Output Settings

The Output settings (width and height) represent the dimensions of the image
when it is output (to either monitor or printer). If the size of the image to be
output is different from the size of the original image, adjust the scaling
Scan Frame options
The Scan Frame options include Fixed Scan Frame, Fixed Output Size, and Keep
Proportion.
Fixed Scan Frame
This option lets you lock in the settings of your scan frame, so that the width and
height dimensions of the frame are always fixed no matter where you move the
frame in your preview image.
If you know the exact input size for your image, or if you wish to "lock" the
settings of your scan frame to a particular size, enter the Scan Frame width and
height values first, then check Fixed Scan Frame. Y our scan frame will be fixed at
those values. So even if you move the scan frame around the preview image, the
dimensions of the frame itself will remain unchanged.
Fixed Output Size
When the Fixed Output Size option is checked, the values specified for output
width and height remain fixed. If any of the input values are changed, the scaling
will be automatically adjusted proportionally to maintain the output dimensions
as defined.
If you know the exact output size for your image, enter the output width and
height values first, then check Fixed Output Size. The image will then be scanned
and output at the values specified.
Keep Proportion
When the Keep Proportion option is checked, the width and height values of the
image are kept in proportion despite changes made to either setting. This
preserves the aspect ratio of the image.
This option is automatically checked when either "Fixed Scan Frame" or "Fixed
Output Size" is selected.
