Summary of Contents for Küppersbusch IKD9885.0
- Page 1 BEDIENUNGS- UND MONTAGEANWEISUNG GB INSTRUCTIONS FOR ASSEMBLY AND USE GR ΟΓΗΓΙΔ ΥΔΙΡΙΜΟΤ ΚΑΙ ΤΝΑΡΜΟΛΟΓΗΗ IKD9885.0 IKD 12440.0 / IKD9440.0 KD9885.0 KD12440.0 / KD9440.0...
-
Page 3: Table Of Contents
Contents General Contents Your appliance data Safety Instructions Installation Assembly instructions Electrical connection Other assembly instructions and tips Mounting on a wall Mounting on the ceiling Operation Switching your appliance on / off Power controls Automatic delayed stop Switching the lamp on / off Dimmer function Filter saturation display Remote control... -
Page 4: Your Appliance Data
Please note: We require the following details for your request for customer service so that our customer service technicians can be well-prepared to carry out repairs and have the required spare parts available: Your exact address Your telephone number and, if available, fax number When can customer service call? An exact appliance designation: model no. -
Page 5: Safety Instructions
Safety Instructions This appliance complies with valid safety regulations. Improper handling may cause damage to property and injury to persons. Please read these instructions carefully before installing your appliance and using it. It contains important information and tips on assembly, safety and maintenance. Information concerning structural requirements The following instructions must be observed when cooker hoods are used in the extraction mode:... - Page 6 Safety instructions for assembly and use The metal grease filters must always be in place when the cooker hood is in operation. Greasy vapours may otherwise be deposited in the hood and in the extraction air system. In the case of gas cookers it is important to ensure that the cooking zones are not operated without any cookware.
-
Page 7: Installation
INSTALLATION Depending on the model, a minimum clearance of 60 cm must be maintained between an electric hob and the bottom of the cooker hood when installing the hood. A minimum clearance of 75 cm must be maintained for gas hobs (Fig. 1). Fig. -
Page 8: Other Assembly Instructions And Tips
Other important information In order to make sure that ventilation is optimal and that the hood operates quietly, the extraction air system, including the wall box, must be at least 150 mm in diameter. Please observe the following when installing the exhaust air pipe: Use short, straight exhaust air ducts. -
Page 9: Mounting On A Wall
MOUNTING ON A WALL KD9440.0E / KD12440.0E dimensioned drawing KD9440.0E / KD12440.0E dimensioned drawing of installation dimensions (back view) - Page 10 KD9885.0GE dimensioned drawing KD9885.0GE dimensioned drawing of installation dimensions (back view)
- Page 11 Take the wall mounting bracket shown in Fig. 2 and place it on the wall so that you have the height you want when you mount the cooker hood. Make sure that you maintain a minimum clearance of 60 cm between the hob and the bottom of the cooker hood for electric hobs and a minimum clearance of 75 cm for gas hobs.
- Page 12 You have several options for aligning the hood thanks to its multiaxial mounting system. To align the hood on the right and left hand side, you can either move the wall mounting bracket to the left or right until it is in the ideal position by loosening the screws and then fastening them again (if the hood needs to be moved by more than 0.5 cm) (Fig.
- Page 13 To mount the chimney take the assembly clamp that has been provided (Fig. 5), place it at the required height, generally right below the ceiling (Fig. 5) and then fasten it. You will then need to make the connection for the extraction air and mount the chimneys according to Fig.
-
Page 14: Mounting On The Ceiling
MOUNTING ON A CEILING IKD9440.0E / IKD12440.0E dimensioned drawing IKD9855.0GE dimensioned drawing... - Page 15 Assembly diagramme Ceiling Ceiling mounting bracket Mounting ring Mounting angle Motor box Stainless steel chimneys Cooker hood body...
- Page 16 Take the ceiling mounting bracket shown in Fig. 6 and place it on the ceiling so that you have the height you want when you mount the cooker hood. Make sure that you maintain a minimum clearance of 60 cm between the hob and the bottom of the cooker hood for electric hobs and a minimum clearance of 75 cm for gas hobs.
-
Page 17: Operation
OPERATION This cooker hood is regulated with touch-sensitive sensor controls or short-travel key controls located on the front of the hood. The controls react when the corresponding symbol is touched lightly or pressed. Short-travel key controls: You can regulate the power settings, the lamp, including the brightness level, as well as the automatic delayed stop function with the sensor controls. -
Page 18: Dimmer Function
Dimmer function The display will show two horizontal bars for approx. 5 seconds without a break as soon as this symbol is touched (Fig. A). When the symbol is touched again the display will show the level of brightness. The lamp is pre-set at brightness level “9”... -
Page 19: Remote Control
IR remote control An IR remote control (Fig. 8) may also be included with delivery, depending on the model and its features. It can be used to operate and regulate all the functions of the cooker hood from a distance of several metres. To do so, point the remote control towards the cooker hood and press the function of your choice on the remote control. -
Page 20: Maintenance, Cleaning And Care
Maintenance, Cleaning and Care It is absolutely essential to have your cooker hood regularly serviced in order to ensure that it operates efficiently for a long time. When the metal grease filter is clogged with particles of grease and dirt it will not work properly. The charcoal filter (only used for the circulation mode) cannot be rinsed or regenerated and must therefore be replaced at regular intervals. -
Page 21: Grease Filter
Grease filter To remove the grease filter press the bar rail handle of the filter down and remove the grease filter from the hood (Fig. 10). Then remove the grease filter from the stainless steel frame (Fig. 10.2). To replace the grease filter, first of all replace it in the stainless steel frame and then return it to the hood. -
Page 22: Charcoal Filter
Depending on how you cook and fry, the metal grease filters should be cleaned approximately every two weeks. Soak the metal grease filters and stainless steel frames well in hot soapy water, clean them with a soft brush and then spray them thoroughly with hot water to rinse them. - Page 23 The charcoal filter should be replaced after approximately three to six months. The intervals for cleaning and replacement should generally be observed in order to ensure that no greasy vapours are deposited on kitchen walls and units. If the metal filter is not regularly cleaned when the hood is operated in the circulation mode, the charcoal filter will also become clogged more quickly, impairing the operation of the hood.
