    9025 USER’S MANUAL: SECTION 1 RACK MOUNT INSTALLATION RECEIVER, 9025, 25 MODULE, SINGLE TIER • PART # 310 104 420 The 25 Module Receiver is designed to fit into a standard 19” rack. It is equipped with a locking handle to ensure your contacts are engaged. A standard integrated microswitch (when wired to the test system) shuts off power when the ITA disengages from the Receiver.
  • Page 3 8U HINGED MOUNTING FRAME • PART # 310 113 316 9U HINGED MOUNTING FRAME • PART # 310 113 320 RECEIVER, 9025, 25 MODULE, SINGLE TIER • PART # 310 104 420 The Vertical Hinged Mounting Frame allows the 9025 Receiver to hinge down allowing access to instrumentation and wiring.
  • Page 4 36" SLIDE KIT (FITS 34" – 38" DEEP RACKS [863.6 – 965.2]) • PART # 310 113 500 Slides are used with the 9025 and 9025TR receiver. The receiver includes a mounting bracket kit and hardware. Choose your slide kit based on the distance from rail to rail and verify that the slides will not interfere with the rack enclosure.
  • Page 5 VIRGINIA PANEL CORPORATION 9025 USER’S MANUAL: SECTION 3 SLIDE CONFIGURATION INSTALLATION - 9025TR RECEIVER, 9025TR, 25 MODULE, WITH 20" PLATFORM • PART # 310 104 435 28" SLIDE KIT (FITS 26"– 30" DEEP RACKS [660.4 – 762]) • PART # 310 113 451 30"...
  • Page 6 9025 USER’S MANUAL: SECTION 3 SLIDE CONFIGURATION INSTALLATION - 9025 RECEIVER, 9025, 25 MODULE, WITH SLIDE MOUNTING KIT • PART # 310 104 437 28" SLIDE KIT (FITS 26"– 30" DEEP RACKS [660.4 – 762]) • PART # 310 113 451 30"...
  • Page 7 9025 USER’S MANUAL: SECTION 3 SLIDE CONFIGURATION INSTALLATION - 9025 RECEIVER, 9025, 25 MODULE, WITH SLIDE MOUNTING KIT • PART # 310 104 437 28" SLIDE KIT (FITS 26"– 30" DEEP RACKS [660.4 – 762]) • PART # 310 113 451 30"...

  • Page 8: Installation

    VIRGINIA PANEL CORPORATION 9025 USER’S MANUAL: SECTION 4 INSTRUMENT BRACKET INSTALLATION PART # 310 113 453 The instrument bracket mounts to the inner slide and provides maintenance access to the chassis and the instruments. NOTE: This instrument bracket kit does not work with the 20”...
  • Page 9 VIRGINIA PANEL CORPORATION 9025 USER’S MANUAL: SECTION 4 INSTRUMENT BRACKET INSTALLATION PART # 310 113 453 Reinstall the inner slides. • Slide the left mid-section of the slide all the way out, you will feel it lock into position. • Feed the matching inner slide into position and ensure the inner section rides into place with the roller bearings seated into the groove.
  • Page 10 VIRGINIA PANEL CORPORATION 9025 USER’S MANUAL: SECTION 4 KEYBOARD TRAY KIT INSTALLATION PART # 310 113 439 The Keyboard Tray Kit mounts below the platform on the slide-mounted 9025TR receiver. The kit includes a keyboard with touchpad and 72" long USB connector, keyboard tray, and 12"...
  • Page 11 VIRGINIA PANEL CORPORATION 9025 USER’S MANUAL: SECTION 4 KEYBOARD TRAY KIT INSTALLATION PART # 310 113 439 INSTRUCTIONS BOTTOM VIEW SUPPLIED 8-32 SCREW, LOCKING WASHER, AND NUT Attach the keyboard mounting brackets to the existing platform mounting brackets using with the supplied...
  • Page 12 VIRGINIA PANEL CORPORATION 9025 USER’S MANUAL: SECTION 4 CABLE TRAY INSTALLATION PART # 310 113 424 The cable tray is used for strain relief and cable management. The horizontal and vertical flanges provide tie down options that allow you to bend and route your cables where you want and also present a secure and reliable way to protect your investment.
  • Page 13 VIRGINIA PANEL CORPORATION 9025 USER’S MANUAL: SECTION 4 TABLETOP CONFIGURATION RECEIVER, 9025TR, 25 MODULE • PART # 310 104 436 The 9025TR for tabletop applications is shipped with a rear cover to protect receiver side wiring and a “skirt” to allow sufficient rotation of the handle.

  • Page 14: Removal Instructions

    VIRGINIA PANEL CORPORATION 9025 USER’S MANUAL: SECTION 5 PLATFORM REMOVAL AND INSTALLATION RECEIVER, 9025TR, 25 MODULE, WITH 20” PLATFORM • PART # PART # 310 104 435 The platform is removable to allow easier packing and moving of the instrument rack.
  • Page 15 VIRGINIA PANEL CORPORATION 9025 USER’S MANUAL: SECTION 5 PLATFORM REMOVAL AND INSTALLATION INSTALLATION INSTRUCTIONS 9025TR PLATFORM Remove the zip ties used to secure the slides. PLATFORM BRACKET Attach the platform with brackets to the slides using six 8-32 mounting screws (Figure C).
  • Page 16 VIRGINIA PANEL CORPORATION 9025 USER’S MANUAL: SECTION 6 MICRO-SWITCH REMOVAL AND INSTALLATION PART # 310 113 200 A microswitch is used in the 90 Series/VXI receivers to determine the presence (or absence) of an ITA engaged in the system. It is usually configured so that power to the interface is turned off when there is no ITA present.
  • Page 17 ENCLOSURE, 25 MODULE, HINGED COVER PLATE, 4” DEEP • PART # 410 112 198 ENCLOSURE, 25 MODULE, HINGED COVER PLATE, 8” DEEP • PART # 410 112 273 ITA, 9025, 25 MODULE, SINGLE TIER • PART # 410 104 111 The 9025 Enclosure is available to meet your testing needs. Custom enclosures are also available if the standard one is not applicable to your test system.

  • Page 18: Handle Removal And Repositioning

    VIRGINIA PANEL CORPORATION 9025 USER’S MANUAL: SECTION 8 HANDLE REMOVAL AND REPOSITIONING RECEIVER, 9025TR, 25 MODULE, WITH 20” PLATFORM • PART # 310 104 420 The 9025TR receiver handle requires approximately 90° of counter- clockwise travel for engagement and 90° of clockwise travel for disengagement of the ITA.
  • Page 19 Module positions are shown in Figure A. Modules must be installed such that Pin 1 of each respective mating receiver and ITA module pair are adjacent. VPC recommends that Pin 1 always be positioned to the left in the receiver and ITA frames.

  • Page 20: Troubleshooting

    Inspect the matching of modules -power ITA module to mate with power receiver module, etc. Excessive force is needed to engage the handle • With a typical contact load, approximately 35lbs force is needed to engage the handle. Consult with a VPC application engineer for detailed contact loading information. •...

  • Page 21: Precautionary Notes

    The foremost precautionary step that needs to be taken is to protect the interface system from damage caused by people (bumping into the receiver/ITA assembly with a box, chair or electronic equipment for example). To prevent this, VPC recommends engaging either the ITA or the receiver protective cover to the receiver when not in use.
