IntuiKey Keyboard
NOTICE! Keyboard access to MONB must be enabled within the Divar menus. See the Divar
i
manual for details.
–
–
–
–
–
–
NOTICE! While in DVR Control Code, the product title continuously displays the programmed
device name. The numeric entry field is used to enter numeric values needed to control the
i
DVR (i.e. camera number, DVR number, shot number, etc.). Above the numeric entry field is a
title displaying the DVR's current mode (i.e. cameo, camera entry, menu mode, or numeric
entry).
4.
3.2

Programming/Controlling DVR Functions

3.2.1

The DVR Main Control Menu

The DVR Main Control menu uses softkey buttons to execute commands or to gain access to
other submenus for additional programming/configuration.
Detailed command descriptions follow. Refer to the Divar Instruction Book for additional
information.
–
–
Bosch Security System, Inc.
Indicates that the DVR is in an ACTION alarm mode.
Indicates that the DVR is in a contact activated alarm mode.
REC – Indicates that the DVR is currently recording.
PLAY – Indicates that the DVR is in a replay mode.
ZOOM – Indicates that the DVR is displaying a zoomed image.
ALM xx – Indicates that a device connected to the IntuiKey with address number xx is
currently in alarm. The IntuiKey's alarm button will light and the keyboard will begin to
beep.
The softkey display shows the DVR Main Control menu.
Exit Search
Full
Play
Screen
Quad
Live
Screen
Multi
Freeze
Screen
Select
Instant
Cameo
Play
Segment
Camera
Sequence
Control
DVR
Zoom
Control
Figure 3.2 Divar DVR Main Control Menu
Exit
Exits one menu and returns to the main menu for the particular function being
programmed.
Full
Select Full Screen Camera Mode by pressing the Full Screen softkey. The camera
currently selected by the keyboard will be displayed in full screen on the monitor.
NOTE: For the Divar MR, PTZ control is only available when in full screen mode.
Controlling Divar Series Digital Video Recorders | en
User Manual
21
F.01U.080.637 | 1.92 | 2008.12
