Thank you for purchasing this CLARKE RANGER25 Oil Free Air Compressor, which is designed for hobby and DIY use only. Please read this leaflet thoroughly and carefully follow all instructions. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to the compressor giving you long and satisfactory service. -
Page 4: Safety Precautions
2. NEVER operate your compressor with any guards removed. 3. Electrical or mechanical repairs should only be carried out by a qualified engineer. If problems occur, contact your Clarke dealer. 4. Before carrying out any maintenance, ensure the pressure is expelled from the air receiver, and the machine is disconnected from the mains. -
Page 5: Assembly
14. Personal safety products can be obtained from your local dealer. 15. NEVER exert any strain on electrical cables and ensure that air hoses are not tangled or wrapped around machinery etc. 16. When disconnecting air hoses or other equipment from your compressor ALWAYS ensure that the air supply is turned off at the machine outlet and expel all pressurised air from within the machine and other equipment attached to it. -
Page 6: Electrical Connections
ELECTRICAL CONNECTIONS Connect the mains lead to a standard, 230 Volt (50Hz) electrical supply through an approved 13 amp BS 1363 plug, or a suitably fused isolator switch. WARNING! THIS APPLIANCE MUST BE EARTHED IMPORTANT: The wires in the mains lead are coloured in accordance with the following code: Green &... -
Page 7: Operating Instructions
OPERATION (Numbers in brackets refer to fig. 1 below) Before connecting your Ranger25 to the mains supply, check the following:- • The mains voltage is 230V. • The ON/OFF control knob (1) is in the OFF (lower) position. • The pressure regulator (2) should be set at its lowest setting, i.e. turned fully anticlockwise, and the tap (3) screwed IN to its closed position. -
Page 8: Routine Maintenance
Daily before use, always open the drain valve to ensure that any condensate, which may have accumulated, is drained off. It is important to keep the CLARKE Air Compressor clean, and this may be done with the help of a small soft brush and vacuum cleaner. In particular,... -
Page 9: Troubleshooting
TROUBLE SHOOTING With considerate use, your CLARKE Air Compressor should provide you with a long and trouble free period of operation. Routine checks should be made on both the electrical supply as well as on all the compressed air lines and connections. If any fault appears, the reason for which is not immediately obvious, we recommend that you contact your local CLARKE Dealer. -
Page 10: Accessories
Dimensions ........660x330x630mm Please note that the details and specifications contained herein, are correct at the time of going to print. However, CLARKE International reserve the right to change specifications at any time without prior notice. Always consult the machine’s data plate... -
Page 11: Paint Spraying Hints - General Preparation
PAINT SPRAYING HINTS WARNING NEVER attempt to spray unless you are wearing suitable, approved respiratory and eye protection. REMEMBER that some modern paints require specialist respiratory protection...always consult the paint manufacturers instructions. 1. GENERAL PREPARATION a. Ensure that the area in which you will be spraying is clean and dust free. b. -
Page 12: Handling The Gun
For a professional looking finish paint must be thinned. If the manufacturers recommendations on thinning are not available, the following can be used as a general guide: Water based paints (emulsions) - 10-20% water Oil based paints (gloss) - up to 10% white spirit thinners Cellulose paints - up to 50% cellulose thinners 3. -
Page 13: Parts List
48 Fuse Protection 8A 1 FN008040000 - Wheel Kit compl. FN117HL0010 For Spare Parts and Service,please contact your nearest dealer, or CLARKE International, on one of the following numbers. PARTS & SERVICE TEL: 020 8988 7400 PARTS & SERVICE FAX: 020 8558 3622 e-mail as follows: PARTS: Parts@clarkeinternational.com... -
Page 14: Parts Diagrams
PARTS DIAGRAM...
