Setting the time of day

The dial on the front of the 102 displays the hours of the
day using the 24hour clock.
Remove dial cover (turn
slightly to the left and
pull off)
Turn the dial clockwise
until the correct time is
aligned to the TIME
mark (as shown).
IMPORTANT: turn the dial clockwise only
!
Remember you will have to re-set the time after
a power-cut, and also when the clocks change
in Spring and Autumn.

Setting the programme

1. If not already done so, remove the dial cover (turn
slightly to the left & pull off)
2. Decide when you want your hot water and heating
to come on and go off. While gripping the dial knob
slide the RED tappets to the required ON times and
the BLUE tappets to the required OFF times (the
tappets may be quite stiff to move)
Note: Tappets can be moved around the dial in a clockwise
or anti-clockwise direction, as convenient.
8
TIME mark
(Tappets A, B, C, D)
