Invacare Pronto M94 Owner's Manual

With surestep
Hide thumbs Also See for Pronto M94:
Table of Contents

Advertisement

Quick Links

See also: Service Manual , Owner's Manual
Owner's Operator and Maintenance Manual
Pronto
M94
®
™
with SureStep
™
DEALER: This manual MUST be given to
the user of the wheelchair.
USER: BEFORE using this wheelchair, read
this manual and save for future reference.
For more information regarding
Invacare products, parts, and services,
please visit www.invacare.com

Advertisement

Table of Contents
loading

Related Manuals for Invacare Pronto M94

Summary of Contents for Invacare Pronto M94

  • Page 1: Pronto M94

    SureStep ™ DEALER: This manual MUST be given to the user of the wheelchair. USER: BEFORE using this wheelchair, read this manual and save for future reference. For more information regarding Invacare products, parts, and services, please visit www.invacare.com...
  • Page 2 APPLICABLE). IF YOU ARE UNABLE TO UNDERSTAND THE WARNINGS, CUATIONS AND INSTRUCTIONS, CONTACT INVACARE TECHNICAL SUPPORT BEFORE ATTEMPTING TO SERVICE OR OPERATE THIS EQUIPMENT - OTHERWISE, INJURY OR DAMAGE MAY RESULT. NOTE: Updated versions of this manual are available on www.invacare.com. ® ™ Pronto Part No. 1122145...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS REGISTER YOUR PRODUCT ............... 6 SPECIAL NOTES ................9 LABEL LOCATIONS ................. 11 TYPICAL PRODUCT PARAMETERS ..........12 SECTION 1—GENERAL GUIDELINES ..........13 Controller Settings/Repair or Service ....................13 Operation Information ..........................13 Accessories ..............................14 Batteries..............................14 Charging Batteries ..........................15 Grounding Instructions ...........................15 Rain Test..............................16...
  • Page 4 TABLE OF CONTENTS TABLE OF CONTENTS SPJ-80 Joystick Switches and Indicators ....................30 On/Off Toggle Switch .........................30 Speed Control switch .........................30 Joystick..............................30 Battery Gauge Display ........................30 Charger/Programming Input......................31 DPJ Joystick Switches and Indicators ....................31 Drive Select Toggle Switch........................31 Selecting the drive mode 32 Speed Control switch .........................32 Joystick..............................32 Mode (On/Off) Switch ........................32...
  • Page 5 TABLE OF CONTENTS TABLE OF CONTENTS Removing/Installing the Seat Assembly....................41 Removing ...............................41 Installing..............................41 Adjusting the Seat Height ........................42 Adjusting Seat Position on Seat Frame....................43 ASBA Model ............................43 Van Seat Model.............................43 Adjusting Seat Position on Seat Base - Van Seat Only..............44 Replacing the Seat Positioning Strap ....................45 ASBA Model ............................45 Van Seat Model.............................46...

  • Page 6: Register Your Product

    3. Receive updates with product information, maintenance tips, and industry news. 4. Invacare can contact you or your provider, if servicing is needed on your product. 5. It will enable Invacare to improve product designs based on your input and needs.
  • Page 7 ❏ ❏ ❏ ❏ ❏ ❏ ❏ ❏ ❏ ❏ ❏ ❏ ❏ ❏ ❏ ❏ ❏ ❏ ❏ ❏ ❏ ❏ ❏ ❏ ❏ ❏...

  • Page 9: Special Notes

    CHANGE WITHOUT NOTICE. WHEELCHAIR USER As a manufacturer of wheelchairs, Invacare endeavors to supply a wide variety of wheelchairs to meet many needs of the end user. However, final selection of the type of wheelchair to be used by an individual rests solely with the user and his/her healthcare professional capable of making such a selection.
  • Page 10 WARNING The drive behavior initially experienced by the user may be different from other chairs previously used. This Power Wheelchair has Invacare’s SureStep technology, a feature that provides the chair with optimum traction and stability when driving forward over transitions and thresholds of up to 2-inches. The following warnings apply specifically to the SureStep Feature.

  • Page 11: Label Locations

    LABEL LOCATIONS LABEL LOCATIONS ® ™ Part No. 1122145 Pronto...

  • Page 12: Typical Product Parameters

    TYPICAL PRODUCT PARAMETERS TYPICAL PRODUCT PARAMETERS 18-INCH 20-INCH 22-INCH 24-INCH ASBA SEAT VAN SEAT VAN SEAT VAN SEAT VAN SEAT SEAT WIDTH RANGE: 18 inches 20 inches 22 inches 24 inches 18-24 inches SEAT DEPTH: 16 -18 inches 18-20 inches 20-22 inches 20-22 inches 16-22 inches...

  • Page 13: Section 1-General Guidelines

    SECTION 1—GENERAL GUIDELINES SECTION 1—GENERAL GUIDELINES WARNING SECTION 1 - GENERAL GUIDELINES contains important information for the safe operation and use of this product. DO NOT use this product or any available optional equipment without first completely reading and understanding these instructions and any additional instructional material such as Owner’s Manuals, Service Manuals or Instruction Sheets supplied with this product or optional equipment.

  • Page 14: Accessories

    BATTERIES The warranty and performance specifications contained in this manual are based on the use of deep cycle gel cell or sealed lead acid batteries. Invacare strongly recommends their use as the power source for this unit. Carefully read battery/battery charger information prior to installing, servicing or operating your wheelchair.

  • Page 15: Charging Batteries

    DO NOT, under any circumstances, cut or remove the round grounding prong from any plug used with or for Invacare products. Some devices are equipped with three-prong (grounding) plugs for protection against possible shock hazards and fire. Where a two-...

  • Page 16: Rain Test

    Invacare DOES NOT recommend the use of its wheelchairs as a weight training apparatus. Invacare wheelchairs have NOT been designed or tested as a seat for any kind of weight training. If occupant uses said wheelchair as a weight training apparatus, Invacare shall NOT be liable for bodily injury and the warranty is void.

  • Page 17: Section 2-Emi Information

    SECTION 2—EMI INFORMATION SECTION 2—EMI INFORMATION WARNING CAUTION: IT IS VERY IMPORTANT THAT YOU READ THIS INFORMATION REGARDING THE POSSIBLE EFFECTS OF ELECTROMAGNETIC INTERFERENCE ON YOUR POWERED WHEELCHAIR. Electromagnetic Interference (EMI) From Radio Wave Sources Powered wheelchairs and motorized scooters (in this text, both will be referred to as powered wheelchairs) may be susceptible to electromagnetic interference (EMI), which is interfering electromagnetic energy (EM) emitted from sources such as radio stations, TV stations, amateur radio (HAM) transmitters, two way radios, and...
  • Page 18 20 V/m, the maximum immunity level of the product is unknown. Modification of any kind to the electronics of this wheelchair as manufactured by Invacare may adversely affect the RFI immunity levels. ® ™...

  • Page 19: Section 3-Safety/Handling Of Wheelchairs

    Individual wheelchair users often develop skills to deal with daily living activities that may differ from those described in this manual. Invacare recognizes and encourages each individual to try what works best for him/her in overcoming architectural obstacles that they may encounter, however ALL WARNINGS and CAUTIONS given in this manual MUST be followed.

  • Page 20: A Note To Wheelchair Assistants

    SECTION 3—SAFETY/HANDLING OF WHEELCHAIRS While the walking beam allows to traverse up to a 2-inch bump or threshold, stopping after the wheels cross the bump poses a problem. The chair cannot reverse over the bump at this point. Continue forward and then turn around.
  • Page 21 SECTION 3—SAFETY/HANDLING OF WHEELCHAIRS WARNING (CONTINUED) Extreme caution is advised when it is necessary to move an unoccupied power wheelchair up or down the stairs. Invacare recommends using two (2) assistants and making thorough preparations. Use ONLY secure, nondetachable parts for hand-hold supports.

  • Page 22: Transferring To And From Other Seats

    SECTION 3—SAFETY/HANDLING OF WHEELCHAIRS 7. Using non-removable (nondetachable) parts, transfer the seat and any accessories to desired location. 8. Reassemble the wheelchair. WARNING: ESCALATORS DO NOT use an escalator to move a wheelchair between floors. Serious bodily injury may occur. Ensure that driving surface, ramps, lifts, elevators, etc.

  • Page 23: Percentage Of Weight Distribution

    SECTION 3—SAFETY/HANDLING OF WHEELCHAIRS PERCENTAGE OF WEIGHT DISTRIBUTION WARNING DO NOT attempt to reach objects if you have to move forward in the seat or pick them up from the floor by reaching down between your knees. Many activities require the wheelchair user to reach, bend and transfer in and out of the wheelchair.

  • Page 24: Reaching And Bending - Backward

    SECTION 3—SAFETY/HANDLING OF WHEELCHAIRS REACHING AND BENDING - BACKWARD WARNING DO NOT lean over the top of the back upholstery. This will change your center of gravity and may cause you to tip over. NOTE: For this procedure, refer to FIGURE 3.5. Position wheelchair as close as possible to the desired object.

  • Page 25: Section 4-Safety Inspection/Troubleshooting

    SECTION 4—SAFETY INSPECTION/TROUBLESHOOTING SECTION 4—SAFETY INSPECTION/ TROUBLESHOOTING NOTE: Every six (6) months or as necessary take your wheelchair to a qualified dealer for a thorough inspection and servicing. Regular cleaning will reveal loose or worn parts and enhance the smooth operation of your wheelchair. To operate properly and safely, your wheelchair must be cared for just like any other vehicle.

  • Page 26: Inspect/Adjust Weekly

    SECTION 4—SAFETY INSPECTION/TROUBLESHOOTING INSPECT/ADJUST WEEKLY ❑ Seat is secured to wheelchair frame. ❑ Seat and/or back upholstery have no rips and do not sag. Replace if necessary. ❑ Seat release latch is not worn and is functional. Replace if necessary. ❑...

  • Page 27: Troubleshooting Guide

    Battery failure. Have batteries checked for shorted cell. Replace if current when charging. necessary. Electrical malfunction. Contact Dealer/Invacare for service. Battery indicator flashes Battery failure. Check batteries for shorted cell. Replace if neces- the charge level is low - sary.

  • Page 28: Section 5-Wheelchair Operation

    SECTION 5—WHEELCHAIR OPERATION SECTION 5—WHEELCHAIR OPERATION WARNING After ANY adjustments, repair or service and BEFORE use, make sure that all attaching hardware is tightened securely - otherwise injury or damage may result. Set-up/programming of the Electronic Control Unit is to be performed ONLY by a qualified technician.

  • Page 29: Using The Joystick To Drive The Chair

    SECTION 5—WHEELCHAIR OPERATION USING THE JOYSTICK TO DRIVE THE CHAIR The joystick is located at the front of the joystick housing and provides smooth control of speed and direction. It is equipped with 360 degrees of mobility for ease of operation. The joystick is spring-loaded, and automatically returns to the upright (neutral) position when released.

  • Page 30: Spj-80 Joystick Switches And Indicators

    SECTION 5—WHEELCHAIR OPERATION NOTE: For specific information about the joystick installed on the wheelchair, refer to one (1) of these procedures: • SPJ-80 Joystick Switches and Indicators on page 30. • DPJ Joystick Switches and Indicators on page 31. • MPJ Joystick Switches and Indicators on page 33. SPJ-80 JOYSTICK SWITCHES AND INDICATORS NOTE: Refer to FIGURE 5.2 for the following information.

  • Page 31: Charger/Programming Input

    SECTION 5—WHEELCHAIR OPERATION The BGD also serves as a system diagnostic device when a fault is detected by the control module. A specific number of flashes of the last two RED bars (up to eight (8) flashes) start to flash on and off separated by a pause to indicate the type of fault detected. A chart of the diagnostic indications is given in DIAGNOSTIC CODE of the Electronics Manual, part number 1122140.

  • Page 32: Selecting The Drive Mode

    SECTION 5—WHEELCHAIR OPERATION SELECTING THE DRIVE MODE 1. To select DRIVE 1 mode, move the toggle UP. 2. To select DRIVE 2 mode, move the toggle to the MIDDLE position. SPEED CONTROL SWITCH The speed control switch is located at the back of the joystick housing. 1.

  • Page 33: Mpj Joystick Switches And Indicators

    SECTION 5—WHEELCHAIR OPERATION MPJ JOYSTICK SWITCHES AND INDICATORS NOTE: Refer to FIGURE 5.4 for the following information. NOTE: The MPJ joystick must be used with the MK5 EX controller. On/Off/Drive Select Toggle Switch Joystick Remote On/Off Input Speed Control Switch Optional Drive Select Input Charger/Programming Input To Controller...

  • Page 34: Speed Control

    SECTION 5—WHEELCHAIR OPERATION SPEED CONTROL The speed control switch is located on the side of the joystick housing. 1. Rotate the switch forward to increase the speed of the chair to the programmed max speed. JOYSTICK The joystick provides proportional drive control of speed and direction. LCD DISPLAY The LCD Display is located in front of the joystick and provides information on the status of the chair through a 2 line by 12 character length backlit display.

  • Page 35: Emergency Stop/Reset Switch

    SECTION 5—WHEELCHAIR OPERATION EMERGENCY STOP/RESET SWITCH The emergency stop/reset switch is used to stop the chair and to select the operating mode for the chair. The switch input is located on the control module next to the joystick input. An emergency stop/reset switch is needed whenever any of the following operating modes are programmed: •...

  • Page 36: Section 6-Arms

    SECTION 6—ARMS SECTION 6—ARMS WARNING After ANY adjustments, repair or service and BEFORE use, make sure that all attaching hardware is tightened securely - otherwise injury or damage may result. Before performing any maintenance, adjustment or service verify that ON/OFF switch on the joystick is in the OFF position.

  • Page 37: Removing

    SECTION 6—ARMS REMOVING 1. Unlock flip back armrest by pulling flip back armrest release lever into the UNLOCKED position (FIGURE 6.1). 2. Remove the quick release pin that secures the flip back armrest to the wheelchair frame. 3. Pull UP on the flip back armrest and remove the armrest from the arm sockets. 4.

  • Page 38: Adjusting

    SECTION 6—ARMS ADJUSTING 1. Unlock top of flip back armrest by pulling height adjustment lever into the UP (HORIZONTAL) position. 2. Adjust top of the flip back armrest to the desired height. 3. Lock top of flip back armrest by pushing height adjustment lever into the DOWN (VERTICAL) position.

  • Page 39: Section 7-Seat

    SECTION 7—SEAT SECTION 7—SEAT WARNING After ANY adjustments, repair or service and BEFORE use, make sure that all attaching hardware is tightened securely - otherwise injury or damage may result. Before performing any maintenance, adjustment or service verify that ON/OFF switch on the joystick is in the OFF position.

  • Page 40: Adjustable Seat Back Angle (Asba) Model

    SECTION 7—SEAT ADJUSTABLE SEAT BACK ANGLE (ASBA) MODEL NOTE: For this procedure, refer to FIGURE 7.3. 1. Remove armrests from the wheelchair. Refer to Installing/Removing Flip Back Armrests on page 36. 2. Remove the mounting screw and washer from the top mounting hole of back angle plate and back cane.

  • Page 41: Removing/Installing The Seat Assembly

    SECTION 7—SEAT REMOVING/INSTALLING THE SEAT ASSEMBLY WARNING DO NOT store items under seat - interference with seat latch may result. NOTE: For this procedure, refer to FIGURE 7.4. REMOVING 1. Disconnect the joystick. Refer to Disconnecting/Connecting the MK5 Joysticks on page 71.

  • Page 42: Adjusting The Seat Height

    SECTION 7—SEAT ADJUSTING THE SEAT HEIGHT NOTE: For this procedure, refer to FIGURE 7.5. NOTE: The seat can be adjusted to five (5) height positions in ½-inch increments. 1. Remove the seat. Refer to Removing/Installing the Seat Assembly on page 41. 2.

  • Page 43: Adjusting Seat Position On Seat Frame

    SECTION 7—SEAT 4. Reinstall mounting screw and locknut (FIGURE 7.5). Securely tighten. 5. Repeat STEPS 2-4 for the three (3) remaining adjustable height tubes. WARNING When reinstalling the seat verify that the seat brackets are engaged with the seat clevis pins by pulling UP on the latch bar. 6.

  • Page 44: Adjusting Seat Position On Seat Base - Van Seat Only

    SECTION 7—SEAT 4. Refer to FIGURE 7.7 to determine the correct mounting holes to achieve the desired seat position. 5. Align the seat assembly mounting holes determined in STEP 4 with the seat frame mounting holes determined in STEP 4. 6.

  • Page 45: Replacing The Seat Positioning Strap

    SECTION 7—SEAT 4. Adjust seat assembly to desired position and reinstall the six (6) mounting screws. Securely tighten. 5. Reinstall the seat assembly onto the seat frame. Refer to Adjusting Seat Position on Seat Frame on page 43. 6. Reinstall the seat. Refer to Removing/Installing the Seat Assembly on page 41. REPLACING THE SEAT POSITIONING STRAP ASBA MODEL NOTE: For this procedure, refer to FIGURE 7.9.

  • Page 46: Van Seat Model

    SECTION 7—SEAT VAN SEAT MODEL NOTE: For this procedure, refer to FIGURE 7.10. 1. Remove the two (2) mounting screws and washers that secure the seat positioning straps to the seat frame. 2. Remove the two (2) halves of the seat positioning strap from the rear seat frame. 3.

  • Page 47: Section 8-Footboard Assembly

    SECTION 8—FOOTBOARD ASSEMBLY SECTION 8—FOOTBOARD ASSEMBLY WARNING After ANY adjustments, repair or service and BEFORE use, make sure that all attaching hardware is tightened securely - otherwise injury or damage may result. Before performing any maintenance, adjustment or service verify that ON/OFF switch on the joystick is in the OFF position.

  • Page 48: Adjusting The Footboard Assembly

    SECTION 8—FOOTBOARD ASSEMBLY Wheelchair Frame Mounting DETAIL “A” - BOTTOM VIEW OF FOOTBOARD Hole Quick Release Pin Quick Detent Release Ball Outer Edge Footboard Detent Balls of Tube Assembly FIGURE 8.1 - REMOVING/INSTALLING THE FOOTBOARD ASSEMBLY ADJUSTING THE FOOTBOARD ASSEMBLY ANGLE NOTE: For this procedure, refer to FIGURE 8.2.

  • Page 49: Depth

    SECTION 8—FOOTBOARD ASSEMBLY DEPTH NOTE: For this procedure, refer to FIGURE 8.3. 1. Remove the quick release pin that secures the footboard assembly to the wheelchair frame. WARNING Make sure the detent balls are engaged with the outer edge of the tube - otherwise, injury and/or damage may result.

  • Page 50: Section 9-Front Riggings

    SECTION 9—FRONT RIGGINGS SECTION 9—FRONT RIGGINGS WARNING After ANY adjustments, repair or service and BEFORE use, make sure that all attaching hardware is tightened securely - otherwise injury or damage may result. DO NOT stand on the front riggings, otherwise damage may occur. When getting in or out of the wheelchair, make sure that the footplates on the front riggings are in the upward position or moved out of the way.

  • Page 51: Removing

    SECTION 9—FRONT RIGGINGS REMOVING 1. Push the front rigging release lever INWARD and rotate the footrest OUT. 2. Lift up on front rigging and remove from the wheelchair. 3. Repeat STEPS 1-2 for opposite side of wheelchair. ADJUSTING FOOTREST HEIGHT MODEL PHWH93 NOTE: For this procedure, refer to FIGURE 9.2.

  • Page 52: Replacing Heel Loops

    SECTION 9—FRONT RIGGINGS 3. Securely tighten the lug bolt and locknut that secure the lower footrest to the footrest support. 4. Repeat STEPS 1-3 for the opposite side of the wheelchair footrest, if necessary. REPLACING HEEL LOOPS NOTE: For this procedure, refer to FIGURE 9.4. 1.

  • Page 53: Adjusting/Replacing Telescoping Front Rigging Supports - Van Style Seats

    SECTION 9—FRONT RIGGINGS ADJUSTING/REPLACING TELESCOPING FRONT RIGGING SUPPORTS - VAN STYLE SEATS NOTE: When adjusting the telescoping front rigging support depth, ensure the footplate does not interfere with the caster wheel rotation. NOTE: Telescoping front rigging supports may be extended up to 2-inches from the wheelchair frame in 1-inch increments.
  • Page 54 SECTION 9—FRONT RIGGINGS Not Used Mounting Bolts Inner Mounting Holes Telescoping Front Rigging Support Seat Frame Mounting Spacer Holes Locknuts Hinge Not Used Pins STANDARD POSITION 1-INCH OUT 2-INCHES OUT 18 & 20-Inch 22 & 24-Inch 18 & 20-Inch 22 & 24-Inch 18 &...

  • Page 55: Adjusting/Replacing Telescoping Front Rigging Supports - Asba

    SECTION 9—FRONT RIGGINGS ADJUSTING/REPLACING TELESCOPING FRONT RIGGING SUPPORTS - ASBA NOTE: For this procedure, refer to FIGURE 9.7. 1. Remove the two (2) mounting screws, spacers and locknuts that secure the telescoping front rigging support to the seat frame. 2. Perform one (1) of the following: A.

  • Page 56: Section 10-Shroud/Wheels

    SECTION 10—SHROUD/WHEELS SECTION 10—SHROUD/WHEELS WARNING After ANY adjustments, repair or service and BEFORE use, make sure that all attaching hardware is tightened securely - otherwise injury or damage may result. Before performing any maintenance, adjustment or service verify that ON/OFF switch on the joystick is in the OFF position.

  • Page 57: Installing

    SECTION 10—SHROUD/WHEELS INSTALLING 1. Perform one of the following: A. TOP SHROUD - Position top shroud on to the base frame and gently press down on top shroud to secure the four (4) hook and loop strips that secure the top shroud to the base frame as shown in Detail “A”...

  • Page 58: Replacing Front/Rear Caster Assemblies

    SECTION 10—SHROUD/WHEELS NOTE: For this procedure, refer to FIGURE 10.2. 1. Locate the motor release handles on the motors protruding through the shrouds by the rear springs. 2. Perform one (1) of the following: A. To DISENGAGE the motor release levers - NOTE: This allows the chair to freewheel for pushing if necessary a.

  • Page 59: Adjusting Forks

    SECTION 10—SHROUD/WHEELS 2. Remove the caster and discard. 3. Secure new caster to fork with existing mounting screw, two (2) washers and locknut (FIGURE 10.3). Securely tighten. ADJUSTING FORKS NOTE: For this procedure, refer to FIGURE 10.4. 1. Remove the dust cover. 2.

  • Page 60: Section 11-Batteries

    DO NOT tip the batteries. Keep the batteries in an upright position. Invacare strongly recommends that battery installation and battery replacement always be done by a qualified technician. After ANY adjustments, repair or service and BEFORE use, make sure all attaching hardware is tightened securely - otherwise injury or damage may result.

  • Page 61: Installing/Removing The Batteries

    SECTION 11—BATTERIES INSTALLING/REMOVING THE BATTERIES NOTE: For this procedure, refer to FIGURE 11.1 and FIGURE 11.2. NOTE: Have the following tools available: TOOL COMMENTS Battery Lifting Strap Supplied 1/2-inch (6 pt) Box Wrench Not Supplied 7/16-inch (6pt) Box Wrench Not Supplied 3/8-inch (6pt) Box Wrench Not Supplied Diagonal Cutters...
  • Page 62 SECTION 11—BATTERIES DETAIL “A” - BATTERIES WITH BUILT-IN DETAIL “B” - BATTERIES WITHOUT LIFTING STRAPS BUILT-IN LIFTING STRAPS Built-in Lifting Battery Lifting Straps Straps Rear Battery Front Battery Battery Tray Battery Battery Terminals/Posts FIGURE 11.1 - BATTERIES WITH/WITHOUT LIFTING STRAPS 9.

  • Page 63: Removing

    SECTION 11—BATTERIES REMOVING 1. Place the wheelchair in a well ventilated area where work can be performed without risking damage to carpeting or floor covering. 2. Verify the joystick ON/OFF switch is in the OFF position and disconnect joystick. Refer to Disconnecting/Connecting the MK5 Joysticks on page 71. 3.

  • Page 64: Connecting

    SECTION 11—BATTERIES CONNECTING NOTE: For this procedure, refer to FIGURE 11.3. 1. Peel back battery terminal covers to expose battery clamp on each battery cable as follows: A. RED battery clamp cover from RED battery cable. B. BLACK battery clamp cover from BLACK battery cable on front battery OR GREY battery clamp cover from BLACK battery cable on rear battery.

  • Page 65: Disconnecting

    SECTION 11—BATTERIES DISCONNECTING NOTE: For this procedure, refer to FIGURE 11.3. 1. Remove the existing tie-wraps that secure the battery terminal covers to the battery terminals. 2. Peel back battery terminal covers to expose battery clamp on each battery cable as follows: A.

  • Page 66: Battery Charger Operation

    SECTION 11—BATTERIES Some basic concepts which will help you understand this automatic process are: The amount of electrical current drawn within a given time to charge a battery is called “charge rate”. If, due to usage, the charge stored in the battery is low, the charge rate is high.
  • Page 67 SECTION 11—BATTERIES 3. If the On/Off LED indicator is "Blinking" RED, this is abnormal. Unplug AC power cord from the on-board battery charger and wall outlet. Contact Invacare at the number listed on the back page of this manual. 4. When the On/Off LED indicator light is OFF, charger is OFF.

  • Page 68: Independent Charger

    SECTION 11—BATTERIES INDEPENDENT CHARGER NOTE: The charger port located on the Front of the joystick requires the use of an independent charger. The independent charger is NOT supplied with the wheelchair. NOTE: For this procedure, refer to FIGURE 11.5. WARNING READ and CAREFULLY follow the individual instructions for each charger (supplied or purchased).

  • Page 69: Section 12-Electronics

    SECTION 12—ELECTRONICS SECTION 12—ELECTRONICS WARNING After ANY adjustments, repair or service and BEFORE use, make sure that all attaching hardware is tightened securely - otherwise injury or damage may result. Before performing any maintenance, adjustment or service verify that On/Off switch on the joystick is in the OFF position.

  • Page 70: Van Seat Model

    SECTION 12—ELECTRONICS Mounting Bracket Washer (Threaded Plate) Hex Mounting Arm Tube Screws Joystick Adjustment Lock Lever Mounting NOTE: MK5 SPJ-80 joystick Bracket shown, MK5 DPJ/MPJ Joystick repositions the same. Mounting Tube FIGURE 12.1 - REPOSITIONING THE JOYSTICK - ADJUSTABLE SEAT BACK ANGLE (ASBA) MODEL VAN SEAT MODEL NOTE: Take note of position and orientation of mounting hardware for reinstalling the joystick...

  • Page 71: Disconnecting/Connecting The Mk5 Joysticks

    SECTION 12—ELECTRONICS DISCONNECTING/CONNECTING THE MK5 JOYSTICKS NOTE: For this procedure, refer to FIGURE 12.3. DISCONNECTING 1. Loosen the thumb screws on the joystick connector. 2. Disconnect the joystick connector from the controller connector. CONNECTING 1. Align the joystick connector with the controller connector. 2.

  • Page 72: Programing The Control Module

    SECTION 12—ELECTRONICS PROGRAMING THE CONTROL MODULE WARNING DO NOT attempt to program the control module. This section MUST be per- formed by a qualified technician. NOTE: Connect programmer to multi-function charger port located on front of joystick as shown in FIGURE 12.4. MPJ JOYSTICK SPJ-80 JOYSTICK DPJ JOYSTICK...
  • Page 73 SECTION 12—ELECTRONICS NOTES ® ™ Part No. 1122145 Pronto...
  • Page 74 SECTION 12—ELECTRONICS NOTES ® ™ Pronto Part No. 1122145...

  • Page 75: Limited Warranty

    In the event you do not receive satisfactory warranty service, please write directly to Invacare at the address on the bottom of the back cover. Provide dealer's name address, date of purchase, indicate nature of the defect and, if the product is serialized, indicate the serial number.
  • Page 76 Invacare Corporation Canada One Invacare Way 570 Matheson Blvd E Unit 8 Invacare and Pronto are registered Elyria, Ohio USA Mississaugua Ontario trademarks of Invacare Corporation. 44036-2125 L4Z 4G4 Canada Yes, you can., M94, SureStep, MK5, EX, 800-333-6900 800-668-5324...
