- Page 1 LC-52XS1E LC-65XS1E TU-X1E LCD COLOUR TELEVISION LCD-FARBFERNSEHGERÄT TÉLÉVISEUR COULEUR À ÉCRAN CRISTAUX LIQUIDES (LCD) TELEVISORE A COLORI LCD OPERATION MANUAL LCD-KLEURENTELEVISIE BEDIENUNGSANLEITUNG TELEVISIÓN EN COLOR LCD MODE D’EMPLOI TELEVISOR DE CRISTAL LÍQUIDO MANUALE DI ISTRUZIONI GEBRUIKSAANWIJZING MANUAL DE MANEJO MANUAL DE OPERAÇÃO...
- Page 2 SPECIAL NOTE FOR USERS IN THE U.K. The mains lead of this product is fitted with a non-rewireable (moulded) plug incorporating a 13A fuse. Should the fuse need to be replaced, a BSI or ASTA approved BS 1362 fuse marked and of the same rating as above, which is also indicated on the pin face of the plug, must be used.
-
Page 3: Table Of Contents
The illustrations and the OSD in this operation manual are for explanation purposes and may vary slightly from the actual operations. • The examples used throughout this manual are based on the LC-52XS1E model. • This model is compatible with H.264 (MPEG4 H.264, MPEG4 AVC, MPEG4 AVC/H.264) compressed broadcasts. -
Page 4: Introduction
Introduction Dear SHARP customer Thank you for your purchase of the SHARP LCD colour TV product. To ensure safety and many years of trouble- free operation of your product, please read the Important Safety Precautions carefully before using this product. -
Page 5: Remote Control Unit
Introduction Remote control unit NOTE The symbols 8, 9 and 0 indicate that the buttons become available in respective operating mode when using as a universal • remote control. TV B (TV Standby/On) (Page 17) b (INPUT SOURCE) Select an input source (Page 17). LIGHT D 8 9 0 When pressed, buttons that are frequently RADIO... -
Page 6: Part Name
Introduction Part name Display (Front view/Side view) il/k Volume buttons* Remote control sensor Ps/r Programme (channel) B (Standby/On) indicator buttons* SLEEP indicator b (INPUT SOURCE) button* OPC indicator MENU button* RESET button The symbols light up when pressing these buttons. After a a (Main Power) button* USB terminal period of time, the light will turn off. -
Page 7: Preparation
AN-52AG8 52XS1E) • Additional optional accessories may be available in the near future. When purchasing, please read the newest Wall mount bracket (LC- AN-65AG2 catalogue for compatibility and check the availability. 65XS1E) Stand unit (LC-52XS1E) AN-52ST1 Stand unit (LC-65XS1E) AN-65ST1... -
Page 8: Inserting The Batteries
Preparation Inserting the batteries Before using the TV for the first time, insert two supplied “AAA” size alkaline batteries. When the batteries become depleted and the remote control unit fails to operate, replace the batteries with new “AAA” size batteries. Open the battery cover. -
Page 9: Quick Guide
Quick guide Initial installation overview Follow the steps below one by one when using the TV for the first time. Some steps may not be necessary depending on your TV installation and connection. Before turning on the main power Prepare the Display (Page 8) HDMI cable: •... -
Page 10: Before Turning On The Main Power
LC-65XS1E: The centre of the TV screen is at mark “A” on the wall bracket. Setting the Display with the optional stand • This Display should be set on a table or floor, etc. only with the stand available from SHARP, sold separately (Page 5). •... -
Page 11: Setting The Tv And Antenna Cables
Quick guide Setting the TV and antenna cables Supplying power to the antenna You must supply power to the antenna in order to receive digital terrestrial broadcasts or satellite broadcasts after running the initial auto installation. Go to “MENU” > “Setup” > “Antenna Setup-DIGITAL” > “Digital Setup” >... -
Page 12: Turning On And Running The Initial Auto Installation
Quick guide Turning on and running the initial auto installation Plugging the AC cord to the AC outlet Place the TV close to the AC outlet, and keep the power plug within reach. AC cord* AC cord* Product shape varies in some countries. Power on and run the auto installation Turn on the main power using a on the Display. -
Page 13: Initial Auto Installation
Quick guide Starting channel search. Initial auto installation When the TV is powered on for the first time after Digital Search purchase, the initial auto installation wizard appears. Analogue Search Follow the menus and make the necessary settings Skip one after another. Press a/b to select “Digital Search”, “Analogue Confirm the following before turning Search”... - Page 14 Quick guide When you change each item to the appropriate “Cable” searching settings: The current DVB-C settings are displayed on the Press c/d to select “Change Setting”, and screen. then press OK. Scrambled stations: Scrambled stations [No] Search method: Channel Search method [Ch] Start frequency:...
- Page 15 Quick guide Menu Description Selectable Item “Analogue Search” setting Specifies if you Scrambled need to add pay-TV Yes, No Stations services. 01 628.25 02 693.25 03 767.25 04 831.25 Channel: Extracts all of information from a channel (quick, but needs Search Specifies how you corresponding TV...
- Page 16 Quick guide Change setting: “Satellite Search” setting Press c/d to select “Change setting”, and then press OK. Press c/d to select “Yes”, and the then press • The setting screen of “Scrambled stations” and “Symbol rate” is displayed. Scrambled stations [No] SAT1-Symbol rate 1 [6875]...
- Page 17 Quick guide When you change the antenna connection EXAMPLE setting: Press c/d to select “Change Setting” on the DVB-S SAT1 LOW [9000] 9000 12000 setting screen in the left column, and then press OK. SAT1 High [12000] 9000 12000 • The antenna connection setting screen is displayed.
-
Page 18: Checking Signal Strength And Channel Strength (Dvb-T/C)
Quick guide Checking signal strength and Checking signal strength and channel strength (DVB-T/C) channel strength (DVB-S) If you install a DVB-T/C antenna for the first time or If you install a DVB-S antenna for the first time or relocate it, you should adjust the alignment of the relocate it, you should adjust the alignment of the antenna to receive a good reception while checking antenna to receive a good reception while checking... -
Page 19: Watching Tv
Watching TV Daily operation Changing channels With 0–9: With Pr/s: Switching on/off Turning on/off the main power Press a on the Display. Switch it off by pressing a on the Display. Selecting an external video source NOTE • When turning off the main power Once the connection is made, press INPUT SOURCE using a on the Display, EPG data... -
Page 20: Epg
Watching TV EPG is a programme list that is displayed on the screen. With the EPG, you can check the schedule of DTV/SAT/ RADIO/DATA, view detailed information about them, tune to an event currently on-air and set a timer for future events. -
Page 21: Selecting A Programme Using Epg
Watching TV Selecting a programme using EPG Basic Operation The illustrations on this page are explained using three digit services. Display/Close the EPG screen [DTV-TV] Today (Tue)20 (Wed)21 (Thu)22 (Fri)23 (Sat)24 (Sun)25 (Mon)26 [Mon]16/04 10:57 AM BBC News 24 BBC News Press EPG. -
Page 22: Timer Recording Using Epg
Watching TV Timer recording using EPG Cancelling the timer recording You can record TV programmes using data from the Press EPG. EPG. Press a/b/c/d to select the programme on Press EPG. timer setup, and then press OK. Press a/b/c/d to select the programme you Press c/d to select “Cancel”, and then press want to record, and then press OK. -
Page 23: Teletext
Watching TV Buttons for teletext operations Teletext Buttons Description What is Teletext? Increase or decrease the page number. Pr/s Teletext broadcasts pages of information and Colour (R/G/ Select a group or block of pages entertainment to specially equipped TV. Your TV Y/B) displayed in the coloured brackets at the receives teletext signals broadcast by a TV network,... -
Page 24: Connecting External Devices
Connecting external devices Before connecting ... • Be sure to turn off the TV and any devices before making any connections. • Firmly connect a cable to a terminal or terminals. • Carefully read the operation manual of each external device for possible connection types. This also helps you get the best possible audiovisual quality to maximise the potential of the TV and the connected device. -
Page 25: Hdmi Connection
Connecting external devices HDMI connection Component connection Example of connectable devices Example of connectable devices DVD player/recorder E Blu-ray player/recorder VCR E DVD player/recorder Game console Blu-ray player/recorder The HDMI connections permit digital video and audio You will enjoy accurate colour reproduction and transmission via a connection cable from a player/ high quality images through the EXT3 terminal when recorder. -
Page 26: Scart Connection
Connecting external devices SCART connection Example of connectable devices Example of connectable devices VCR E DVD player/recorder Decoder When using the EXT2 (SCART) terminal If your VCR supports TV-VCR advanced AV Link systems, you can connect the VCR using a fully wired SCART cable. -
Page 27: Speaker/Amplifier Connection
Connecting external devices Speaker/amplifier connection Connect an amplifier with external speakers as shown below. Connecting an amplifier with digital audio Connecting an amplifier with analogue input audio input Optical audio cable Audio cable DIGITAL AUDIO IN AUX OUT AUX1 IN Amplifier with Amplifier with digital audio input... -
Page 28: Inserting A Ca Card
Connecting external devices Checking CI Module information Inserting a CA Card NOTE In order to receive coded digital stations, a Common • Make sure that the CI Module is properly inserted. Interface Module (CI Module) and a CA Card must be •... -
Page 29: Aquos Link
AQUOS LINK Controlling HDMI devices using AQUOS LINK What is AQUOS LINK? Using the HDMI CEC protocol, with AQUOS LINK you can interactively operate compatible system devices (AV amplifier, DVD player/recorder, Blu-ray player/recorder) using a single remote control unit. NOTE •... -
Page 30: Aquos Link Setup
AQUOS LINK Connecting an AQUOS BD Player/AQUOS Recorder via Connecting an AQUOS BD the AQUOS AUDIO speaker system Player/AQUOS Recorder only Optical audio cable HDMI-certified HDMI-certified cable cable HDMI-certified cable AQUOS BD Player/ AQUOS BD Player/ AQUOS AUDIO AQUOS Recorder AQUOS Recorder speaker system AQUOS LINK Setup... -
Page 31: Operating An Aquos Link Device
AQUOS LINK Open the remote control unit’s flip cover, and Operating an AQUOS LINK device then press OPTION. Press a/b to select “Setup Menu”, and then AQUOS LINK allows you to operate the HDMI- press OK. connected device with a single remote control unit. Open the remote control unit’s flip cover. -
Page 32: Menu Operation
Menu operation What is the MENU? • You need to call up the OSD to perform settings for the TV. The OSD for the settings is called “MENU”. • The “MENU” enables various settings and adjustments. • The “MENU” can be operated with the remote control unit. Common operations Display the MENU Select an item... -
Page 33: Basic Adjustment
Basic adjustment Picture Settings Picture Advanced Picture DYNAMIC This TV provides various advanced functions for optimising the picture quality. [Off] Backlight [+14] –16 Contrast [+30] Brightness –30 Colour –30 100Hz Tint –30 Film Mode Sharpness –10 Active Contrast Gamma setup Advanced Reset 3D-Y/C... -
Page 34: Av Mode
Basic adjustment AV MODE Film Mode Automatically detects a film-based source (originally encoded “AV MODE” gives you several viewing options to at 24 or 25 frames per second, depending on the vertical choose from to best match the system environment, frequency), analyses it and then recreates each still film frame which can vary due to factors like room-brightness, for high-definition picture quality. -
Page 35: Power Save Settings
Basic adjustment EXAMPLE Audio Picture Surround DYNAMIC This function allows you to enjoy realistic live sound. [On] Backlight [+14] –16 Audio Contrast [+30] Sound Mode Brightness –30 • When “OPC” is set to “On” or “On:Display”, an “Energy Save” status icon appears to the left of “OPC” in the This function allows you to select the sound mode “Picture”... -
Page 36: Channel Settings
Basic adjustment Programme Setup Channel Settings Auto Installation Setup Programme Setup Setup Auto Installation You can reconfigure each service setting automatically or manually. Press a/b to select the broadcast standard The TV automatically detects and stores all available you want to reconfigure, and then press OK. services in your area. - Page 37 Basic adjustment Buttons for Manual Adjust operation Satellite Setting Lock: Press R button. Before selecting the type of search in “Satellite When the service is locked, you must enter your PIN Setting”, you need to select the satellite broadcast. whenever you tune to the service. CH Skip: Press G button.
- Page 38 Basic adjustment Skip Analogue Setting Channels with “Skip” set to “On” are passed over You can reconfigure the analogue TV channels settings when using Pr/s even if selected while watching automatically or manually. the image from the TV. Additional Search Decoder Use this menu to add new channels automatically after When connecting a decoder to the AVC System, you...
-
Page 39: Password/Parental Lock Settings
Basic adjustment Password/Parental lock settings Language Settings (language, subtitle, multi audio) Setup Setup Child Lock Language Allows you to use a PIN to protect certain settings from being accidentally changed. You can select a OSD language from the “Setup” menu. Select from among 23 languages (Czech, Change PIN Danish, Dutch, English, Estonian, Finnish, French, German, Greek, Hungarian, Italian, Latvian, Lithuanian,... -
Page 40: Useful Viewing Functions
Useful Viewing functions Selecting the picture size manually Selecting the picture size You can select the picture size. Selectable picture size Selecting the WSS picture size varies with the type of signal received. automatically Item (for SD [Standard-Definition] signals) Setup Normal: Keeps the original aspect ratio in a full screen display. -
Page 41: Selecting The Recording Picture Size Manually
Useful Viewing functions Selecting the recording picture Automatic volume adjustment size manually Option Digital Setup Auto Volume REC Picture Size Different sound sources sometimes do not have the same volume level, such as a programme and its You can use this menu to set the appropriate picture commercial breaks. -
Page 42: Display Settings
Useful Viewing functions Display Settings Time and Title display Channel display Option Time Display You can display the channel information by pressing p on the remote control unit. DTV Mode ATV Mode Time Display BBC2 BBC1 This function allows you to display the clock time in the lower-right corner of the screen. -
Page 43: Other Useful Features
Other useful features Setting when using external Skipping specified inputs devices Setup Input source settings Input Skip Option This setting allows you to skip the SCART, HDMI, Input Select RGB, ATV, DTV or SAT input on the Input Source Selection operation. For setting the signal type of external equipment. -
Page 44: Connecting A Usb Device
Other useful features Connecting a USB device Photo Mode Connect a USB device to the AVC System as shown below. Viewing thumbnails Sample Demo/Demo 01 Demo.jpg • Depending on the USB device, the TV may not be able to 2007:10:18 13:30:00 600KB recognise the contained data. -
Page 45: Music Mode
Other useful features Music Mode Slide show Selecting the BGM File name Time Demo/Demo1 ROOT File name Time CLASSIC SONG_01.MP3 3:05 Demo/Demo1 SONG_02.MP3 3:15 SONGS SONG_03.MP3 3:02 CLASSIC SONG_04.MP3 6:05 SONG_01.MP3 3:05 SONG_05.MP3 4:52 SONG_02.MP3 3:15 SONG_06.MP3 0:00 SONG_03.MP3 3:02 SONG_07.MP3 3:13 SONG_04.MP3... -
Page 46: Gallery Mode
Other useful features Gallery Mode You can display pictures saved in USB devices for your wallpaper picture by pressing GALLERY on the remote control unit. NOTE • Compatible files include those taken by digital cameras with the DCF 2.0 specification or mobile phones’ built-in cameras. •... -
Page 47: Troubleshooting For Gallery Mode
Other useful features Picture size Troubleshooting for Gallery Mode Follow the possible solutions listed below when you Item see the error message. Normal: Keeps the original aspect ratio in a full screen display. Dot by Dot: Displays images with a 1:1 pixel ratio on the screen without any scaling. -
Page 48: Connecting A Pc
Connecting a PC Connecting a PC Displaying a PC image on the screen HDMI Connection Selecting the picture size HDMI1, 2 or 3 You can select the picture size. HDMI-certified cable Press f. • The “WIDE MODE” menu displays. Press f or a/b to select a desired item on the menu. -
Page 49: Adjusting The Pc Image Automatically
Connecting a PC Item Adjusting the PC image H-Pos.: Centres the image by moving it to the left or automatically right. V-Pos.: Centres the image by moving it up or down. This function enables the screen to be automatically Clock: Adjusts when the image flickers with vertical adjusted to its best possible condition when the stripes. -
Page 50: Rs-232C Port Specifications
Connecting a PC Parameter RS-232C port specifications Input the parameter values, aligning left, and fill with blank(s) for the remainder (Be sure that four values are PC Control of the TV input for the parameter). • When a programme is set, the TV can be controlled When the input parameter is not within an adjustable from the PC using the RS-232C terminal. -
Page 51: Pc Compatibility Chart
Connecting a PC PC compatibility chart Horizontal Vertical Analogue (D- VESA Resolution Digital (HDMI) Frequency Frequency Sub) Standard ✔ ✔ ✔ 640 g 480 31.5 kHz 60 Hz ✔ ✔ ✔ SVGA 800 g 600 37.9 kHz 60 Hz ✔ ✔... -
Page 52: Appendix
Appendix Manufacturer code Using the universal remote control Manufacturer Code Manufacturer Code Sharp 029 128 143 177 191 Marantz 049 098 200 201 You can operate connected AV products (DVD player/ Magnum Matsui recorder, SetTopBox, VCR and others) by setting up... - Page 53 077 087 090 092 093 095 100 Blue Sky 051 059 Inno Hit 021 052 054 055 058 061 067 104 108 110 136 149 150 153 Sharp 029 (DVD)/028 032 (VCR) Bondstec 052 055 058 Bush 087 (DVD)/036 (VCR)
- Page 54 Appendix Manufacturer Code Satellite Manufacturer Code Satellite Manufacturer Code Satellite Manufacturer Code Sony 003 004 013 022 027 044 066 ASLF Eurostar 044 053 055 057 104 001 038 Luxor 050 071 084 156 168 288 305 068 082 083 084 085 088 094 082 288 001 114 Eutelsat 306 313 331 001 111...
- Page 55 Appendix Satellite Manufacturer Code Satellite Manufacturer Code Satellite Manufacturer Code Cable Box Manufacturer Code Filmnet Telasat 044 052 053 157 001 135 Finnsat 043 119 Quadral 049 056 066 080 086 088 094 Tele Piu France Satellite/TV 125 Filmnet Cablecrypt 353 369 096 161 311 341 342 343 344 Teleciel Galaxi...
-
Page 56: Troubleshooting
The copyrights for the software components and various relevant documents included with this product that were developed or written by SHARP are owned by SHARP and are protected by the Copyright Act, international treaties, and other relevant laws. This product also makes use of freely distributed software and software components whose copyrights are held by third parties. -
Page 57: Updating Your Tv Via Dvb-T
Updating your TV via DVB-T Information Receiver Report Ensure that your TV software version is always up to date. From time to time SHARP will make updated TV base software and DVB software available. Display reports regarding failures and changes for timer settings. -
Page 58: Identification
Appendix The TV displays a confirmation screen while Updating your TV via USB checking the data in the inserted USB device. Setup Software Update This function allows you to update to the latest software using a USB device. Checking You must update the software individually for both the Display and AVC System through the USB terminal located on each. -
Page 59: Specifications
• As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units. -
Page 60: End Of Life Disposal
If the product is used for business purposes and you want to discard it: Please contact your SHARP dealer who will inform you about the take-back of the product. You might be charged for the costs arising from take-back and recycling. Small products (and small amounts) might be taken back by your local collection facilities. -
Page 61: Abbreviation List
Rating table for Child Lock Broadcasted rating User- adjusted rating ✔ Universal viewing — — — — — — — — — — — — — — ✔ ✔ ✔ ✔ ✔ Parental approval pref. — — — — — —... - Page 62 Memo...
- Page 63 ( 1429,0 ) / [ 1156,0 ] 56.6 / 56,6 ( 1312.0 ) / [ 1075.0 ] ( 1312,0 ) / [ 1075,0 ] 60.4 / 60,4 400.0 400,0 ) : LC-65XS1E ] : LC-52XS1E : LC-52XS1E/65XS1E : TU-X1E 318.3 318,3 430.0 328.9 430,0...
-
Page 64: Sharp Corporation
SHARP ELECTRONICS (Europe) GmbH Sonninstraße 3, D-20097 Hamburg SHARP CORPORATION Printed in Japan Gedruckt in Japan Imprimé au Japon Stampato in Giappone Gedrukt in Japan Impreso en Japón Impresso no Japão TINS-D825WJN1 08P12-JA-KG...
