Washing Machine OWNER'S Manual
DWD-WD1352WC/RC/SC, DWD-WD1352WC2/RC2/SC2
Features
■ Economic wash system
With artificial intelligence, the washer uses minimum energy and water by selecting
optimal water level and washing time.
■ Low noise system
The washer minimizes the washing and spinning noises by sensing the
amount of laundry.
■ Child-Lock
The Child-Lock system is adopted to prevent children from pressing any
button to change the program during operation.
CONTENTS
IMPORTANT SAFETY GUIDE.................................................................2
PARTS AND FEATURES .........................................................................3
INSTALLATION INSTRUCTIONS............................................................4
INSTALLATION OF ACCESSORIES.......................................................8
OPERATING YOUR WASHER ................................................................9
USING THE DISPENSER.......................................................................11
THE FUNCTION OF CONTROL PANEL ..............................................13
WASHING PROGRAM ...........................................................................15
WASHING PROCEDURE AND SELECTION.......................................17
GUIDE FOR OTHER USEFUL PROGRAMS .......................................18
MAINTENANCE.......................................................................................21
HOW TO CLEAN THE FILTER ..............................................................22
REMOVING STAINS...............................................................................23
TROUBLE SHOOTING...........................................................................24
SPECIFICATION .....................................................................................25
A NOTE TO YOU
Thank you for buying a DAEWOO appliance.
DAEWOO washers are easy to use, save time, and help you manage your home better.
This manual contains valuable information about how to operate and maintain your washer property and safely.
Please read it carefully.
CONTACT INFORMATION
Website : http://www.e-daewoo.com
Call : 1-877-393-7823(1-877-DWESVC3)
Page
As an E
NERGY
DAEWOO has determined that
this product meets the E
S
® guidelines for energy
TAR
efficiency.
S
® partner,
TAR
NERGY
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Daewoo DWD-WD1352WC
Summary of Contents for Daewoo DWD-WD1352WC
-
Page 1: Table Of Contents
A NOTE TO YOU Thank you for buying a DAEWOO appliance. DAEWOO washers are easy to use, save time, and help you manage your home better. This manual contains valuable information about how to operate and maintain your washer property and safely. -
Page 2: Important Safety Guide
IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE WARNING! For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury, or loss of life IMPORTANT SAFETY INSTRUCTIONS WARNING! - To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following :... -
Page 3: Parts And Features
PARTS AND FEATURES The parts and features of your washer are illustrated on the page. Become familiar with all parts and features before using your washer. NOTE The drawings in the book may vary from your washer model. They are designed to show the different features of all models coverd by this book, So your model may not include all the features. -
Page 4: Installation Instructions
INSTALLATION INSTRUCTIONS Removing transit bolts 1. Before operating the washer, 2. Unscrew the 4 bolts with the 3. Close holes with supplied cap remove the transit bolts(4ea) spanner supplied. Keep the 4 holders. along with the rubber. bolts and spanner for future use. •If the bolts are not removed, it •Whenever the appliance is may cause heavy vibration,... -
Page 5: Electrical Connection
Connecting water supply hose • Water supply pressure must be between 4.5 and 145 PSI (30~1000 kPa). • Do not crossthread when connecting inlet hose to the valve. If the water supply pressure is more than 145 PSI, a pressure reducing device should be installed. -
Page 6: Positioning The Washer
Positioning the washer Installation Clearances Minimum clearances for closet installation • Washer dimensions • Closet installations require a minimum clearance. Sides - 1 in(2.5cm) Rear - 1 in(10.2cm) Top - 32 in(81.3cm) 3" (7.6cm) 48 in. (310 cm 40.1 (102cm) 24 in. -
Page 7: Level Floor
31.8" 1" 1" (80.9cm) (2.5 cm) (2.5 cm) [Side view] Level floor • Allowable slope under entire washer is 1°. • To minimize noise and vibration, the washer MUST be installed on a solidly constructed floor. • Carpeting and soft tile surfaces are not recommended. -
Page 8: Installation Of Accessories
INSTALLATION OF ACCESSORIES *Please be sure to read and follow the installation operation manual. (Pedestal Model : P-W151W) CAUTION : When installing the said product, please be sure to let the expert with electrictiy & machine related training and sufficient experiences install it. People's safety is the first priority. -
Page 9: Operating Your Washer
OPERATING YOUR WASHER To obtain the best washing results, you must operate your washer properly. This section gives you this important information. Preparing clothes for washing • Close zippers, snaps, and hooks to avoid snagging other • Turn down cuffs and turn synthetic knits inside out to items. - Page 10 Loading • Drop items into washer loosely. • Mix large and small items in each load. Items should move easily through wash water for best Load evenly to maintain washer balance. cleaning and wrinkle-free results. An unbalanced load can make the washer vibrate during spin.
-
Page 11: Using The Dispenser
USING THE DISPENSER The automatic dispenser consists of four compartments which hold 1) liquid chlorine bleach, 2) liquid fabric softener, 3) liquid or powdered detergent for prewash and 4) liquid or powdered detergent and color safe bleach for main wash. All laundry products can be added at once in their respective dispenser compartments. - Page 12 3. Liquid Bleach Compartment 2. Main Wash Detergent Compartment • Add measured liquid chlorine bleach to this • Add measured detergent to this compartment for Main compartment. The bleach will be automatically wash. Detergent is flushed from the dispenser at the dispensed at the proper time during the wash cycle.
-
Page 13: The Function Of Control Panel
THE FUNCTION OF CONTROL PANEL Delay Wash Steam Spray Normal Speed Wash Cotton Pre-Wash Baby Care Delicate Steam Gym Shoes Heavy Duty Extra Rinse Drum Cleaning Sanitary Rinse+Spin Night Time Press this switch to turn the power “ON” or “OFF”. Operation and temporary stop is repeated as it is pressed. - Page 14 If can be used to pre-engaged in for wash 1 hour to 12 hours. Delay Wash use to memorize frequently used program To make a Custom Program. 1. Select a cycle. ('18:88'or'CEP' will be showen by turns) 2. Select Wash/Rinse Temperature, Spin Speed, and Soil Level. 3.
-
Page 15: Washing Program
WASHING PROGRAM Program Fabric type Proper Temp. Default data Maximum Load Normal Mixed loads, Work Clothes, Warm / Cold Wash: main wash Refer to Jeans, Shirts. Rinse: 2 rating label Spin: Medium soil level : normal Cotton Cotton, Linen, Towels, Shirts, Warm / Cold Wash: main wash Refer to... - Page 16 Delay Extra Rinse Night Custom Soak PreWash Steam Wash Rinse +Spin Time Program Baby care Delicate Steam Spray Cotton Normal Heavy Duty Gym shoes Sanitary Speed wash Drum Cleaning...
-
Page 17: Washing Procedure And Selection
WASHING PROCEDURE AND SELECTION 1. PROGRAM Put the laundry into the Drum and put the detergent and softerner into the detergent case. Then close the Door. • Put the detergent into the main wash room(I I marking) and prewash room(I marking) in the detergent case. -
Page 18: Guide For Other Useful Programs
GUIDE FOR OTHER USEFUL PROGRAMS DELAY WASH Put the laundry into the Drum and put the detergent and softerner into the detergent case. Then close the Door. • Put the detergent into the main wash room(I I marking) and prewash room(I marking) in the detergent case. - Page 19 CUSTOM PROGRAM Put the laundry into the Drum and put the detergent and softerner into the detergent case. Then close the Door. • Put the detergent into the main wash room(I I marking) and prewash room(I marking) in the detergent case. •...
- Page 20 RINSE+SPIN Put the laundry into the Drum and put softerner into the detergent case. Then close the Door. • Softener should be below ‘MAX’ level. Press the Power button. • The LED shows only ‘- --’ signal. Select the program you want using the program selection dial. •...
-
Page 21: Maintenance
MAINTENANCE Proper care of your washer can extend its life. This section explains how to care for your washer properly and safely. Cleaning your washer Exterior Interior Wipe up detergent, bleach, and other spills with Clean interior with 250ml of chlorine bleach a soft, damp cloth or sponge as they occur. -
Page 22: How To Clean The Filter
HOW TO CLEAN THE FILTER Cleaning the water inlet filter Clean the filter when water leaks from the water inlet. ① Pull the power plug out ② Turn off the water ③ Pull the inlet filter out. ④ Remove the dirt from before cleaning it. -
Page 23: Removing Stains
REMOVING STAINS Stained, heavily-soiled, or greasy items may need to be prewashed or soaked for best results. Soaking helps remove protein-type stains like blood, milk or grass. Prewashing helps loosen soil before washing. Stain removal rules • Use warm water for soaking or prewashing stained laundry. Hot water can set stains. •... -
Page 24: Trouble Shooting
TROUBLE SHOOTING Most problems are easily solved if you understand the cause. Check the following list for problem before calling for service. If the error mode such as IE, OE, UE were displayed on the control part, in order to solve these problem, first turn off the power of the washing machine and then turn on the power pressing Power button. -
Page 25: Specification
SPECIFICATION MODEL DWD-WD1352WC/RC/SC, DWD-WD1352WC2/RC2/SC2 Dimension (inches) 27 x 31.8 x 40.1 (W x D x H) (Door open D : 40.9) Unit Weight (lbm) 198.4(Net) / 227(Gross) Wash capacity 3.8 cu.ft. DOE Spin Speed (RPM) 1300 rpm max. Operating Water Pressure 4.5~145 PSI (30~1000 kPa) - Page 26 DAEWOO WASHER LIMITED WARRANTY Your DAEWOO will be will repaired or replaced, at DAEWOO's option, if it proves to be defective in material or workmanship under normal use, during the warranty period ("Warranty Period") set forth below, effective from the date ("Date of Purchase") of original consumer purchase of the product.
- Page 27 서울 종로구 통의동 6번지 이룸빌딩 4층 담 당 배상일 대리님 브 랜 드 DAEWOO 언 어 영 어 F. MODEL DWD-WD135*S 으로 만듬 B. MODEL DWD-WD1352WC/RC/SC, WD1352WC2/RC2/SC 1차 2차 일 정 3차 4차 5차 인 인 쇄 쇄 제 판 한...
