Summary of Contents for VPC SL4
- Page 1 SL4 USER’S MANUAL TABLE OF CONTENTS SECTION 1 RACK/CHAMBER MOUNTING SECTION 2 TABLE TOP MOUNTING SECTION 3 ACCESSORIES SECTION 4 ITA AND RECEIVER ENGAGEMENT SECTION 5 TROUBLESHOOTING SECTION 6 PRECAUTIONARY NOTES 10/16/13 For more information visit vpc.com...
- Page 2 Flat head screwdriver ³/ Allen Wrench Custom Rack Design A custom rack is required for mounting the SL4 Receiver for a rack/chamber application. Determine the number of SL4 receivers that are needed. Determine the vertical spacing of the SL4 receivers. The height and recommended spacing is shown in Figure A.
- Page 3 VIRGINIA PANEL CORPORATION SL4 USER’S MANUAL: SECTION 1 RACK/CHAMBER MOUNTING, CONTINUED CUSTOM CARD GUIDE CUSTOM CARD GUIDE 6.73 12.19 Figure C. Card guides are not included with the receiver. Card Guides should be incorporated into the rack design (Figure C).
-
Page 4: Installation
SL4 USER’S MANUAL: SECTION 1 RACK/CHAMBER MOUNTING, CONTINUED TOOLS REQUIRED Phillips head screwdriver INSTALLATION Slide the SL4 into the desired position. Use the included 10-32 captive mounting hardware to secure the receiver to the rack (Figure E). 10-32 CAPTIVE MOUNTING SCREW Figure E. - Page 5 The SL4 table top receiver is suitable for a variety of testing needs. TOOLS REQUIRED Phillips head screwdriver INSTALLATION The SL4 Table Top version may be mounted to the bench top using the 4 legs with 6-32 tapped holes using the hole pattern shown in Figure A. 255.52 10.06 230.63...
-
Page 6: Optional Installation
Use the provided 4-40 screws to attach the rear cover to the SL4 receiver (Figure A). 4-40 MOUNTING SCREWS TYP. BOTH SIDES Figure A. Rear cover, Part # 310 113 506, is designed to attach to the table top SL4 receiver, Part # 310 125 102. OPTIONAL INSTALLATION Rear covers can be permanently mounted to a tabletop using the dimensions provided in Figure B. - Page 7 Allen wrench INSTALLATION Align the keying pin in the desired location. Place the keying pin in the hexagonal opening in the SL4 receiver (See Figure 1). Secure the keying pin with the 4-40 screw. Secure the other keying pin in the corresponding location in the SL4 ITA (Figure A).
- Page 8 Module positions are shown in Figure A. Modules must be installed such that Pin 1 of each respective mating receiver and ITA module pair are adjacent. VPC recommends that Pin 1 always be positioned to the left in the Receiver and ITA frames.
-
Page 9: Troubleshooting
VIRGINIA PANEL CORPORATION SL4 USER’S MANUAL: SECTION 5 TROUBLESHOOTING ITA Frame is not lined up when in the process of engagement with receiver • This may indicate that the ITA was damaged and is out of alignment or that a Module is not mating with its intended module. -
Page 10: Precautionary Notes
The foremost precautionary step that needs to be taken is to protect the Interface System from damage caused by people (bumping into the receiver/ITA assembly with a box, chair or electronic equipment for example). To prevent this, VPC recommends engaging either the ITA or the receiver protective cover to the receiver when not in use.
