Summary of Contents for Daewoo DWD-WD1132

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE WARNIG! For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury, or loss of life IMPORTANT SAFETY INSTRUCTIONS WARNIG! - To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following :...

  • Page 4: Parts And Features

    PARTS AND FEATURES The parts and features of your washer are illustrated on the page. Become familiar with all parts and features before using your washer. NOTE The drawings in the book may vary from your washer model. They are designed to show the different features of all models coverd by this book, So your model may not include all the features.

  • Page 5: Installation Instructions

    INSTALLATION INSTRUCTIONS Removing transit bolts 1. Before operating the washer, 2. Unscrew the 4 bolts with the 3. Close holes with supplied cap remove the transit bolts(4ea) spanner supplied. Keep the 4 holders. along with the rubber. bolts and spanner for future use. #If the bolts are not removed, it #Whenever the appliance is may cause heavy vibration,...

  • Page 6: Connecting Water Supply Hose

    Connecting water supply hose • Water supply pressure must be between 4.5 and 145 PSI (30~1000 kPa). • Do not crossthread when connecting inlet hose to the valve. If the water supply pressure is more than 145 PSI, a pressure reducing device should be installed.

  • Page 7: Positioning The Washer

    Positioning the washer • Installation clearances The location must be large enough to fully open the washer door. • Washer dimensions 31.8" 4" (809cm) (10 cm) [Side view] 40.1 (102cm) 1" 27" 1" (2.5 cm) (2.5 cm) (68.6 cm) [Front view] Level floor •...

  • Page 8: Installation Of Accessories

    INSTALLATION OF ACCESSORIES *Please be sure to read and follow the installation operation manual. (Pedestal Model : P-W151W) CAUTION : When installing the said product, please be sure to let the expert with electrictiy & machine related training and sufficient experiences install it. People's safety is the first priority.

  • Page 9: Operating Your Washer

    OPERATING YOUR WASHER To obtain the best washing results, you must operate your washer properly. This section gives you this important information. Preparing clothes for washing • Close zippers, snaps, and hooks to avoid snagging other • Turn down cuffs and turn synthetic knits inside out to items.
  • Page 10 Loading • Drop items into washer loosely. • Mix large and small items in each load. Items should move easily through wash water for best Load evenly to maintain washer balance. cleaning and wrinkle-free results. An unbalanced load can make the washer vibrate during spin.

  • Page 11: Using The Dispenser

    Designed specially to use only HE(High Efficiency) detergent Your DAEWOO KLASSE washer is designed to use only High Efficiency (HE) detergents. HE detergents are formulated specifically for front load washers and contain suds reducing components. HE detergents make less suds, improve washing and rinsing performance, and help to keep the interior of your DAEWOO KLASSE washer clean.
  • Page 12 2. Main Wash Detergent Compartment 3. Liquid Bleach Compartment • Add measured detergent to this compartment for Main • Add measured liquid chlorine bleach to this wash. Detergent is flushed from the dispenser at the compartment. The bleach will be automatically beginning of the cycle.

  • Page 13: The Function Of Control Panel

    THE FUNCTION OF CONTROL PANEL (DWD-WD1132) Press this switch to turn the power “ON” or “OFF”. Operation and temporary stop is repeated as it is pressed. When you want to change program in operating; Press the “Start / Pause” button ' Select the program that you want to change ' Press the “Start / Pause”...
  • Page 14 If can be used to pre-engaged in for wash 1 hour to 12 hours. use to memorize frequently used program To make a Custom Program. 1. Select a cycle. ('18:88'or'CEP' will be showen by turns) 2. Select Wash/Rinse Temperature, Spin Speed, and Soil Level. 3.

  • Page 15: Washing Program

    WASHING PROGRAM Program Fabric type Proper Temp. Default data Maximum Load Wash: main wash First check whether laundry is White Warm/ Cold Refer to Rinse: 2 machine washable. rating label Spin: Medium (white cotton, linen, towel and soil level : light sheets..) Wash: main wash Machine washable woolens with...
  • Page 16 Delay Extra Extra Rinse Night Program Soak PreWash Wash Wash Rinse +Spin Time White Wool Delicate Permpress Cotton Normal Heavy Duty Bulk Sanitary Speed wash Drun Cleanign...

  • Page 17: Washing Procedure And Selection

    WASHING PROCEDURE AND SELECTION 1. WHITE PROGRAM Put the laundry into the Drum and put the detergent and softerner into the detergent case. Then close the Door. • Put the detergent into the main wash room(I I marking) and prewash room(I marking) in the detergent case.

  • Page 18: Wool Program

    2. WOOL PROGRAM Put the laundry into the Drum and put the detergent and softerner into the detergent case. Then close the Door. • Put the detergent into the main wash room(I I marking) in the detergent case. • Liquid detergent, Softner and Bleach should be below ‘MAX’ level. Press the Power button.

  • Page 19: Delicate Program

    3. DELICATE PROGRAM Put the laundry into the Drum and put the detergent and softerner into the detergent case. Then close the Door. • Put the detergent into the main wash room(I I marking) and prewash room(I marking) in the detergent case. •...
  • Page 20 4. Perm Press PROGRAM Put the laundry into the Drum and put the detergent and softerner into the detergent case. Then close the Door. • Put the detergent into the main wash room(I I marking) and prewash room(I marking) in the detergent case. •...
  • Page 21 5. COTTON PROGRAM Put the laundry into the Drum and put the detergent and softerner into the detergent case. Then close the Door. • Put the detergent into the main wash room(I I marking) and prewash room(I marking) in the detergernt case. •...

  • Page 22: Normal Program

    6. NORMAL PROGRAM Put the laundry into the Drum and put the detergent and softerner into the detergent case. Then close the Door. • Put the detergent into the main wash room(I I marking) and prewash room(I marking) in the detergernt case. •...
  • Page 23 7. HEAVY Duty PROGRAM Put the laundry into the Drum and put the detergent and softerner into the detergent case. Then close the Door. • Put the detergent into the main wash room(I I marking) and prewash room(I marking) in the detergent case. •...
  • Page 24 8. BULKY / LARGE PROGRAM Put the laundry into the Drum and put the detergent and softerner into the detergent case. Then close the Door. • Put the detergent into the main wash room(I I marking) and prewash room(I marking) in the detergernt case.
  • Page 25 9. SANITARY PROGRAM Put the laundry into the Drum and put the detergent and softerner into the detergent case. Then close the Door. • Put the detergent into the main wash room(I I marking) and prewash room(I marking) in the detergernt case. •...
  • Page 26 10. SPEED-WASH PROGRAM Put the laundry into the Drum and put the detergent and softerner into the detergent case. Then close the Door. • Put the detergent into the main wash room(I I marking) in the detergent case. • Liquid detergent, Softner and Bleach should be below ‘MAX’ level. Press the Power button.
  • Page 27 11. DRUM CLEANING PROGRAM Press the Power button. • The LED shows only ‘- --’ signal. Select the ‘DRUM CLEANING’ program using the program selection dial. • If you press ‘Start/Pause’ button aftrer pressing Power button without selecting program, the ‘Cotton’ program is selected as default program. •...

  • Page 28: Delay Wash

    GUIDE FOR OTHER USEFUL PROGRAMS DELAY WASH Put the laundry into the Drum and put the detergent and softerner into the detergent case. Then close the Door. • Put the detergent into the main wash room(I I marking) and prewash room(I marking) in the detergent case.

  • Page 29: Custom Program

    CUSTOM PROGRAM Put the laundry into the Drum and put the detergent and softerner into the detergent case. Then close the Door. • Put the detergent into the main wash room(I I marking) and prewash room(I marking) in the detergent case. •...

  • Page 30: Rinse+Spin

    RINSE+SPIN Put the laundry into the Drum and put softerner into the detergent case. Then close the Door. • Softener should be below ‘MAX’ level. Press the Power button. • The LED shows only ‘- --’ signal. Select the program you want using the program selection dial. •...

  • Page 31: Maintenance

    MAINTENANCE Proper care of your washer can extend its life. This section explains how to care for your washer properly and safely. Cleaning your washer Exterior Interior Wipe up detergent, bleach, and other spills with Clean interior with 250ml of chlorine bleach a soft, damp cloth or sponge as they occur.

  • Page 32: How To Clean The Filter

    HOW TO CLEAN THE FILTER Cleaning the water inlet filter Clean the filter when water leaks from the water inlet. $ Pull the power plug out % Turn off the water & Pull the inlet filter out. ( Remove the dirt from before cleaning it.

  • Page 33: Removing Stains

    REMOVING STAINS Stained, heavily-soiled, or greasy items may need to be prewashed or soaked for best results. Soaking helps remove protein-type stains like blood, milk or grass. Prewashing helps loosen soil before washing. Stain removal rules • Use warm water for soaking or prewashing stained laundry. Hot water can set stains. •...

  • Page 34: Troubleshooting

    TROUBLE SHOOTING Most problems are easily solved if you understand the cause. Check the following list for problem before calling for service. If the error mode such as IE, OE, UE were displayed on the control part, in order to solve these problem, first turn off the power of the washing machine and then turn on the power pressing Power button.

  • Page 35: Specification

    SPECIFICATION MODEL DWD-WD1131 Dimension (inches) 27 x 31.8 x 40.1 (W x D x H) (Door open D : 40.9) Unit Weight (lbm) 198.4(Net) / 227(Gross) Wash capacity 3.29 cu.ft. DOE, 3.8 cu.ft. IEC, 10.4kg Spin Speed (RPM) 1100 rpm max. Operating Water Pressure 4.5~145 PSI (30~1000 kPa) Electrical Spec.
  • Page 36 DAEWOO DRYER LIMITED WARRANTY - USA Your DAEWOO will be will repaired or replaced, at DAEWOO's option, if it proves to be defective in material or workmanship under normal use, during the warranty period ("Warranty Period") set forth below, effective from the date ("Date of Purchase") of original consumer purchase of the product.
  • Page 37 ABOUT THIS MANUAL ABOUT THIS MANUAL VISION CREATIVE, INC. ab cde fgV Fhi jklmGn +,- ./0 45623 67687699:; <=>2? CDE:E; CDEGE;C CDE:E;H!! CDEGE;: CDE:E:C!! CDEGE;G CDEGE9C CDEGE9H CDEGE;LOPQRS 4245 CDE:E;8opqWO:;rS CDE:E;H8opsjitJ CDE:E:C8LuHONvwptJSu;G8tJ CDEGE9C8xiOyz{xp|67687699:988}67687699:;Su ;u:uGuLuFuDu99~;:8tJ CDEGE9H8opsjitJ CDEGE;C8Dr|tJ CDEGE;:8Fru:9r|tJ CDEGE;:8:9r|tJ CDEGE;G8Fru:9r|tJ CDEGE;L8op•€•‚ CDELECD8xiuGuLu9;~9:Osjiƒ„Su:98tJO+,-0S CDEDECL8B…uLu9Gu9Lu9Fu9Du9Ku9Hu;Cu;9u;;u;:u;Lu;Du;Ku;Hu:G8tJ OqW89DrS|+,-0...
