Imc Networks Technical Support - IMC Networks iMediaChassis/6 Operation Manual

IMC Networks Technical Support

Tel: (949) 465-3000 or (800) 624-1070 (in the U.S. and Canada);
+32-16-550880 (Europe)
Fax: (949) 465-3020
E-Mail: techsupport@imcnetworks.com
Web: www.imcnetworks.com
Specifications
Physical Specifications
Dimensions: 1.75" x 17.35" x 10.65" (4.45cm x 44.07cm x 27.05cm)
Environmental
Operating Temperature: 32° - 122° F (0° - 50° C)
Storage Temperature: 0° - 160° F (-20° - 70° C)
Humidity: 5 - 90% (non-condensing); 0-10,000 ft. altitude
Power
AC Input Load: 100/240VAC±10%~50/60Hz
115V @ 0.8A and 230V @ 0.4A (redundant)
115V @ 1.6A and 230V @ 0.8A (single)
DC Input Load: -48VDC = 1A max (redundant); 2A max (single)
18
