- Page 2 Dear Customer, If you follow the recommendations contained in this Instruction Manual, your appliance will give you constant high performan- ce and will remain efficient for many years to come. CONTENTS RECOMMENDATIONS AND SUGGESTIONS CHARACTERISTICS INSTALLATION MAINTENANCE...
-
Page 3: Recommendations And Suggestions
RECOMMENDATIONS AND SUGGESTIONS INSTALLATION • The manufacturer will not be held liable for any damages resulting from incorrect or improper installation. • The minimum safety distance between the cooker top and the extractor hood is 650 mm. • Check that the mains voltage corresponds to that indicated on the rating plate fixed to the inside of the hood. - Page 4 CHARACTERISTICS Dimensions...
- Page 5 Components Ref. Q.ty Product Components Hood Body, complete with: Controls, Light, Blower, Filters Telescopic Chimney comprising: Upper Section Lower Section Telescopic frame complete with extractor, consisting of: 7.1a Upper frame 7.1b Lower frame Air Outlet Grill Reducer Flange ø 150-120 mm Hood Body Air Outlet Extension Piece consisting of two Half Shells 14.1...
-
Page 6: Installation
INSTALLATION Drilling the Ceiling/shelf and fixing the frame DRILLING THE CEILING/SHELF • Use a plumb line to mark the centre of the hob on the ceiling/support shelf. • Place the drilling template 21 provided on the ceiling/support shelf, making sure that the template is in the correct position by lining up the axes of the template with those of the hob. -
Page 7: Fixing The Frame
FIXING THE FRAME • Unfasten the two screws fastening the upper chimney stack 2.1 to the frame, and remove the chimney from the upper stack. If you wish to adjust the height of the frame, proceed as follows: • Unfasten the four safety screws located at the top in the frame separation area. -
Page 8: Recirculation Version Air Outlet
RECIRCULATION VERSION AIR OUTLET • Insert reducer flange 9 on the extractor outlet. • Push fit the extension piece 14 onto the flange. • Push fit connector 15 onto the extension piece. • Insert extension piece/connector 14.1 laterally on connector 15, ensuring that the outlet is in line with the chimney intake. -
Page 9: Electrical Connection
ELECTRICAL CONNECTION • Connect the hood to the mains through a two- pole switch having a contact gap of at least 3 • Remove the grease filters (see paragraph Maintenance) being sure that the connector of the feeding cable is correctly inserted in the socket placed on the side of the fan. -
Page 10: Remote Control (Optional)
Fixed Indicates that the Metal grease filters saturation alarm has been triggered, and the filters need to be washed. The alarm is triggered after 100 working hours. (Reset; check the Maintenance-paragraph) Flashing indicates that the activated charcoal odour filter saturation alarm has been triggered, and the filter has to be replaced;... -
Page 11: Activated Charcoal Filter (Recirculation Version)
Activated charcoal filter (Recirculation version) REPLACING THE ACTIVATED CHARCOAL FILTER • The filter is not washable and cannot be regenerated. It must be replaced when led S1 flashes or at least every 4 months. The alarm signal will only light up when the extractor motor is switched on.
