IntuiKey Keyboard
B Camera Control Command Reference
The IntuiKey Keyboard provides access to the camera control functions for applicable system
devices. Certain features may be restricted by the AutoDome security feature. Refer to
Appendix D for additional details. The Camera Control Main menu is shown below. The
command descriptions follow.
Figure B.1 Camera Control Main Menu
–
–
–
Entering a two digit shot number followed by ENTER, programs the present camera position
as the entered shot number. Four digit numbers are reserved for camera configuration
commands.
NOTICE! This function is also accomplished by pressing and holding the SHOT button
i
(located next to the joystick) for more than two seconds.
–
Bosch Security System, Inc.
Camera
Exit
Functions
Advanced
Menu
Set Show
Shot Shot
Modify Pre-set
Pre-set Scene
Tour Control
Add Scene Remove
to Tour Scene from
Tour
Aux On Aux Off
Exit
Exits the camera menu and returns to the previous control/programming menu.
Not Used
Set Shot
Camera pre-position scenes are programmed by pressing the Set Shot softkey. The
status display changes to the following for input:
----
Set Shot
Allegiant
Figure B.2 Allegiant Set Shot Status Display
Modify Preset Tour
This command is specific to G3 AutoDome® cameras. Pressing this softkey displays a
camera on-screen display.
User Manual
| en 37
F.01U.080.637 | 1.92 | 2008.12
