Bosch IntuiKey Keyboard User Manual page 15

IntuiKey Keyboard
Bosch Security System, Inc.
Load Sequence Enables the loading of a previously programmed sequence.
–
Sequence programming is displayed on the controlled monitor
screen.
–
–
–
Hold Sequence Stops a running sequence.
Previous Sequence Sets the sequence direction to run in reverse. If the sequence is
Step already running in reverse, pressing this button executes the
previous sequence step immediately. Holding the key causes the
sequence to run in fast reverse mode, at approximately two steps
per second.
User Log-off Used to LOG OFF the Allegiant Switcher.
–
–
–
User Manual
Controlling Allegiant Series Video Switchers | en
Press the Load Sequence softkey. The status display shows
the following:
- - -
Sequence?
Allegiant
Figure 2.7 Load Sequence Display
Enter the sequence number, then press ENTER.
To unload a sequence, stop the sequence (if necessary),
press the Load Sequence softkey, then press ENTER.
Use CLR to clear an incorrectly entered number.
Press the User Log OFF softkey.
The softkey display shows the following:
Allegiant
User Log OFF
Press:
[Enter] to log off
[Clr] to Exit
Figure 2.8 User Log-off Menu
Press CLR to clear the pending log-off. Press ENTER to
complete the log-off process. The softkey display reverts to
displaying only USER LOG ON, and the status display
changes back to the default mode (i.e. camera and monitor
numbers replaced with dashes). This mode times out in
approximately two seconds and reverts to the previous
menu.
11
F.01U.080.637 | 1.92 | 2008.12
