Front Panel - Engl SOVEREIGN 100 Operating Manual

The last page contains a front- and backpanel illustration!

FRONT PANEL

1 GAIN .............................................................................................................................
Input sensitivity control for the Clean channel.
2 BRIGHT (Lo/Hi) ............................................................................................................
Alters the EQ by boosting the upper treble range in the Clean Channel;
effectiveness decreases at higher GAIN (1) settings.
3 MID SHIFT
Shifts the midrange in the Clean channel: press the pushbutton, and the mids are amplified
in the 1 to 2 kHz range.The degree of amplification depends a great deal on the
TREBLE control setting.
4 BASS .............................................................................................................................
Bottom end voicing control for the Clean channel.
5 MIDDLE .........................................................................................................................
Mid-range voicing control for the Clean channel.
6 TREBLE ..........................................................................................................................
Upper range voicing control for the Clean channel.
7 REVERB
Reverb control, adjusts the portion of the reverb signal and increases reverb intensity in the
Clean channel if you rotate it clockwise; the reverb can be switched on/off via a footswitch (jack 31).
8 CLEAN BOOST .............................................................................................................
Amplification boost for the Clean channel. This function can also be activated via the
footswitch jack 31; you can select two variations (refer to 31).
9 CLEAN VOL.
Volume control for the Clean channel. (in front of the FX loop, affects the SEND level)
10 CHANNEL
Main channel selector pushbutton for switching between Clean and Crunch or Lead,
depending on the CRUNCH/LEAD (21) setting. The green LED next to the CLEAN VOL. control
indicates the Clean channel is active. This function can also be activated via footswitch (jack 19)
in this case the channel selector pushbutton is deactivated.
11 INPUT
Unbalanced 1/4" input jack
12 GAIN
Input sensitivity control, functions as pre-gain for the Crunch and the Lead channel and
defines the amount or distortion in the Crunch channel.
13 LEAD BOOST
Boosts the degree of distortion in the Lead channel, with primary emphasis on the bottom end.
4
