About the iMediaChassis/6

The iMediaChassis/6 is a modular chassis platform designed for use with IMC
Networks' SNMP-manageable series of modules. The iMediaChassis/6 is a 1U high,
rackmountable chassis that features six slots for installing application series modules
plus an additional slot for installing an SNMP management module. Each
iMediaChassis/6 has the option of redundant power supplies.
SNMP Management Modules include two twisted pair ports, one for management
and one reserved for future use. The management module also features a DB-9 serial
port, and supports SNMP V1/V2c.
Redundant Power
When using redundant power, the two power supplies each supply 50% of the power
to the iMediaChassis/6 (i.e., they are load-sharing power supplies). AC and DC
power supplies can be mixed in the same chassis and power supplies are hot-
swappable. Refer to Power Supplies, Fans, and Temperature Gauge for more
information.

Installing the iMediaChassis/6

Manage an iMediaChassis/6 by installing a Management Module. Without the
Module, the chassis remains unmanaged. Before installing the application modules
into an iMediaChassis/6 install the chassis first. When installing the chassis, be sure to
observe the following precautions to prevent electrical or mechanical damage:
•
Stay within the chassis power rating to prevent overload of supply circuits or
damage to overcurrent protection and supply wiring.
•
Maintain reliable earth ground, especially when connecting to a power strip
instead of directly to a branch circuit.
•
Protect the chassis from exposure to sunlight and electrical or magnetic
fields.
•
Ensure that the equipment rack remains stable, even with the addition of
the chassis and its associated cabling.
To install an iMediaChassis/6, have four #10 screws and four clip nuts available.
(Hardware may vary depending on rack type.) The rest of the hardware is supplied
with the unit.
First, locate a suitable location in the rack for installation and secure the clip-nuts
onto the mounting rails. Use screws to attach the chassis to the rack. Finally, plug
the chassis into a reliable, filtered power source.
