Extron electronics System 8/10 Plus User Manual page 2

Toshiba Installation
Toshiba P7300U Projector Configuration
__________ Before changing anything, remove the AC power cord to the System 8/10 P
Config Model
as
Toshiba P7300U
_ RS5 is for RGB switching
delay. See page 3-4 for
more information on switch
functions.
______ Secure the screws on all D connectors.
Extron • System 8/10 P
LUS
Verify that the System 8/10 P
projector. The general setup is explained on page 3-4 and the switch settings for
the projector are repeated below.
1. Use a small screwdriver to remove the access cover from the System 8/10 P
front panel. See bottom of page 3-3. The label on the back of the access cover
also has the configuration information.
to verify that the main power is OFF; also turn the projector power OFF.
2. Set the switches as follows:
Rotary Switches Cable
RS1 RS2 RS3 RS4 J2/J3
0 0 4 A
RS2
RS5 RS2
RS1
3. Use a grease pencil (or other rub-off marker) to mark the space on the label next
to "Toshiba P7300U".
4. Locate the switcher's Address DIP switches on the rear panel, lower right.
Unless this is part of a master/slave system, set #3 and #5 to the up position and
the others down. See illustration to the left.
Use the illustration on the next page to do the following steps.
5. Connect the Comm Adapter's 9-pin male connector to the 9-pin female "Remote
1" connector on the rear panel of the projector.
6. Connect the CC-50' (or CC-100') cable from the 9-pin male connector of the
Comm Adapter to the 15-pin HD "Projector Control" port located on the rear
panel of the System 8/10 P
7. Connect the BNC (RGBS) cables from the System 8/10 P
Toshiba P7300U projector inputs according to the application requirements.
8. Apply Main Power to the System 8/10 P
Main Power LED should light. Apply power to the projector.
9. Return System 8/10 P
• User's Manual • P/N 68-417-01 Rev. A
Configuration and Connections
is already configured for the Toshiba P7300U
LUS
SW15 Settings
1 2 3 4 5 6
J2
-
ON
SW15 DIP Switch
RS1
Configured For:
RS-232
.
LUS
by connecting the power cord. The
LUS
and projector to normal operation.
LUS
LUS
LUS
Comm
7 8 9 10 Adapter
26-471-01
RS3
RS4
RS3 RS4
outputs to the
LUS
Page 1
