S6 USER MANUAL

TABLE OF CONTENTS

SECTION 1 TABLETOP CONFIGURATION
SECTION 9 ITA AND RECEIVER ENGAGEMENT
Please note that any printed or downloaded User Manuals or Procedure Sheets may not reflect the
most current revisions. The information contained in these materials is subject to change.
For the most current information available, visit www.vpc.com.
10/17/19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for VPC S6

Summary of Contents for VPC S6

  • Page 1: Table Of Contents

    SECTION 11 PRECAUTIONARY NOTES Please note that any printed or downloaded User Manuals or Procedure Sheets may not reflect the most current revisions. The information contained in these materials is subject to change. For the most current information available, visit www.vpc.com. 10/17/19...
  • Page 2 Figure A. Locations for drill holes. Attach the S6 receiver to the tabletop with #8-32 screws and washers. Hardware is included with the rear cover, Part # 310 113 431. See Table 1 to determine the proper screw length for your table.
  • Page 3 S6 RECEIVER, WITH PLATFORM, TABLETOP CONFIGURATION PART # 310 122 110 / 310 122 111 TOOLS REQUIRED Drill Hardware Kit, VPC Part # 310 113 446 ( -20 Hardware, Allen Wrench) RECEIVER WITH PLATFORM MOUNTING Prepare the mounting surface using the dimensions provided in Figure A and drill 0.257" [6.53 mm] minimum thru holes.

  • Page 4: Section 2 Tabletop Configuration Accessories

    Use the provided #8-32 screws and washers to attach the rear cover to the S6 receiver (Figure A). Figure A. Rear cover, Part # 310 113 431, is designed to attach to the S6 receiver, Part # 310 122 100.

  • Page 5: Section 3 Slide Configuration

    36” SLIDE KIT (FITS 34” – 38” DEEP RACKS [863.6 - 965.2]) • PART # 310 113 500 Slides can be used with the S6 receiver with 15" or 20" platform (Part # 310 122 101/108). Choose your slide kit based on the distance from rail to rail and verify that the slides will not interfere with the rack enclosure.
  • Page 6 36” SLIDE KIT (FITS 34” – 38” DEEP RACKS [863.6 - 965.2]) • PART # 310 113 500 Remove the rubber feet. Attach the S6 platform to the platform mounting brackets (Figure C). NOTE: If you are installing a cable tray or instrument brackets, do not attach the platform until those accessories are installed.

  • Page 7: Section 4 Slide Configuration Accessories

    Attach the cover to the brackets with the flat head screws. With the extender kit in place, secure the S6 receiver to the mating surface on the extender brackets with #10-32 cap screws. NOTE: The #10-32 cap screws are provided with the S6 receiver.
  • Page 8 Figure B. The slots on the instrument brackets are designed to accept a strap should you want to secure your chassis. For the most current information available, visit www.vpc.com 10/17/19...
  • Page 9 NOTE: The middle section will not go into the outer section until the inner section has been fully installed into the middle section. Tighten the slide mounting screws. MAKE SURE ALL SCREW HEADS HAVE BEEN SECURELY TIGHTENED. ONLY USE 8-32 BUTTON HEAD SCREWS. 10/17/19 For the most current information available, visit www.vpc.com...
  • Page 10 Attach the cable tray to the slides with #8-32 screws as shown in Figure A. Figure A. The angled side of the cable tray should face the S6 receiver, and with shorter slide kits the cable tray will sit below the lip of the instrument brackets.
  • Page 11 KEYBOARD TRAY KIT • PART # 310 113 439 The Keyboard Tray Kit mounts below the 15" platform on the slide-mounted S6 receiver. The kit includes a keyboard with touchpad and 58" long USB connector, keyboard tray, and 12" slides.
  • Page 12 Fully extend the 12" slides and mount the keyboard tray (Figure D). The different hole patterns allow for variations in the overall extension of the keyboard tray. Figure D. The remaining four #8-32 button head screws are used to attach the keyboard tray to the slides. For the most current information available, visit www.vpc.com 10/17/19...

  • Page 13: Section 5 Rack Mount Configuration

    RECEIVER, S6, 6 MODULE • PART # 310 122 100 The S6 receiver is ideal for consolidating multilple test instruments while only occupying 1U of rack space. To mount the S6 receiver to a 19" rack, the rotation blocks must be removed to access the rack mounting holes.

  • Page 14: Section 6 Rack Mount Configuration Accessories

    Do not fully tighten until until the cover plate is attached. Attach the cover to the brackets with the flat head screws. With the extender kit in place, secure the S6 receiver to the S6 receiver mating surface on the extender brackets with #10-32 cap screws.

  • Page 15: Section 7 Ita Enclosures

    ENCLOSURE, S6, 1.75x18x8 • PART # 410 112 701 ENCLOSURE, S6, 4x18x12 • PART # 410 112 703 ENCLOSURE, S6, 1.75x18x8 FOR DISCRETE WIRING • PART # 410 112 702 ENCLOSURE, S6, 4x18x12 FOR DISCRETE WIRING • PART # 410 112 712 The front mounting S6 enclosures are available in varying sizes to meet your needs.

  • Page 16: Section 8 Platform Removal

    S6 receiver with 15" or 20" Platform. TOOLS REQUIRED Allen Wrench Wrench REMOVAL Remove the six mounting brackets screws (Figure A). NOTE: This step is only necessary if the S6 receiver is mounted to the slides. BRACKET MOUNTING SCREWS PLATFORM SECURING SCREWS Figure A.
  • Page 17 Always protect the contacts when the system is not in use. The receiver contacts are protected when either the ITA or receiver protective cover is engaged. VPC recommends use of both receiver and ITA protective covers to avoid potential contact damage.

  • Page 18: Section 10 Troubleshooting

    FORCEFUL ENGAGEMENT OF THE RECEIVER AND THE ITA WILL RESULT IN SERIOUS DAMAGE TO MULTIPLE PARTS OF THE SYSTEM (MODULES, RECEIVER, ITA AND CONTACTS)! 10/17/19 10-1 For the most current information available, visit www.vpc.com...

  • Page 19: Section 11 Precautionary Notes

    The foremost precautionary step that needs to be taken is to protect the interface system from damage caused by people (bumping into the receiver/ITA assembly with a box, chair or electronic equipment for example). To prevent this, VPC recommends engaging either the ITA or the receiver protective cover to the receiver when not in use.
