Invacare® Pronto® M91™
Power Wheelchair Base
with SureStep®

User Manual

EN
This manual MUST be given to the user of the product.
BEFORE using this product, read this manual and save for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pronto M91 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Invacare Pronto M91

Summary of Contents for Invacare Pronto M91

  • Page 1: User Manual

    Invacare® Pronto® M91™ Power Wheelchair Base with SureStep® User Manual This manual MUST be given to the user of the product. BEFORE using this product, read this manual and save for future reference.
  • Page 2 © 2011 Invacare Corporation. All rights reserved. Republication, duplication or modification in whole or in part is prohibited without prior written permission from Invacare. Trademarks are identified by ™ and ®. All trademarks are owned by or licensed to Invacare Corporation or its subsidiaries unless otherwise noted.

  • Page 3: Table Of Contents

    Accessories Information..........................................16 Powered Seating Systems Only ........................................16 Transport................................................. 17 Repair or Service Information ........................................19 Safety/Handling ..............................................20 A Note to Wheelchair Assistants......................................21 Stability and Balance ............................................22 Coping with Everyday Obstacles........................................ 24 Part No 1143153 Invacare® Pronto® M91™...
  • Page 4 Wheels ................................................38 Driving ................................................39 Weight................................................39 WHEELCHAIR OPERATION Preparing the Joystick for Use .......................................... 40 Operating the Wheelchair..........................................41 Turning the Power On/Off.......................................... 41 Using the Joystick to Drive the Wheelchair.................................... 42 Invacare® Pronto® M91™ Part No 1143153...
  • Page 5 When to Charge Batteries ..........................................55 SPJ+, SPJ+ w/PSS and SPJ+ w/ACC Joysticks................................... 56 CMPJ+ Joystick ............................................... 56 Charging Batteries ............................................... 57 Description and Use of Battery Chargers...................................... 58 On-Board Battery Charger..........................................59 Independent Battery Charger ........................................... 61 Part No 1143153 Invacare® Pronto® M91™...
  • Page 6 Securing the Occupant ............................................72 Wheelchair-Anchored Belts........................................72 Vehicle-Anchored Belts..........................................74 Seating System ..............................................74 Positioning Belts ............................................. 75 SETUP/MAINTENANCE Setup/Delivery Inspection ..........................................77 User/Attendant Inspection Checklists ......................................78 Inspect/Adjust Weekly..........................................78 Inspect/Adjust Monthly..........................................78 Inspect/Adjust Periodically........................................... 79 Invacare® Pronto® M91™ Part No 1143153...
  • Page 7 Removing/Installing the Footboard Assembly ....................................96 Removing ................................................. 97 Installing................................................97 Adjusting the Footboard Assembly........................................98 Angle ................................................. 98 Depth................................................99 Replacing Front/Rear Caster Assemblies................................100 Adjusting Forks ........................................101 Repositioning Joystick ............................................102 Adjustable ASBA ............................................102 Van Seat................................................103 Part No 1143153 Invacare® Pronto® M91™...
  • Page 8 CONTENTS Disconnecting/Connecting the Joysticks ......................................104 SPJ+ Joysticks ..............................................104 MPJ+ Joysticks...............................................105 TROUBLESHOOTING Driving Performance ............................................106 Electrical................................................106 SPJ+, SPJ+ w/PSS or SPJ+ w/ACC Joysticks...................................106 CMPJ+, PSR+, PSF+ Joysticks or Displays....................................109 Checking Battery Charge Level ........................................112 Invacare® Pronto® M91™ Part No 1143153...

  • Page 9: General

    Caution indicates a potentially hazardous situation which, if not avoided, may result in property damage or minor injury or both. IMPORTANT Indicates a hazardous situation that could result in damage to property if it is not avoided.  Gives useful tips, recommendations and information for efficient, trouble-free use. Part No 1143153 Invacare® Pronto® M91™...

  • Page 10: Reference Documents

    Refer to the table below for part numbers of additional documents which are referenced in this manual. MANUAL PART NUMBER MK6i™ Electronics Programming Guide 1141471 Adjustable ASBA Owner’s Manual 1143192 Van Seat Owner’s Manual 1143195 Formula™ CG Seating System 1143155 Adjustable ASBA Service Manual 1143238 M91 and M94™Service Manual 1125038 Invacare® Pronto® M91™ Part No 1143153...

  • Page 11: Global Limited Warranty (Excluding Canada)

    This warranty gives you specific legal rights and you may also have other legal rights which vary from state to state. Invacare warrants the base frame to be free from defects in materials and workmanship for a period of five (5) years from the date of purchase from Invacare or a dealer, with a copy of the seller’s invoice required for coverage under this warranty.
  • Page 12 INVACARE, OR TO A PRODUCT DAMAGED BY CIRCUMSTANCES BEYOND INVACARE'S CONTROL, AND SUCH EVALUATION WILL BE SOLELY DETERMINED BY INVACARE. THE WARRANTY SHALL NOT APPLY TO PROBLEMS ARISING FROM NORMAL WEAR AND TEAR OR FAILURE TO ADHERE TO THE PRODUCT INSTRUCTIONS. A CHANGE IN OPERATING NOISE, PARTICULARLY RELATIVE TO MOTORS AND GEARBOXES DOES NOT CONSTITUTE A FAILURE OR DEFECT AND WILL NOT BE REPAIRED;...

  • Page 13: Canada Limited Warranty

    (excluding batteries), powered seating actuators, 2-pole motors and gearboxes to be free from defects in materials and workmanship for a period of two (2) years from the date of purchase from Invacare or a dealer, with a copy of the seller’s invoice required for coverage under this warranty.
  • Page 14 INVACARE, OR TO A PRODUCT DAMAGED BY CIRCUMSTANCES BEYOND INVACARE'S CONTROL, AND SUCH EVALUATION WILL BE SOLELY DETERMINED BY INVACARE. THE WARRANTY SHALL NOT APPLY TO PROBLEMS ARISING FROM NORMAL WEAR AND TEAR OR FAILURE TO ADHERE TO THE PRODUCT INSTRUCTIONS. A CHANGE IN OPERATING NOISE, PARTICULARLY RELATIVE TO MOTORS AND GEARBOXES DOES NOT CONSTITUTE A FAILURE OR DEFECT AND WILL NOT BE REPAIRED;...

  • Page 15: Safety

    NOTICE THE INFORMATION CONTAINED IN THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. Check all parts for shipping damage and test before using. In case of damage, DO NOT use. Contact Invacare/Carrier for further instruction. As a manufacturer of wheelchairs, Invacare endeavors to supply a wide variety of wheelchairs to meet many needs of the end user.

  • Page 16: Operation Information

    If there is a procedure or adjustment that needs to be performed on the seating system that is not in this manual, DO NOT perform that procedure. Have the seating system serviced by a qualified technician. Invacare® Pronto® M91™ Part No 1143153...

  • Page 17: Transport

    As of this date, the Department of Transportation has not approved any tie-down systems for transportation of a user while in a wheelchair, in a moving vehicle of any type. It is Invacare’s position that users of wheelchairs should be transferred into appropriate seating in vehicles for transportation and use be made of the restraints made available by the auto industry.
  • Page 18 Extreme caution is advised when it is necessary to move an unoccupied power wheelchair up or down the stairs. Invacare recommends using two assistants and making thorough preparations. Make sure to use ONLY secure, non-detachable parts for hand-hold supports.

  • Page 19: Repair Or Service Information

    (2) the service manual (if applicable) and (3) the seating system’s manual (if applicable). if you are unable to understand the warnings, cautions and instructions, contact Invacare technical support before attempting to service or operate this equipment - otherwise, injury or damage may result.

  • Page 20: Safety/Handling

    Individual wheelchair users often develop skills to deal with daily living activities that may differ from those described in this manual. Invacare recognizes and encourages each individual to try what works best for him/her in overcoming architectural obstacles that they may encounter. However all warnings and cautions given in this manual MUST be followed.

  • Page 21: A Note To Wheelchair Assistants

    Also, be aware of detachable parts such as arms or legrests. These must NEVER be used to move the wheelchair or as lifting supports, as they may be inadvertently released, resulting in possible injury to the user and/or assistant(s). When learning a new assistance technique, have an experienced assistant help you before attempting it alone. Part No 1143153 Invacare® Pronto® M91™...

  • Page 22: Stability And Balance

    The drive behavior initially experienced by the user may be different from other wheelchairs previously used. This wheelchair has Invacare’s SureStep technology, a feature that provides the wheelchair with optimum traction and stability when driving forward over transitions and thresholds of up to 3 inches. The following warnings apply specifically to the SureStep Feature.
  • Page 23 DO NOT move beyond the center of gravity. DO NOT lean forward out of the wheelchair any further than the length of the armrests. Part No 1143153 Invacare® Pronto® M91™...

  • Page 24: Coping With Everyday Obstacles

     For this procedure, refer to FIGURE 1. Do not go down a ramp at full speed. Some seat/ Bump/ back positions will cause the wheelchair to feel Threshold unstable. FIGURE 1 Coping with Everyday Obstacles Invacare® Pronto® M91™ Part No 1143153...

  • Page 25: Pinch Points

    FIGURE 3. WARNING: Pinch point may occur when adjusting the arm angle position (Detail “A”). Pinch point may occur when rotating the footboard assembly (Detail “B”). DETAIL “A” DETAIL “B” Pinch Point Pinch Point FIGURE 3 Part No 1143153 Invacare® Pronto® M91™...

  • Page 26: Footplates And Front Rigging

    Make sure detent balls of the quick-release pin are fully released before operating the wheelchair. Keep detent balls clean. Invacare® Pronto® M91™ Part No 1143153...

  • Page 27: Reaching, Leaning And Bending - Forward

    For this procedure, refer to FIGURE 4. FIGURE 4 Reaching, Leaning and Bending - Forward Engage motor locks and turn power off before reaching, leaning or bending only as far as your arm will extend without changing your sitting position. Part No 1143153 Invacare® Pronto® M91™...

  • Page 28: Reaching, Bending - Backward

    Reach back only FIGURE 5 Reaching, Bending - Backward as far as your arm will extend without changing your sitting position. Invacare® Pronto® M91™ Part No 1143153...

  • Page 29: Transferring To And From Other Seats

    Shift body weight into seat with transfer. FIGURE 6 Transferring To and From Other Seats  During independent transfer, little or no seat platform will be beneath you. Use a transfer board if at all possible. Part No 1143153 Invacare® Pronto® M91™...

  • Page 30: Storage

    Avoid storing or using the wheelchair near open flame or combustible products. Serious injury or damage to property may result. Invacare has tested its power wheelchairs in accordance with ISO 7176 “Rain Test”. This provides the end user or his/her attendant sufficient time to remove his/her power wheelchair from a rain storm and retain wheelchair operation.

  • Page 31: Electrical - Grounding Instructions

    Electrical - Grounding Instructions WARNING DO NOT, under any circumstances, cut or remove the round grounding prong from any plug used with or for Invacare products. Some devices are equipped with three-prong (grounding) plugs for protection against possible shock hazards.

  • Page 32: Electrical - Charging Batteries

    Ensure the pins of the extension cord plug are the same number, size, and shape as those on the charger. DO NOT under any circumstances cut or remove the round grounding plug from the charger AC cable plug or the extension cord plug. Invacare® Pronto® M91™ Part No 1143153...

  • Page 33: Weight Training

    WARNING Invacare DOES NOT recommend the use of its wheelchairs as a weight training apparatus. Invacare wheelchairs have NOT been designed or tested as a seat for any kind of weight training. If occupant uses said wheelchair as a weight training apparatus, INVACARE SHALL NOT BE LIABLE FOR BODILY INJURY AND THE WARRANTY IS VOID.

  • Page 34: Powered Wheelchair Electromagnetic Interference (Emi)

    Electromagnetic interference (EMI) from sources such as radio and TV stations, amateur radio (HAM) transmitters, two-way radios, and cellular phones can affect powered wheelchairs and motorized scooters. FOLLOWING THE WARNINGS LISTED BELOW SHOULD REDUCE THE CHANCE OF UNINTENDED BRAKE RELEASE OR POWERED WHEELCHAIR MOVEMENT WHICH COULD RESULT IN SERIOUS INJURY. Invacare® Pronto® M91™ Part No 1143153...
  • Page 35 2) This device has been tested to a radiated immunity level of 20 volts per meter. 3) The immunity level of the product is unknown. Modification of any kind to the electronics of this scooter as manufactured by Invacare may adversely affect the EMI immunity levels.

  • Page 36: Label Locations

    3 LABEL LOCATIONS 3 Label Locations M91 Standard M91 Heavy Duty Serial Number Label is located on the inside of the right rear frame. Weight Capacity Label located here (Base Only). Invacare® Pronto® M91™ Part No 1143153...
  • Page 37 Auto style seat positioning without TRRO strap shown. This label is also on the airline style seat positioning strap. Wheelchairs with TRRO Also on opposite side of wheelchair. Also on opposite side of wheelchair. Part No 1143153 Invacare® Pronto® M91™...

  • Page 38: Technical Data

    Adjustable ASBA: 22.5 to 23.5 inches (Cushion Not Compressed) Van Seat: 20 - 22 inches (To Seat Pan) Wheels Casters: 6 x 2 inch Front/Rear with Precision Sealed Bearings Drive Wheel: 14 x 3 inch Invacare® Pronto® M91™ Part No 1143153...

  • Page 39: Driving

    260 lbs (w/o Batteries), 310 lbs (w/ Batteries) Battery Weight: 37 lbs Each (Use 22NF Batteries Only) *Maximum Weight Limitation: Up to 300 lbs Up to 400 lbs  Refer to Weight Limitation on page 33. Part No 1143153 Invacare® Pronto® M91™...

  • Page 40: Wheelchair Operation

    Adjustment Lock Slide joystick mounting tube to the desired position. Lever Turn the adjustment lock lever to secure the adjustment lock to the joystick mounting tube. FIGURE 1 Preparing the Joystick for Use Invacare® Pronto® M91™ Part No 1143153...

  • Page 41: Operating The Wheelchair

    Turning the power Off can be achieved by performing one of the following steps: JOYSTICK ACTION CMPJ+ Move the On/Off switch Back to the Off position. FIGURE 2 Turning the Power On/Off SPJ+ Press the On/Off button. Part No 1143153 Invacare® Pronto® M91™...

  • Page 42: Using The Joystick To Drive The Wheelchair

    To drive the wheelchair, perform the following: Adjust speed control knob to the appropriate setting. Turn the power On. Refer to Turning the Power On/Off on page 41. Maneuver the joystick in the following manner: Invacare® Pronto® M91™ Part No 1143153...
  • Page 43 For specific information about the joystick installed on the wheelchair, refer to one of these procedures: • SPJ+, MK6i™ SPJ+ w/PSS and MK6i SPJ+ w/ACC Joystick Switches and Indicators on page 44. • CMPJ+ Joystick Switches and Indicators on page 47. Part No 1143153 Invacare® Pronto® M91™...

  • Page 44: Spj+, Mk6I™ Spj+ W/Pss And Mk6I Spj+ W/Acc Joystick Switches And Indicators

    Service Indicator Powered Seating Switch Charger/ Active Programming (If Programed) Input  *The mode button is only present on SPJ+ w/ACC joystick. FIGURE 4 SPJ+, MK6i™ SPJ+ w/PSS and MK6i SPJ+ w/ACC Joystick Switches and Indicators Invacare® Pronto® M91™ Part No 1143153...

  • Page 45: On/Off Button

    ) to decrease/increase the speed in 20% increments. The larger bars in the speedometer will light. • Press and hold the tortoise button ( ) or hare button ( ) to decrease/increase the speed in smaller increments. The smaller bars in the speedometer will light. Part No 1143153 Invacare® Pronto® M91™...

  • Page 46: Joystick

    Service Indicator The AMBER service indicator will light when an error or fault occurs. Refer to Service Indicator Light Diagnostics on page 108 for a listing of the flash codes and what they indicate. Invacare® Pronto® M91™ Part No 1143153...

  • Page 47: Cmpj+ Joystick Switches And Indicators

    Move the toggle up and release one more time to select DRIVE 1. Speed Control Knob Joystick Remote On/ Programmable Mono Off Input Port 1/2 or External Mode Switch To Controller FIGURE 5 CMPJ+ Joystick Switches and Indicators Part No 1143153 Invacare® Pronto® M91™...

  • Page 48: Speed Control

    This screen is displayed at startup of the joystick for about 2 seconds. This screen displays the software version and date information. FIGURE 6 LCD Display Screens - Splash Screen After this screen, the joystick displays the Main Screen. Invacare® Pronto® M91™ Part No 1143153...

  • Page 49: Lcd Display

    *Drive names can be customized. Actual drive names may display differently.  **No Drive selected via the programmer. BATTERY This symbol shows the Battery Level and will change depending on the available battery power. LEVEL This indicator is shown on every screen. INDICATOR Part No 1143153 Invacare® Pronto® M91™...
  • Page 50 Digital 3 Speed 1 - 3 RIM Mode No Driving Automatic Positioning Powered Seating 4-Switch Level 1 4-Switch Level 2 Drive Select ECU Output Activated ASM 1 (L1, L1 Latched) (L2, L2 Latched) ASM 2 Infrared Mouse Mouse B Invacare® Pronto® M91™ Part No 1143153...
  • Page 51 This screen is shown when the operator issues a drive command and the Drive Icon on the main screen was highlighted.  The Drive’s name, warning/info message, status icon and battery indicator are displayed on this screen. FIGURE 8 LCD Display Screens - Driving Screen Part No 1143153 Invacare® Pronto® M91™...

  • Page 52: User Settings

    FAULT CODES - Displays time and date stamped fault codes. This information can be helpful to a provider prior to making a service call. CONNECTED DEVICES CONNECTED DEVICES - Displays device connections. Refer to Connected Devices Screen on page 53. Invacare® Pronto® M91™ Part No 1143153...
  • Page 53 Micro Extremity Actuator Control Elevate Actuator Control Interface Peachtree Control 4-way Switch Box Generic Tilt Actuator ASL Digital Control Multiple Actuator Generic Recline Control Box Actuator FIGURE 9 LCD Display Screens - Connected Devices Screen Part No 1143153 Invacare® Pronto® M91™...

  • Page 54: Programmable Mono Ports 1 And 2 With External Mode Switch

    (normally open momentary switch with mono plug). To use the remote On/Off feature, the Drive Select/On/Off switch must be in the On position. Each activation of the ability switch will alternately turn the joystick On or Off. Invacare® Pronto® M91™ Part No 1143153...

  • Page 55: Mode Switch

    When to Charge Batteries Keep Batteries charged. When possible, DO NOT allow battery charge to empty.  If battery charge becomes so low that no battery indicators are lit, allow the batteries to charge overnight. Part No 1143153 Invacare® Pronto® M91™...

  • Page 56: Spj+, Spj+ W/Pss And Spj+ W/Acc Joysticks

    Batteries Empty Batteries Full right and moving towards the left a bar at a time until no segments appear. At this level the user should charge the batteries as soon as FIGURE 11 CMPJ+ Joystick possible. Invacare® Pronto® M91™ Part No 1143153...

  • Page 57: Charging Batteries

    DO NOT under any circumstances cut or remove the round grounding plug from the charger AC cable plug or the extension cord plug. CAUTION Always charge new batteries before initial use or battery life will be reduced. Part No 1143153 Invacare® Pronto® M91™...

  • Page 58: Description And Use Of Battery Chargers

    If the batteries need to be charged more often or take longer to charge than normal, they may need to be replaced.  Contact an Invacare dealer for service. The batteries can be charged using the on-board battery charger or by plugging an independent battery charger into the port located on the front of the SPJ-80/DPJ/CMPJ joysticks.

  • Page 59: On-Board Battery Charger

    If the On/Off LED indicator is “Blinking” RED, this is abnormal. Unplug AC power cord from the on-board battery charger and wall outlet. Contact Invacare at the number listed on the back page of this manual. When the On/Off LED indicator light is Off, charger is Off.
  • Page 60 Fully Charges LED “Off” Charger Disconnected Female Connector on AC Power Cord Solid RED or “Blinking” RED Under Voltage, Over Voltage (Connects to AC or Over Temperature Receptacle on Charger) FIGURE 12 On-Board Battery Charger Invacare® Pronto® M91™ Part No 1143153...

  • Page 61: Independent Battery Charger

    It is advantageous to recharge frequently rather (On Back of (On Back of than only when necessary. In fact, a battery’s life is Display) Display) extended if the charge level is maintained well above a low condition. FIGURE 13 Charging Batteries Part No 1143153 Invacare® Pronto® M91™...

  • Page 62: 5.10 Removing/Installing The Seat Assembly

    When reinstalling the seat verify that the seat brackets are engaged with the seat clevis pins by pulling up on the latch bar. Pull up on latch bar to verify that brackets are engaged with seat clevis pins. Connect the joystick. Refer to Disconnecting/Connecting the Joysticks on page 104. Invacare® Pronto® M91™ Part No 1143153...
  • Page 63 5 WHEELCHAIR OPERATION  Van Seat model shown. Adjustable ASBA seat removes/installs in the same way. Rear Pivot Brackets Seat Clevis Pins Latch Bar (located under the front of the seat) FIGURE 14 Removing/Installing the Seat Assembly Part No 1143153 Invacare® Pronto® M91™...

  • Page 64: 5.11 Tilting The Seat Assembly

    Remove the two screws and washers securing the Formula PTO Plus frame to the front seat posts. Firmly grasp the front edge of the seat assembly, slowly tilt the seat assembly back into the up/open position. Invacare® Pronto® M91™ Part No 1143153...

  • Page 65: Tilting The Seat Assembly Forward

    - otherwise injury or damage may result. Insert the two screws through the washers, the Formula PTO Plus frame and the two front seat posts. Prop Rod FIGURE 15 Tilting the Seat Assembly Part No 1143153 Invacare® Pronto® M91™...

  • Page 66: Motor Locks

    Disengage (PUSH) - Move the motor lock levers UP to disengage the motors and push the wheelchair. DETAIL “A” Motor Lock Lever ENGAGE MOTOR (Drive) - Move Motor Lock Lever DOWN DISENGAGE MOTOR (Push) - Move Motor Lock Rear Caster Drive Wheel Lever UP FIGURE 1 Disengaging/Engaging Motor Lock Levers Invacare® Pronto® M91™ Part No 1143153...

  • Page 67: Transport Ready Option (Trro)

    This section applies only to wheelchairs equipped with TRRO (Transport Ready Option). Contact Invacare Corporation (800-333-6900) with any questions about using this wheelchair for seating in a motor vehicle. When feasible, wheelchair occupants should transfer into the vehicle seat and use the OEM (Original Equipment Manufacturer) vehicle-installed restraint system.

  • Page 68: About Transport Ready Packages

    As of this date, the Department of Transportation has not approved any tie-down systems for transportation of a user while in a wheelchair, in a moving vehicle of any type. It is Invacare’s position that users of wheelchairs should be transferred into appropriate seating in vehicles for transportation and use be made of the restraints made available by the auto industry.

  • Page 69: Compliance Information

    Specifications MODEL WEIGHT LIMIT M91 Standard Up to 300 lbs M91 Heavy Duty Up to 400 lbs Part No 1143153 Invacare® Pronto® M91™...

  • Page 70: Positioning The Wheelchair In The Vehicle

    The estimated seated height (HHT) from the ground or floor to the top of the wheelchair-seated occupant’s head ranges from approximately 47-inches for a small adult female to about 61-inches for a tall adult male (Frontal Clear Zone) 16in. 8in. Side View 8in. 16in. (Frontal Clear Zone) Top View Invacare® Pronto® M91™ Part No 1143153...

  • Page 71: Securement Points

    A copy of SAE J2249 Wheelchair Tie-down and Occupant Restraint Systems (WTORS) for use in Motor Vehicles can be  obtained from: SAE International, 400 Commonwealth Drive, Warrendale, PA 15096-0001, (877) 606-7232 or (724) 776-4970. Attach WTORS to the tie-down brackets in accordance with the manufacturer's instructions and SAE J2249. Part No 1143153 Invacare® Pronto® M91™...

  • Page 72: Securing The Occupant

    The wheelchair has been provided with a pelvic belt which meets the requirements of ANSI/RESNA WC/19. The pelvic belt provided by Invacare has been designed to accommodate use on either side of the vehicle. If necessary, follow the instructions below to reverse the orientation of the pelvic belt to accommodate the vehicle-anchored upper torso belt.
  • Page 73 DETAIL “A” - PELVIC BELT DETAIL “B” Back Angle Bracket Belt Mounting Bracket Pelvic Belt Large End of Slot Male End Small End of Slot (Used to secure the vehicle- anchored upper torso belt.) FIGURE 2 Wheelchair-Anchored Belts Part No 1143153 Invacare® Pronto® M91™...

  • Page 74: Vehicle-Anchored Belts

    When feasible, wheelchair occupants should transfer into the vehicle seat and use the OEM (Original Equipment Manufacturer) vehicle-installed restraint system Ensure that the factory installed seating system is secured to the wheelchair frame before operation. Refer to the seating system owner’s manual. Invacare® Pronto® M91™ Part No 1143153...

  • Page 75: Positioning Belts

    Steeper belt angles also reduce the tendency for upper-torso belts to pull the pelvic belt onto the abdomen during frontal impact loading.  For this procedure, refer to FIGURE 4 on page 76. Part No 1143153 Invacare® Pronto® M91™...
  • Page 76 Ensure the belt(s) are not be twisted. Adjust belts as firmly as possible, being mindful of user comfort. DO position belts INSIDE of DO NOT position belts OUTSIDE armrests, wheels, etc. of armrests, wheels, etc. FIGURE 4 Positioning Belts Invacare® Pronto® M91™ Part No 1143153...

  • Page 77: Setup/Maintenance

    Ensure casters are free of debris, and all mounting hardware is secure and not damaged/missing.  Check that cables are routed and secured properly to ensure that cables DO NOT become entangled and damaged during normal operation of  seating system. Part No 1143153 Invacare® Pronto® M91™...

  • Page 78: User/Attendant Inspection Checklists

    Ensure seat release latch is not worn and is functional. Replace if necessary.  Ensure proper operation of powered functions (Example: drive, seating and legrests). Inspect/Adjust Monthly  Clean upholstery and armrests. Clean dirt and lint from axles.  Clean dirt and lint from bearings.  Invacare® Pronto® M91™ Part No 1143153...

  • Page 79: Inspect/Adjust Periodically

     Check front riggings/footboard for loose fasteners. Replace /tighten if necessary. Check that all labels are present and legible. Replace if necessary.  Inspect charger AC power cord for damage. Replace if necessary.  Part No 1143153 Invacare® Pronto® M91™...

  • Page 80: Service Inspection

    Six Month Inspection Clean upholstery and armrests.   Clean dirt and lint from axles. Clean dirt and lint from bearings.  Check that all labels are present and legible. Replace if necessary.  Invacare® Pronto® M91™ Part No 1143153...
  • Page 81 Ensure the anti-tipper wheels are properly installed and located in the proper mounting position.  Ensure wheel locks DO NOT interfere with tires when rolling.   Ensure wheel lock pivot point are free of wear and looseness.  Ensure wheel locks are easy to engage. Part No 1143153 Invacare® Pronto® M91™...

  • Page 82: Inspect/Adjust Every 18 Months

    Inspect foam handgrips for damage. If damaged, have them replaced by a qualified technician.  Ensure swingarm stops are in place and not deteriorated or damaged. Replace if necessary.  Inspect/Adjust Every 18 Months Replace motor brushes and gearbox coupling.  Invacare® Pronto® M91™ Part No 1143153...

  • Page 83: Batteries

    The use of rubber gloves is recommended when working with batteries. Invacare strongly recommends that battery installation and battery replacement always be done by a qualified technician. After ANY adjustments, repair or service and before use, make sure all attaching hardware is tightened securely - otherwise injury or damage may occur.

  • Page 84: Using The Proper Batteries

    For proper battery connection, batteries MUST use post style terminals with mounting holes through the terminal. PROPER BATTERIES TO USE DO NOT USE THIS TYPE OF BATTERY Terminal Mounting Holes POSITIVE (+) NEGATIVE (-) NEGATIVE (-) POSITIVE (+) Battery Terminal/ Battery Battery Terminal/ Battery Post Terminal/Post Post Terminal/Post Invacare® Pronto® M91™ Part No 1143153...

  • Page 85: Installing/Removing The Batteries

    Place the wheelchair in a well ventilated area where work can be performed without risking damage to carpeting or floor covering. Verify the joystick On/Off switch is in the Off position and disconnect joystick cable (not shown). Refer to Disconnecting/Connecting the Joysticks on page 104. Part No 1143153 Invacare® Pronto® M91™...
  • Page 86 If necessary, connect the wiring harness to the two batteries. Refer to Replacing the Batteries and/or Battery Cables on page 90. 10. Reconnect RIGHT and LEFT motor leads to allow access to the FRONT of the battery tray, if disconnected in STEP 5. Invacare® Pronto® M91™ Part No 1143153...
  • Page 87 Wheelchairs without Formula PTO Plus - Reinstall the seat. Refer to Removing/Installing the Seat Assembly on page 62. • Wheelchairs with Formula PTO Plus - Tilt the seat forward. Refer to Tilting the Seat Assembly on page 64. Part No 1143153 Invacare® Pronto® M91™...
  • Page 88 Terminal Mounting Screw, Nut and Fuse Hardware* RED Rear POSITIVE (+) Battery Terminal Mounting Screw, Nut and Fuse Hardware* Rear Battery Rear of wheelchair  Terminal cap shown Retaining Strap removed for clarity. FIGURE 2 Installing/Removing the Batteries Invacare® Pronto® M91™ Part No 1143153...

  • Page 89: Removing The Batteries

    Batteries With Built-in Lifting Strap- Use built in lifting strap to remove the battery from the battery tray (Detail “A” of FIGURE 1). • Batteries Without Built-in Lifting Strap- Use the battery lifting strap to remove the battery from the battery tray (Detail “B” of FIGURE 1). Part No 1143153 Invacare® Pronto® M91™...

  • Page 90: Replacing The Batteries And/Or Battery Cables

    Peel back BLACK battery terminal cover from BLACK battery cable on front battery or GREY battery terminal cover from BLACK battery cable on rear battery. Remove the mounting screws and nuts that secure the POSITIVE (+) RED battery cable to the POSITIVE (+) battery terminal/post as shown in FIGURE 3. Invacare® Pronto® M91™ Part No 1143153...
  • Page 91 NEGATIVE (-) Battery Cable POSITIVE (+) Battery Cable, Mounting Screw with Fuse Hardware NEGATIVE (-) Battery Terminal Tie-Wrap Mounting Screw Locknut Tie-Wrap POSITIVE (+) Battery Battery Terminal FIGURE 3 Replacing the Batteries and/or Battery Cables Part No 1143153 Invacare® Pronto® M91™...

  • Page 92: Connecting Battery Cables

    Verify wiring harness is correctly installed and securely tightened. Verify proper battery orientation. Reposition battery terminal covers over battery post(s). Using new tie-wraps, secure the terminal covers to the battery terminals as shown in FIGURE 3. Invacare® Pronto® M91™ Part No 1143153...

  • Page 93: Replacing The Flat Free Tires On The Wheel Rim

    DO NOT attempt to replace flat free tires. This procedure MUST be performed by a qualified technician. During initial use of the wheelchair, the user may experience flat spots on the wheels. Flat spots will vanish with continued  use of the wheelchair. Part No 1143153 Invacare® Pronto® M91™...

  • Page 94: Removing/Installing The Shrouds

    Wheelchairs with Formula PTO Plus - Tilt the seat forward. Refer to Tilting the Seat Assembly on page 64. • Wheelchairs without Formula PTO Plus - Reinstall the seat. Refer to Removing/Installing the Seat Assembly on page 62. Invacare® Pronto® M91™ Part No 1143153...
  • Page 95 DETAIL “B” - FRONT SHROUD DETAIL “A” - TOP SHROUD Base Frame Top Shroud Hooks Rear of Seat Supports Wheelchair Base Frame Front Shroud Release Knob Front of Hook and Wheelchair Loop Strips FIGURE 4 Removing/Installing the Shrouds Part No 1143153 Invacare® Pronto® M91™...

  • Page 96: 8.10 Removing/Installing The Footboard Assembly

    If the user’s feet are allowed to rest off the side of the footboard they may come in contact with the caster possibly resulting in injury.  For this procedure, refer to FIGURE 5 on page 97. Invacare® Pronto® M91™ Part No 1143153...

  • Page 97: Removing

    Ensure that the detent balls of the quick release pin are fully released and protruding past the outer edge of the tube (Detail “A”). Outer Edge of Tube Detent Balls FIGURE 5 Removing/Installing the Footboard Assembly Part No 1143153 Invacare® Pronto® M91™...

  • Page 98: 8.11 Adjusting The Footboard Assembly

    Thread the jam nut and washer inward until it is flush with the footboard bracket. Securely tighten the jam nut and washer to secure the mounting screw in place. FIGURE 6 Adjusting the Footboard Assembly - Angle Invacare® Pronto® M91™ Part No 1143153...

  • Page 99: Depth

    Install the quick release pin. Make sure the detent balls of the quick release pin are fully released and past the outer edge of the tube (Detail “A”). Outer Edge of Tube Detent Balls FIGURE 7 Adjusting the Footboard Assembly - Depth Part No 1143153 Invacare® Pronto® M91™...

  • Page 100: Replacing Front/Rear Caster Assemblies

    Washer secures the caster to the fork. Caster Remove the caster and discard. Secure new caster to fork with existing mounting screw, two FIGURE 8 Replacing Front/Rear Caster Assemblies washers and locknut (FIGURE 8). Securely tighten. Invacare® Pronto® M91™ Part No 1143153...

  • Page 101: Adjusting Forks

    Test wheelchair for maneuverability. Readjust locknuts if necessary, and repeat STEPS 1-3 until correct. Snap the dust cover into the caster headtube ensuring that the tabs are under the side shroud. FIGURE 9 Adjusting Forks Part No 1143153 Invacare® Pronto® M91™...

  • Page 102: Repositioning Joystick

    Slide the joystick mounting tube through the mounting bracket to the desired position.  Joystick not shown. Turn the adjustment lock lever to secure the joystick mounting tube into the mounting bracket. FIGURE 10 Repositioning Joystick Invacare® Pronto® M91™ Part No 1143153...

  • Page 103: Van Seat

    Locknuts  MK5 SPJ-80 joystick shown, all other joysticks reposition in the same way. Arm Frame Spacers Hex Mounting Screws Joystick Mounting Tube Adjustment Lock Lever Mounting Bracket FIGURE 11 Repositioning Joystick - Van Seat Part No 1143153 Invacare® Pronto® M91™...

  • Page 104: 8.15 Disconnecting/Connecting The Joysticks

    Hold the light GREY collar portion of the joystick connector with one hand and the controller connector on the wheelchair in the other and align them. FIGURE 12 Disconnecting/Connecting the Joysticks - SPJ+ Joysticks Lightly push to engage the joystick connector and the controller connector. Invacare® Pronto® M91™ Part No 1143153...

  • Page 105: Mpj+ Joysticks

    Top and Bottom Connectors - Install connector caps onto the Cable Gasket network connector. Push the latch in to secure the network connectors and caps. If necessary secure excess cable using tie-wraps. Bottom Connector Gasket FIGURE 13 Disconnecting/Connecting the Joysticks - MPJ+ Joysticks Part No 1143153 Invacare® Pronto® M91™...

  • Page 106: Troubleshooting

    The LEDs on the information gauge may flash in a particular pattern or the service indicator light will flash. The number or type of flashes indicates the nature of the error. If multiple errors are found, only the first error encountered by the control module will be displayed. Invacare® Pronto® M91™ Part No 1143153...
  • Page 107 The steady LEDs indicate the current state of ing with steady display. and/or charging mode. the battery charge. All LEDs are flashing slowly. Joystick has detected Out-of- Release the joystick back to Neutral. Neutral-at-Power-Up mode. Part No 1143153 Invacare® Pronto® M91™...
  • Page 108 Check that battery cables are connected properly. If necessary, replace batteries. Refer to Replacing the Batteries and/or Battery Cables on page 90. Left Motor Fault Contact Invacare/Dealer for service. Right Motor Fault Contact Invacare/Dealer for service. Left Park Brake Fault Ensure brake lever is in the drive position before turning on the wheelchair.

  • Page 109: Cmpj+, Psr+, Psf+ Joysticks Or Displays

    Check joystick cable connections. Check joystick cable and connectors for damage. Contact Invacare/Dealer for service. General Fault Contact Invacare/Dealer for service. Incompatible or Wrong type of remote connected. Contact Invacare/Dealer for service. incorrect Remote CMPJ+, PSR+, PSF+ Joysticks or Displays SYMPTOM PROBABLE CAUSE...
  • Page 110 Attendant control is active and can ATTENDANT ACTIVE and displays. be used to drive the chair. Batteries draw excessive current when Battery failure. Have batteries checked for shorted cell. Replace if necessary. charging. Electrical malfunction. Contact Dealer/Invacare for service. Invacare® Pronto® M91™ Part No 1143153...
  • Page 111 Replace batteries if necessary. Refer to Replacing the Batteries and/or Battery Cables on page 90. Motor “chatters” or runs irregular. Motor/gearbox malfunction. Stop use of Wheelchair. Contact Dealer/Invacare for Service. Joystick erratic or does not respond as Damaged motor coupling. Contact Dealer/Invacare for Service.

  • Page 112: Checking Battery Charge Level

    Don’t tap on clamps and terminals with tools. Push battery clamps on the terminals. Spread clamps wider if necessary. Don’t mismatch your battery and chargers. Use ONLY a GEL charger for a GEL battery. Invacare® Pronto® M91™ Part No 1143153...
  • Page 113 9 TROUBLESHOOTING Notes Invacare® Pronto® M91™ Part No 1143153...
  • Page 114 9 TROUBLESHOOTING Notes Invacare® Pronto® M91™ Part No 1143153...
  • Page 115 9 TROUBLESHOOTING Notes Invacare® Pronto® M91™ Part No 1143153...
  • Page 116 Invacare Corporation Canada One Invacare Way 570 Matheson Blvd E Unit 8 Elyria, Ohio USA Mississauga Ontario 44036-2125 L4Z 4G4 Canada 800-333-6900 800-668-5324 Part No 1143153 Rev F - 05/11 www.invacare.com...

Table of Contents
