- Page 2 Documents that you scan may be protected under copyright law. The unauthorized use of such documents could be a violation of the rights of the copyright holder. Microtek bears no responsibility for the unauthorized use of copyrighted materials.
-
Page 3: Table Of Contents
Contents Introduction ... 1 System Requirements ... 1 Launching ScanWizard DI ... 2 Exiting ScanWizard DI ... 2 ScanWizard DI Control Panel ... 2 Basic Scenarios ... 4 A. How to Scan a Stack of Papers ... 4 B. How to Scan a Single-sheet Document ... 6 C. - Page 4 Save Settings ... 31 Save Settings to Function Button ... 31 Load Settings to Function Button ... 34 The Scanner Menu ... 35 Get Current Scanner Info ... 35 Scanner Control ... 35 The Preferences Menu ... 35 Invert ... 35 Scan Quality ...
-
Page 5: Introduction
Introduction ScanWizard DI is Microtek's scanning software developed exclusively for Document Imaging (DI) scanners. Supporting both TWAIN and ISIS protocols and featuring multiple scanning frames with an all-in-one control panel, ScanWizard DI is easy to use, yet powerful. • Dual-driver support — ISIS (Image and Scanner Interface Specification) and TWAIN. -
Page 6: System Requirements
• From Plug-in mode: Choose the Import or Acquire command from the File menu of your application, then select Microtek ScanWizard DI. • From Stand-alone mode: Double-click the ScanWizard DI icon on the Windows desktop, or choose Start, Programs, Microtek ScanWizard DI for Windows, then ScanWizard DI. Exiting ScanWizard DI To exit ScanWizard DI: Click the Exit button “X”... - Page 7 ScanWizard DI Control Panel Interface Image input device (i.e., flatbed, or ADF ) Image output type Dimensions of the preview window or Selections for paper size Output resolution (in dpi) Image orientation (i.e., rotate or mirror) Parameters for controlling the frame location settings (i.e., position of coordinates, image size, and the unit of...
-
Page 8: Basic Scenarios
Basic Scenarios This section provides three basic scanning scenarios with ScanWizard DI, including scanning a stack of paper, scanning a single-sheet document, and performing multiple-frame scanning. Details on how to adjust images are discussed in later chapters. A. How to Scan a Stack of Paper 1. - Page 9 If ScanWizard DI is launched as a stand-alone program, the scanned image can be saved after the scan to a file, opened in an image-editing program, or sent to a printer. Scanning settings Image type Image correction settings For preview purposes only, take note of the additional notes below: 1.
-
Page 10: How To Scan A Single-Sheet Document
B. How to Scan a Single-sheet Document 1. Place the single-sheet document to be scanned on either the scanner glass surface, or from the ADF’s document feed tray. 2. Launch ScanWizard DI (either as a stand-alone by clicking on the program icon, or by using the File-Import or Scan command from an application program. - Page 11 7. If necessary, adjust image quality using the image correction tools. 8. Click the Scan or Scan To button to start scanning. If ScanWizard DI is launched from an image-editing program, the scanned image is delivered after the scan to your application, where the image can be saved, printed, or modified further.
-
Page 12: How To Scan Multiple Frames
C. How to Use Multiple Frames 1. Place the single-sheet color print to be scanned on either the scanner glass surface, or from the ADF’s document feed tray. 2. Launch ScanWizard DI (either as a stand-alone by clicking on the program icon, or by using the File-Import or Scan command from an application program. - Page 13 b) Select Line Art in the Attribute as your image type for the selected frame. c) If necessary, adjust image quality using the image correction tools. 10. Click the Scan or Scan To button to start scanning. If ScanWizard DI is launched from an image-editing program, the scanned image is delivered after the scan to your application, where the image can be saved, printed, or modified further.
-
Page 14: Preview Button
It performs the final scan and sends the scanned image (output) to the application that you are using. If you are using the ISIS scanner interface, the Scan button will not be visible. To perform the final scan, use the Scan function in your ISIS-based application. -
Page 15: Scan To
TIF. When enabled, ScanWizard DI will prompt you to place the next page as you scan from the scanner bed. Then click the Continue button to scan; or click the Close button to save multiple images as a single file. If you scan through the ADF, the scanning originals are sequentially scanned until paper out;... -
Page 16: Copy
When the Scan Type in the Settings window is set to “RGB Color” or “Grayscale,” and you select “PDF” as your “Save as type” in the “Scan To: Save As” dialog box and then click the File Option button, the “PDF Save Options”... -
Page 17: Ocr
ScanWizard DI will prompt you to place the next page as you scan from the scanner bed. Then click the Continue button to scan; or click the Close button to save multiple pages as a single file. If you scan through the ADF, the scanning originals are sequentially scanned until paper out;... -
Page 18: Toolbar
Toolbar The toolbar has buttons for executing certain tasks. The toolbar includes Select Frame, Pan, Zoom In, Zoom Out, Create Subframe, and Delete Subframe. Select Frame tool The Select Frame tool allows you make the frame selection and adjust the size of the frame for enclosing your final scan. -
Page 19: Zoom Out Tool
Zoom Out tool The Zoom Out tool reduces your view of the preview image, allowing you to set the scan frame with greater precision. Only the view size of the preview image is changed; the actual output size of the image remains the same. The reduction levels decrease from 400%, 300%, 200%, to 100%. -
Page 20: Scan Source
The maximum dimension of the preview size depends on the bed size of your scanner or is controlled by the ADF . Paper Size options include: A3, B4, Legal, Letter, A4, B5, A5, Full Scan Area, and Auto-crop; default is A4. -
Page 21: Rotate
When dealing with resolution, remember to distinguish between optical resolution and interpolated resolution. Optical resolution is the “real” resolution as measured by the scanner’s optics. Interpolated resolution is software-enhanced resolution and can be useful for enlarging very small images or for printing line art to obtain superior results. -
Page 22: Frame Settings
Frame Settings Allows you to set different frame settings. The options for frame property settings include: Attribute, Coordinate Position (X, Y), Image Size (W, H), Unit of Measurement, Image Correction tools, Default button, and Advanced buttons. Attribute The Attribute allows you to select the image type of the selected frame. Options include Photo, Line Art, and Text. -
Page 23: Coordinate Position (X,Y)
Coordinate Position (X, Y) The Coordinate Position shows the X/Y coordinates of the selected frame, starting from the upper left corner of the frame in the preview window. To move the selected frame to another position, enter the values manually in the X and Y edit boxes;... -
Page 24: Image Correction Settings
Image Correction Settings Image correction tools let you adjust the image attributes in ScanWizard DI. Work with the image correction tools to see how they optimize your results. ScanWizard DI supports these image correction tools: • Threshold • Brightness/Contrast • Hue/Saturation •... -
Page 25: Threshold
Threshold The Threshold control is active only when the Attribute setting of the selected frame image is Line Art. The default Threshold is preset to 128. To change the default Threshold setting, you should disable the “Auto Threshold” setting in the Advanced Setting window. To do this, click the Advanced... button to open its window, uncheck “Auto Threshold”, and click OK. -
Page 26: Brightness/Contrast
Brightness/Contrast The Brightness/Contrast control is active only when the Attribute setting of the selected frame image is Photo. Brightness/Contrast lets you control the brightness and contrast levels of the selected frame image. Increasing the brightness makes all tones in the image lighter. Contrast, on the other hand, is the range between the darkest and lightest shades in the image, and increasing the contrast makes for greater separation between the darkest and lightest areas of the image. -
Page 27: Sharpen
Sharpen The Sharpen filters let you apply or create special sharpening effects to your selected frame images. The Sharpen filters include None, Sharpen, Sharpen More, Edge Enhancement, and Unsharp Masking. In using any of the sharpen filters, keep in mind that the image you obtain in the preview window may differ from the way the image appears when you finally scan it in. -
Page 28: Unsharp Masking
Unsharp Masking The Unsharp Masking filter is used to adjust the contrast of edge detail, creating the illusion of more image sharpness. This filter can be useful for refocusing an image that has become blurry from interpolation or scanning, and it is an essential tool for doing CMYK color separation. -
Page 29: Descreen
Descreen The Descreen feature lets you remove moiré patterns from printed materials. Moirés occur when you scan a screened original (mostly reflective or previously printed material, such as pictures from a newspaper or magazine). These patterns appear to the naked eye like a series or grid of dots or as shown in the example below. Before To set the screen for your needs, follow the steps below: 1. -
Page 30: Default Button
Whether or not the tabs for optional functions can be seen is determined by the scanner you are using. This means that if your scanner (e.g., ArtixScan DI 6020) implements the endorser function, double feeds, or MICR function, these tabs can be seen in this window;... -
Page 31: Lamp Filter
The Lamp Filter function allows you to remove an unwanted color cast (i.e., green, red, or blue) from your originals. For example, to eliminate a greenish color cast, select Green as your lamp filter. For some scanner models (i.e., ArtixScan DI 6020), only the green and red filter options are available. -
Page 32: Endorser
“Main Frame”. Enable Endorser: This enables the scanner to print the endorser string on the backside of the scanned document. If unchecked, the endorser string will not be printed. The default is unchecked. -
Page 33: Double Feed
If selected, the scanning will stop and a beep sounds when double-feed errors caused by this factor occur during scanning. For details on how to remove double-feeds from the tray, refer to the Microtek Installation and Operation Manual. -
Page 34: Micr (Magnetic Ink Character Recognition)
MICR function and the current working frame is “Main Frame”. Magnetic ink character recognition: This enables the scanner to convert MICR codeline into a text string. If unchecked, a scanned MICR codeline will not be recognized from the document. The default is unchecked. -
Page 35: The File Menu
.set. The saved template can be loaded at a later time when necessary. Saving same image setting is useful if you consistently work in a specific format, scan the same kind of the images, or if the scanner is shared to use by others who have their own image settings. - Page 36 TIF. When enabled, ScanWizard DI will prompt you to place the next page as you scan from the scanner bed, then click the Continue button to scan; or click the Close button to save multiple images as a single file. If you scan through the ADF, originals are sequentially scanned until paper out;...
- Page 37 The OCR page allows you to define a function button as a set of OCR settings. When you have completed the settings on this page, press the corresponding function button on your scanner, and the scanner will scan the image and save it as a text file ready for OCR and editing.
-
Page 38: Load Settings To Function Button
PDF. When enabled, ScanWizard DI will prompt you to place the next page as you scan from the scanner bed, then click the Continue button to scan; or click the Close button to save multiple pages as a single file. If you scan through the ADF, originals are sequentially scanned until paper out;... -
Page 39: The Scanner Menu
The Scanner Menu Get Current Scanner Info This command displays information about your current scanner. When you choose this command, a dialog box appears showing the scanner model, scanner ID number, firmware version, and the equipment. Scanner Control This command lets you specify a lead time for turning off the scanning lamp, thus saving power. -
Page 40: Show/Hide Frame Tag
Visible: The frame is marked with a check, indicating that the frame is visible in dotted lines in the preview window. The frame is visible by default. To hide the frame selection in the preview window, click the check mark again. If the frame is unchecked, the frame cannot be selected in the preview window.
