- Page 1 Service M anual Washing Machine Model: DWD-AF1011 DWD-AF1012 DWD-AF1013...
-
Page 2: Specifications
INLET HOSE DETERGENT CASE POWER CORD CONTROL PANEL DOOR HOSE DRAIN LOWER COVER ADJUSTABLE LEG MODEL DWD-AF1011/AF1012/AF1013 POWER SOURCE A.C 220V/50Hz , A.C 230V/50Hz , A.C 240V/50Hz DiMENSION (WXDXH) 595mm x 540mm x 850mm WEIGHT 64 kg WATER CONSUMPTION 47~59... -
Page 3: Explode View And Parts List
5 . EXPLODE VIEW AND PARTS LIST BOX INLET AS ■ PART NAME PART CODE SPECIFICATION Q'TY REMARK 3612611600 DWD-AF1011,HIPS DWD-AF1011(2) HANDLE CASE 3612611601 ABS + SILVER SPRAY DWD-AF1013 CASE DETERGENT 3611140300 CAP SOFTENER 3610916600 BOX INLET 3610526500 3618103510 COLD ONLY... - Page 4 PANEL FRONT AS (DWD-AF101X SERIES) ■ PART NAME PART CODE SPECIFICATION Q'TY REMARK PANEL FRONT 36142T1700 HIPS DWD-AF1011(2) PANEL F AS 3614285822 ABS, URETHANE COATING DWD-AF1013 BUTTON SELECT 3616639200 DWD-AF1011(2) BUTTON SELECT AS 3613405252 ABS + SILVER SPRAY DWD-AF1013 WINDOW LED...
- Page 5 Detailed Part Code of PCB AS ■ No. PART NAME PART CODE SPECIFICATION Q'TY REMARK PRPSSWC030 AF1011 SERIES, EC OPTION, HOT V/V, BUBBLE OPTION PRPSSWC031 AF1011 SERIES, EC OPTION, COLD V/V, NON BUBBLE OPTION DWD-AF101X'S PCB AS PRPSSWC032 AF1011 SERIES, EC OPTION, COLD V/V, BUBBLE OPTION (1000RPM) PRPSSWC033 AF1011 SERIES, EC OPTION, HOT V/V, NON BUBBLE OPTION EXPLODE VIEW AN D PARTS LIST...
- Page 6 CABINET FRONT AS ■ PART NAME PART CODE SPECIFICATION Q'TY REMARK CABINET F 3610811201 DWD-800W PAINTING DWD-AF1011(2) CABINET FRONT 3610811210 PCM, SGCC 0.8T, SILVER DWD-AF1013 SWITCH DOOR LOCK 3619046800 250V16A, ROLD, BI-METAL SCREW TAPPING 7122401208 T2S TRS 4X12 SUS PLATE HINGE SUPPORT 3614531900 SGCC T1.6...
- Page 7 TUB ASS’Y ■ EXPLODE VIEW AN D PARTS LIST...
- Page 8 PART NAME PART CODE SPECIFICATION Q'TY REMARK BALANCER WEIGHT F L/R 3616106300 FRONT, 6.0kg SPECIAL SCREW(BALANCER) 3616029400 SWCH 8.5X30 GASKET 3612321400 EPDM CLAMP GASKET AS 3611204500 HSWR D=1.8 TUB FRONT 3618821001 FRPP FH7300GM SPECIAL SCREW(TUB) 3616029800 SWCH 6.5X30 FIXTURE HEATER 3612007300 SUS 0.7T 440x45 DRUM SUB AS...
- Page 9 CABINET AS ■ EXPLODE VIEW AN D PARTS LIST...
- Page 10 PART NAME PART CODE SPECIFICATION Q'TY REMARK 3610811101 SGCC(GI), 0.7TX825.7X1630.8, WHITE PAINTIN G DWD-AF1011(2) CABINET 3610811101 SGCC(GI), 0.7TX825.7X1630.8, SILVER PAINTING DWD-AF1013 SPECIAL SCREW 3616029100 M4x12.5, MACHINE FRAME UPPER 3612205800 SGCC T1.2 55X580 SCREW TAPPING 3616029950 TTS"S" HEX F/L 4X8 FRAME TOP-L 3612205600 SGCC T1.6 52x500...
- Page 11 PLATE T AS + PANEL LOWER AS ■ PART NAME PART CODE SPECIFICATION Q'TY REMARK 3614532940 HIPS,AF1011,AF1221,AFD1431 DWD-AF1011(2) PLATE T AS 3614532941 URETHANE,1433 DWD-AF1013 SCREW TAPPING 7122401411 T2S TRS 4x14 MFZN PANEL LOWER 3614282801 HIPS COVER PUMP FILTER 3611425801 HIPS...
-
Page 12: Troubleshooting Guide
9 . TROUBLESHOOTING GUIDE This wahing machine is equipped with automatic safety function which detect and diagnose faults at an early stage and react appropriately. When the machine does not function properly or does not fuction at all, check the following points. Problem Cause Solution... - Page 13 DISPLAY ERROR MESSAGE ■ When mechanical or electrical troubles of the washer are occurred, indicator lights of buttons twinkle simultaneously as follows; Indicator Light twinkling ERROR MESSAGE Start/Pause Intensive wash Rinse+ Rinse hold ● ● PFE(E0), OE, E4 ● ● E5, E6, E7, E8 ●...
- Page 14 MESSAGE ERROR CAUSE SOLUTION The water tap is closed. Open the water tap. The filter of the valve inlet is clogged. Clean the filter of the valve inlet. The valve inlet is an inferior product or broke down. Change the valve inlet. WATER INLET The water level sensor (sensor pressure) is an inferior product Change the water level sensor...
- Page 15 MESSAGE ERROR CAUSE SOLUTION THERMISTOR The heater worked without the water in the tub. Check the water level. WASH OVER- HEATING ERROR The thermistor wash is an inferior product or broke down. Change the thermistor wash. The water temp. is over 45°C in delicate & wool course. WATER TEMP.
- Page 16 1 0 . W IRING DIAGRAM W IRING DIAGRAM...
- Page 17 DAEWOO ELECTRONICS CORP. 1-2, Jeo-dong 1(il)-ga, Jung-gu, Seoul, Korea C.P.O. BOX 8003 SEOUL, KOREA TELEX: DWELEC K28177-8 CABLE: “DAEWOOELEC” S/M No. : PRINTED DATE: Aug. 2010...
-
Page 18: About This Manual
ABOUT THIS MANUAL ABOUT THIS MANUAL vision@ @ creativeL@ @ incN fN@model dMafQPQQOafQPQROafQPQSHsOmI bN@model dwdMafQPQQOafQPQROafQPQSHsOmI RPPXNPYNQP memo@ Z@H SUI PXNPYNQPM SU PXNQRNQYM L@RL@QTL@QUL@QWL@QYL@RQL@RRL@RSL@RTL@RUL RVL@RWL@RXL@RYL@SPL@SQL@SR@ QX PXNQRNRYMQTL@QUL@QWL@RQL@RR@ U QPNPWNRVMRWL@RX@ R QPNPXNQSM R vision telZ WSPMPVVP@faxZ WSPMSWXX...
