Total Access 900e Series Hardware Installation Guide

Table A-5. 1000Base-T Gigabit Ethernet Port Pinouts

Pin Name
1 TRD0+
2 TRD0-
3 TRD1+
4 TRD2+
5 TRD2-
6 TRD1-
7 TRD3+
8 TRD3-

Table A-6. CRAFT Port Pinouts

Pin Name
1 DCD
2 RD
3 TD
4 DTR
5 GND
6 DSR
7 RTS
8 CTS
9 —
Connection directly to an external modem requires a cross-over cable.
64243916F1-34A
Description
Transmit/Receive Positive
Transmit/Receive Negative
Transmit/Receive Positive
Transmit/Receive Positive
Transmit/Receive Negative
Transmit/Receive Negative
Transmit/Receive Positive
Transmit/Receive Negative
Description
Data Carrier Detect (output)
Receive Data (output)
Transmit Data (input)
Data Terminal Ready (input)
Ground - connected to unit chassis
Data Set Ready (output)
Request To Send - flow control (input)
Clear To Send - flow control (output)
Not Connected
Copyright © 2013 ADTRAN, Inc.
Appendix A
33
