Please note that any printed or downloaded User Manual may not reflect the most current revisions.
The information contained herein is subject to change.
For the most current information available, visit vpc.com.
9025/ 9025TR USER MANUAL
INDEX
(CLICK TO NAVIGATE TO PAGE)
PAGE
1
PRECAUTIONARY NOTES
2
INSTALLING 9025 RACK MOUNT RECEIVER
3
INSTALLING 9025 WITH VERTICAL HINGED MOUNTING FRAME
4
INSTALLING 9025TR WITH SLIDE KIT
6
INSTALLING 9025 WITH SLIDE KIT
8
SLIDE MOUNT NOTATION REGARDING U HEIGHT
9
INSTALLING INSTRUMENT BRACKET
10
INSTALLING KEYBOARD TRAY
12
INSTALLING CABLE TRAY
13
MOUNTING 9025TR TABLETOP RECEIVER
14
REMOVING 9025TR PLATFORM
15
REINSTALLING 9025TR PLATFORM
16
9025TR HANDLE ROTATION & SIDE CHANGE
17
MICROSWITCH REMOVAL & INSTALLATION
18
ITA ENCLOSURES
19
ITA & RECEIVER ENGAGEMENT
20
TROUBLESHOOTING
07/11/2022
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for VPC 9025
Summary of Contents for VPC 9025
- Page 1 INDEX (CLICK TO NAVIGATE TO PAGE) PAGE PRECAUTIONARY NOTES INSTALLING 9025 RACK MOUNT RECEIVER INSTALLING 9025 WITH VERTICAL HINGED MOUNTING FRAME INSTALLING 9025TR WITH SLIDE KIT INSTALLING 9025 WITH SLIDE KIT SLIDE MOUNT NOTATION REGARDING U HEIGHT INSTALLING INSTRUMENT BRACKET...
-
Page 2: Precautionary Notes
FORCEFUL ENGAGEMENT OF THE ITA AND RECEIVER MAY RESULT IN SERIOUS DAMAGE TO MULTIPLE PARTS OF THE SYSTEM (MODULES, RECEIVER, ITA AND CONTACTS). IN THE EVENT OF OPERATIONAL DIFFICULTIES, A TRAINED VPC TECHNICIAN SHOULD BE NOTIFIED TO AVOID ANY POTENTIAL DAMAGE TO THE SYSTEM FROM IMPROPER HANDLING. -
Page 3: Tools Required
9025 USER MANUAL INSTALLING 9025 RACK MOUNT RECEIVER PART # 310 104 420, 310 104 114, 310 104 331 TOOLS REQUIRED Phillips Head Screwdriver INSTALLATION INSTRUCTIONS Install clip/cage nuts on rack, to correlate with mounting holes and captive screws on receiver. -
Page 4: Installation
9025 USER MANUAL INSTALLING 9025 WITH VERTICAL HINGED MOUNTING FRAME PART # 310 113 316, 310 113 320, 310 104 420, 310 104 331 TOOLS REQUIRED Phillips Head Screwdriver ³/ Allen Wrench 1/4 TURN LATCHES VERTICAL HINGED MOUNTING FRAME INSTALLATION MOUNTING HOLE TYP. -
Page 5: Slide Installation
The smaller inner slides move into the middle section, which should not move. Push receiver until it SLIDE backs against the rack. RELEASE TAB INNER SLIDE Figure C. Remove inner section of slide from assembly. RETURN TO INDEX For more information visit vpc.com 07/11/2022... - Page 6 PANHEAD SCREWS TYP. EACH SIDE Figure F. Secure the receiver to the rack with the captive 10-32 screws, taking care to lift up on the platform slightly to ensure even engagement. RETURN TO INDEX For more information visit vpc.com 07/11/2022...
- Page 7 9025 USER MANUAL INSTALLING 9025 WITH SLIDE KIT PART # 310 104 437, 310 104 498, 310 113 409, 310 113 451, 310 113 500 TOOLS REQUIRED Phillips Head Screwdriver ³/ Allen Wrench DETERMINE SLIDE KIT LENGTH The slide kit should be chosen based on the distance from rail to rail inside the rack.
- Page 8 9025 USER MANUAL INSTALLING 9025 WITH SLIDE KIT (CONT’D) PART # 310 104 437, 310 113 409, 310 113 451, 310 113 500 9025 INSTALLATION Attach each receiver mounting flange to the appropriate slide using the provided (3) 8-32 button head screws, per side. Ensure that the mounting surface portion of the flange is directed toward the outside of the overall assembly (Figure D).
- Page 9 PART # 310 104 363, 310 104 387, 310 104 437 With certain receivers including the 9025/ 9025TR, the slide mechanism protrudes downward slightly into the next U height on both sides of the receiver. Please make any necessary adjustments to U height when planning your test rack layout.
- Page 10 Tighten the slide mounting screws. MAKE SURE ALL MOUNTING SCREWS HAVE BEEN SECURELY TIGHTENED. ONLY USE 8-32 BUTTON HEAD SCREWS. RETURN TO INDEX For more information visit vpc.com 07/11/2022...
-
Page 11: Installing Keyboard Tray
MOUNTING BRACKET, LEFT MOUNTING BRACKET, RIGHT 13.0 [330.2] USB KEYBOARD CONNECTOR. 12 INCH SLIDES 28.4 [721.36] RUBBER GROMMET 12 INCH SLIDE MOVEMENT KEYBOARD WITH TOUCHPAD KEYBOARD TRAY 13.3 [337.82] [30.48] Figure A. RETURN TO INDEX For more information visit vpc.com 07/11/2022... - Page 12 Figure B. Fully extend the keyboard slides to access the mounting holes for the self- locking fasteners. Figure C. The different hole patterns allow for variations in the overall position of the keyboard. RETURN TO INDEX For more information visit vpc.com 07/11/2022...
- Page 13 Attach the cable tray to the inner slides with the provided 8-32 screws (Figure A). The angled side of the cable tray should face the receiver. Figure A. Reinstall the inner slides and cable tray assembly into the rack. Retighten the slide mounting screws. RETURN TO INDEX For more information visit vpc.com 07/11/2022...
-
Page 14: Permanent Mounting
184.15 123.83 7.25 4.88 219.08 8.63 314.33 12.38 11.43 197.76 197.76 37.19 7.79 7.79 1.46 37.19 1.46 Figure A. Receiver without Rear Cover Installed. Figure B. Receiver with Rear Cover Installed. RETURN TO INDEX For more information visit vpc.com 07/11/2022... -
Page 15: Removal Instructions
3 sections of each slide. Figure A. 8-32 x .625" PLATFORM MOUNTING SCREWS Figure B. The 6 mounting screws must be removed from the receiver before the platform can be removed. RETURN TO INDEX For more information visit vpc.com 07/11/2022... - Page 16 10-32 mounting screws. 9025TR PLATFORM PLATFORM BRACKET 8-32 X .50" BRACKET MOUNTING SCREWS TYP. Figure C. The brackets will be securely reinstalled to the slides after the mounting screws are installed. RETURN TO INDEX For more information visit vpc.com 07/11/2022...
- Page 17 Replace the screw and handle washer into the cavity on right side of the receiver. Figure B. Remove handle from standard right side. OFFSET LINK Figure C. Install handle on left side. RETURN TO INDEX For more information visit vpc.com 07/11/2022...
- Page 18 MICROSWITCH REMOVAL AND INSTALLATION PART # 310 113 200 NOTE: A microswitch may be used in VPC receivers to determine the presence (or absence) of an engaged ITA in the system. It is typically configured so that power to the interface is turned off when there is no ITA present.
-
Page 19: Standard Enclosures
• There is no limit to the height of the enclosure. 25.40 1.00 164.85 6.49 9025TR with Standard ITA Enclosure RETURN TO INDEX For more information visit vpc.com 07/11/2022... - Page 20 Modules must be installed so that Pin 1 of each respective mating receiver and ITA module pair are adjacent. VPC recommends that Pin 1 be positioned to the left in the receiver and ITA frames. All ITA modules must match the respective receiver modules. It is crucial for all modules to be installed properly.
-
Page 21: Troubleshooting
• See above troubleshooting steps ITA will not engage with the receiver after attempting above troubleshooting steps. Contact VPC – unauthorized user adjustments to the system will void the warranty. No continuity upon engagement. • When replacing an ITA contact, the mating contact on the receiver side should also be inspected and replaced if necessary.
