- Page 1 All manuals and user guides at all-guides.com BEDIENUNGSANWEISUNG mit Montageanweisungen Instructions for use and installation instructions Instructions d’ utilisation et avis de montage Gebruiksaanwijzing en montagehandleiding Istruzioni di uso e di montaggio Instrucciones de uso y de montaje IKDEM 976.1GE IKD 976.1GE...
-
Page 2: General Information
All manuals and user guides at all-guides.com Part 1 - INSTALLATION INSTRUCTIONS 1 - GENERAL INFORMATION This hood is designed for installation over a cooking appliance fitted into a peninsular or island kitchen cabinet. The hood can be fixed to the ceiling or to a wooden buttress (fig. -
Page 3: Safety Warnings
All manuals and user guides at all-guides.com Part 1 - INSTALLATION INSTRUCTIONS 2 - COMPONENTS The cooker hood is made up of the following components (fig. 1): 2.1 - no. 1 canopy item “C”, including controls, worktop illumination and fan unit 2.2 - no. - Page 4 All manuals and user guides at all-guides.com Part 1 - INSTALLATION INSTRUCTIONS 4 - INSTALLATION To install the hood proceed by fitting the components in the following order: 4.1 - Fitting of upper telescopic frame “TS” 4.2 - Fitting of lower telescopic frame “TI” 4.3 - Setting the hood for recirculation or evacuation 4.4 - Connection to the mains supply 4.5 - Fitting the chimney...
- Page 5 All manuals and user guides at all-guides.com Part 1 - INSTALLATION INSTRUCTIONS g) For extraction mode with ceiling vent only Use the template provided to mark the ø 125 mm hole on the ceiling for ducting when the range hood is to be installed in the extraction mode.
-
Page 6: Electrical Connection
All manuals and user guides at all-guides.com Part 1 - INSTALLATION INSTRUCTIONS 4.3 - Setting the hood for evacuation or recirculation 1 - Setting for evacuation: a) Apply the reducing spigot “7B” to the upper part of the extraction unit “7D”. b) Connect spigot “7B”... -
Page 7: Fitting The Canopy
All manuals and user guides at all-guides.com Part 1 - INSTALLATION INSTRUCTIONS 4.6 - Fitting the canopy a) Remove the three grease filters “8D” by applying pressure to the handles “8E”. b) If fitted, remove the charcoal filter “8C”. c) Position the canopy item “8A” in line with the holes of lower frame “TI”... -
Page 8: Part 2 - Use And Maintenance Instructions
All manuals and user guides at all-guides.com Part 2 - USE AND MAINTENANCE INSTRUCTIONS 1 - SAFETY WARNINGS It is most important that all the warnings shown in paragraph 3 of the Installation Instructions are strictly observed. Moreover, pay special attention to the following warnings during the use and maintenance of the cooker hood: 1.1 - The grease filters and the charcoal filter should be cleaned or replaced as recommended by the manufacturer or more frequently if the hood is used consistently over 4 hours... -
Page 9: Metal Grease Filters
All manuals and user guides at all-guides.com Part 2 - USE AND MAINTENANCE INSTRUCTIONS 3.1 - Metal grease filters 1 - Cleaning These filters must be washed when LED 0/1 Motor starts to flash, or at the most once every 2 months, using a normal household detergent; their compact size also enables them to be washed in a dishwasher. - Page 10 All manuals and user guides at all-guides.com Part 2 - USE AND MAINTENANCE INSTRUCTIONS 2 - Replacement Remove the antigrease filters “8D” and the activated carbon filter “11A” from its seat by acting on the hooks. Fit the new activated carbon filter and the metal antigrease filters.
