual. Again, follow all handling procedures to avoid electro-static discharges.
Page 8 Double Click "system" Click "Device Manager" Double Click "Network Adapter" Highlight " …." And , Click on "Properties" Click on Advance Chose the properties as required by the Network Administrator Restart the computer. Your adapter is now configured. To access your network, protocols may need to be configured.
Page 9: Microsoft Windows 98 - Software Upgrade
MICROSOFT WINDOWS 98 - SOFTWARE UPGRADE Power up the computer and start Windows 98. Update the driver for the PCI card - open the control panel by clicking "Start," then "Settings," then "Control Panel." Double Click "system" Click "Device Manager" Double Click "Network Adapter"...
Page 10: Microsoft Windows Nt 4.0 - New Installation
MICROSOFT WINDOWS NT 4.0 - NEW INSTALLATION Install the Transiton (EFA020X series) Adapter card in accordance with your personal computer user's manual. Again, follow all handling procedures to avoid electro-static discharges. Start Windows NT, and open the control panel by clicking "Start," then "Settings," then "Control Panel."...
Page 11: Microsoft Windows Nt 4.0 - Software Upgrade
MICROSOFT WINDOWS NT 4.0 - SOFTWARE UPGRADE Start Windows NT, and open the control panel by clicking "Start," then "Settings," then "Control Panel." Double Click on "Network." Click on the Adapters tab. Highlight the existing Transition LANart adapter, and click "Remove." Close the control panel to effect the change.
Page 12: Novell Netware 4.X / 5.X - New Installation
NOVELL NETWARE 4.X / 5.X - NEW INSTALLATION Power off the machine. Install the Transiton / LANart (EFA020X ) Adapter card in accordance with your personal computer user's manual. Again, follow all handling procedures to avoid electro-static discharges. Install the server software When the NIC selection menu appears, place the appropriate disk in the drive Press Insert (Ins) Press [F3] to change the path.
Page 13: Novell Netware 4.X / 5.X - Software Upgrade/Adding Network
NOVELL NETWARE 4.X/ 5.X - SOFTWARE UPGRADE/ADDING NETWORK CARD TO AN EXISTING SYSTEM. Shutdown Netware Server and power-off the machine. Install the Transiton / LANart (EFA020X series) Adapter card in accordance with your personal computer user's manual. Again, follow all handling procedures to avoid electro- static discharges.
Page 14: Microsoft Windows Nt 4.0 - Permanet Server
Click "Add" inside the Network control panel, then select "Adapter", and click "Add" inside the Select Network Component Type window. Select "Have Disk." Insert the Transition Networks Driver Disk into the drive For the Permanet Server driver, type at the prompt: "A:\Winnt_PS4"...
Page 15: Installing Sunsoft Solaris Driver (X86 Environment)
Wait for the process to complete Restart the computer. Your Transition Networks / LANart adapter is now configured. To access your network, protocols will need to be configured. Please see your network administrator for details DMI INSTALLATION PROCEDURE (DMI VERSION 2.0)
Page 16: Compliance Information
© 2000 TRANSITION Networks. All rights reserved. No part of this work may be reproduced or used in any form or by any means – graphic, electronic, or mechanical – without written permission from TRANSITION Networks. Printed in the U.S.A.
