A. Menu bar: The Menu bar includes the different menus for setting up the
scanner (Scanner menu), controlling view options (View menu), customizing
the software (Preferences menu), Image Correction function (Correction
menu), and accessing on-line help (Help menu).
B. Overview button: This button previews the specified or entire scan bed.
C. Prescan button: This button previews one or more detailed images of the
area(s) selected by the Frame (Scan Frame) tool.
D. Unit of Measurement: Select the unit of measurement for the rulers by
clicking the arrow button at the 0,0 point of the rulers and choosing from
the drop-down menu.
E. Rulers: Rulers are located on both sides of the Preview window to help you
with measurement and alignment.
F . Toolbar: The buttons in the T oolbar perform specific actions on the
overview or prescan image. Tool buttons include the Scan Frame (Frame)
tool, Zoom (Magnify Glass) tool, Move (Pan) tool, and Pickers tool.
G. Exit button: Click to close the user interface of the ScanWizard EZ -
Professional mode and quit the ScanWizard EZ scanning software.
H. Minimize button: Click it to minimize ScanWizard EZ - Professional mode.
I. Advanced Mode button: Click to switch to ScanWizard EZ - Advanced
mode.
J. EZ Mode button: Click to switch to ScanWizard EZ - EZ mode.
K. Scan Material button: This shows the type of your scan material – Reflective
(photos and prints), Positive, or Negative.
L. Scan to button: This button starts the final scanning process.
M. Overview window: This is a floating window with a fixed size, which
appears on the screen whenever the Professional mode is activated.
N. Overview area: The overview or prescan image is displayed in this area
after you perform a scan.
O. Status bar: This area shows you information pertinent to the operation
underway or being performed.
P. Resize: To increase or decrease the Preview window , drag the bottom right
corner of the window to resize.
