Viking VCSB5421 Installation Manual

Side-by-side & bottom-mount refrigerator/freezer.
Hide thumbs

Advertisement

Viking Installation Guide
Viking Range, LLC
111 Front Street
Greenwood, Mississippi 38930 USA
(662) 455-1200
For product information,
call 1-888-(845-4641)
or visit the Viking Web site at
vikingrange.com
Side-By-Side &
Bottom-Mount Refrigerator/Freezer
U L
U L
C
F20842A EN
(041513)

Advertisement

Table of Contents

   Also See for Viking VCSB5421

   Related Manuals for Viking VCSB5421

   Summary of Contents for Viking VCSB5421

  • Page 1 Viking Installation Guide Viking Range, LLC 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-(845-4641) or visit the Viking Web site at vikingrange.com Side-By-Side & Bottom-Mount Refrigerator/Freezer F20842A EN (041513)
  • Page 2: Table Of Contents

    Table of Contents IMPORTANT– Please Read and Follow! Warnings & Important Information _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 3 Professional Side-by-Side •...
  • Page 3 • make sure that you have these materials (not provided with your unit), which are necessary • Viking Range Corporation will NOT warranty any problems resulting from GFI outlets which for proper installation: are not installed properly or do not meet the requirements below.
  • Page 4: Dimensions & Specifications (professional 42" & 48")

    Dimensions Specifications (Side-By-Side) (Side-By-Side) 42” Side-By-Side 42” Side-By Side Description VCSB5421 VCSB5421D Overall width 42” (106.7 cm) Overall height from bottom 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max. Overall depth from rear To front edge of side trim: 22-3/16”...
  • Page 5 (Side-By-Side with flush mount trim) (Side-By-Side with flush mount trim) 42” Side-By-Side with Flush Mount Trim 42” Side-By-Side with Description VCSB5421/Flush Mount VCSB5421D/Flush Mount Flush Mount Trim Overall width 42” (106.7 cm) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
  • Page 6: Cutout Dimensions (42")

    Cutout Dimensions Anti-Tip Dimensions (Side-By-Side) (Side-By-Side) 42” Side-By-Side 42” Side-By-Side Anti-Tip Location Electric Outlet Location 6 ” Two 2”x 4” Mounting Boards (1 5 .2 c m ) 3” (7.6 cm) x 3-1/2” (8.9 cm) 9 ” (2 2 .9 c m ) 3 ”...
  • Page 7: Cutout Dimensions (48")

    Cutout Dimensions Anti-Tip Dimensions (Side-By-Side) (Side-By-Side) 48” Side-By-Side 48” Side-By-Side Anti-Tip Location Electric Outlet Location 6 ” (1 5 .2 c m ) Two 2”x 4” Mounting Boards 3” (7.6 cm) x 3-1/2” (8.9 cm) 9 ” (2 2 .9 c m ) 3 ”...
  • Page 8 Dimensions Specifications (Bottom-Mount) (Bottom-Mount) 36” Bottom-Mount 36” Bottom-Mount Description VCBB5361 Overall width 36” (91.5 cm) Overall height from bottom 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max. To front edge of side trim: 22-3/16” (56.4 cm) Overall depth from rear 3 –...
  • Page 9: Cutout Dimensions (36")

    Cutout Dimensions Anti-Tip Dimensions (Bottom-Mount) (Bottom-Mount) 36” Bottom-Mount 36” Bottom-Mount Anti-Tip Location Electric Outlet Location 6 ” (1 5 .2 Two 2”x 4” Mounting Boards c m ) 3” (7.6 cm) x 3-1/2” (8.9 cm) 9 ” (2 2 .9 c m ) 9 ”...
  • Page 10: Cabinet Information (professional)

    Cabinet Information Cabinet Information (Professional) (Professional) Professional models fit “semi-flush” in standard 24” (61.0 cm) deep cabinet openings. The door Professional models fit “semi-flush” in standard 24” (61.0 cm) deep cabinet openings. The door face protrudes 1-3/4” (4.4 cm) from the cabinet face. The handles protrude an additional face protrudes 1-3/4”...
  • Page 11 Cabinet Information Cabinet Information (Professional with Flush Mount Trim) (Professional with Flush Mount Trim) Professional models with flush mount trim fit flush in standard 24” (61.0 cm) deep cabinet openings with Professional models with flush mount trim fit flush in standard 24” (61.0 cm) deep cabinet openings with no protrusion into the room except the handle protrudes 2-1/2”...
  • Page 12: Custom Side Panel Dimensions (professional)

    Custom Side Panel Dimensions Custom Side Panel Dimensions (Professional) (Professional with Flush Mount Trim ) 3/16” 3/4” (0.5 cm) (1.9 cm) Back filler Z-Bracket 1” panel End panel 3/4” (2.5 cm) 1/4” (0.6 cm) (1.9 cm) End panel 4 ” - 3 / 6 ”...
  • Page 13: General Information

    (1.9 L) of water through the copper Anti-Tip Requirements tubing and into a bucket to remove any • The installation of Viking units with a • Cutout dimensions are accurate. The anti-tip boards should be fastened particles in the water line.
  • Page 14: Flush Mount Side Trim Installation

    General Information Flush Mount Side Trim Installation Note: If the unit is to be installed flush with the cabinets, the flush mount side trim must be installed first. If not, skip to “installation”. • Most of the unit’s weight is at the top. TIP OVER HAZARD Extra care is needed when moving the Appliance is top heavy and tips easily...
  • Page 15: Hinge Adjustment

    Hinge Adjustment Front of unit Remove four side screws and remove unit top. Carefully move unit until semi flush with cabinet Loosen the four hinge screws. Adjust door. Place unit within 3” of being flush with cabinets. Retighten four hinge screws. (depending on unit).
  • Page 16: Kickplate Installation

    Door Stop Adjustment (Side-by-Side) 90˚ Screw 110˚ Wall 120˚ 2 x 4 Refrigerator Attach positive secure self-tapping bolts to 2x4 Lift unit off rollers to desired height and level unit Open refrigerator door so door stop and shoulder Remove shoulder screw and place in 90° or using a 22”...
  • Page 17: Water Filter Installation

    Water Filter Installation (Side-by-Side with Dispenser) Water Filter System Specification and Performance Data This system has been tested according to NSF/ANSI 42/53 for reduction of the substances listed below. The concentration of the indicated substances in water entering the system was reduced to a concentration of less than or equal to the permissible limit for water leaving the system, as specified in NSF/ANSI 42/53.* (100% safety factors built-in for unmetered usage for health claims only.) NSF Specified...
  • Page 18: Final Installation

    Final Installation Performance Checklist Replace top air grille. Using an 8” magnetic nut driver, replace the two 1/4” screws. Replace the center grille louver. Open door. Display should flash. □ Align/square door(s). □ Verify cabinet size. □ Verify electrical supply and water supply □...
  • Page 19: Control Panels

    COOL FAST COOL POWER SAB SHOW HIGH TEMP authorized service agency, or if you continue to have service problems, contact Viking Range Corporation at 1-888-(845-4641), or write to: 1. Press “Activate Controls” pad. VIKING RANGE, LLC PREFERRED SERVICE 2. Verify unit is not in Sabbath Mode.
