Kenmore 650-30643-0 Owner's Manual

Liquid propane gas grill
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Cover
Owner's Manual
Liquid Propane Gas Grill
Sears Model No.:650-30643-0
!
WARNING:
Read this Owner's manual carefully and be
sure your gas grill is properly assembled,
installed and maintained. Failure to follow
these instructions could result in serious injury
and/or property damage. This gas grill is
intended for outdoor use only and is not
intended to be installed in or on recreational
vehicles or boats.
Note to Installer
Leave this Owner's Manual with the customer
after delivery and/or installation.
400
300
500
600
200
100
700
800
Note to Consumer
Leave this Owner's Manual in a convenient
place for future reference and keep receipt as
proof of purchase to validate the warranty.
Customer Service Helpline:
For questions and warranty parts, call helpline
8 AM to 5 PM EST at:
1-800-469-4663
Sears Model No.:650-30643-0
Manufacturer model No: 720-0286
Date: 2006/02/22

Advertisement

Table of Contents
loading

Related Manuals for Kenmore 650-30643-0

Summary of Contents for Kenmore 650-30643-0

  • Page 1 Cover Owner’s Manual Liquid Propane Gas Grill Sears Model No.:650-30643-0 Note to Consumer WARNING: Leave this Owner’s Manual in a convenient Read this Owner’s manual carefully and be place for future reference and keep receipt as sure your gas grill is properly assembled, proof of purchase to validate the warranty.

  • Page 2: Table Of Contents

    Your grill will get very hot. Never lean over the cooking area while using your grill. Do not touch Kenmore Elite Warranty cooking surfaces, grill housing, lid or any other grill parts while the grill is in operation, or until the gas grill has cooked down after use.
  • Page 3 PRECAUTIONS • Never store an LP gas tank indoors. If you store your gas grill in the garage or other indoor A tank of approximately 12 inches in diameter by 18-1/2 location, always disconnect the LP gas tank first inches high is the maximum size LP gas tank to use. You and store it safely outside.

  • Page 4: Pre-Assembly Instructions

    NOTE: The normal flow of gas through the CAUTION: Beware of Flash-back regulator and hose assembly can create a humming noise. A low volume of noise is perfectly normal and will not interfere with operation of the grill. If humming noise is loud CAUTION: Spiders and small insects and excessive you may need to purge air from occasionally spin webs or make nests in the grill...

  • Page 5: Hardware List

    Contents for Hardware Pack (part #643-072) The following table illustrates a breakdown of the hardware pack. It highlights what components are used in the various stages of assembly. ¼” x 15mm Philips Head Screw ¼” x 10mm Philips Head Screw 5/32”...

  • Page 6: Parts Diagram

    Sears Model 30643 Parts Diagram (Manufacturer model #: 720-0286)

  • Page 7: Parts List

    Sears Model 30643 Parts List (Manufacturer model #: 720-0286) PART # DESCRIPTION Q’TY PART # DESCRIPTION Q’TY KEY # KEY # 653-001 Stainless Steel Main Lid 653-038 Lighting Rod 653-002 Temperature Gauge 653-039 Tow el Holder Bracket 653-003 Name Plate 653-040 Tow el Holder Hook 653-004 Heat Gasket 653-041 Condiment Rack...

  • Page 8: Assembly Instructions

    Assembly Instructions Caution: While it is possible for one person to assemble this grill, obtain assistance from another person when handling some of the larger, heavier pieces. 1. Open lid of shipping carton and remove top sheet of cardboard. Lay cardboard sheet on floor Figure 1 and use as a work surface to protect floor and grill parts from scratches.
  • Page 9 Installing Side Burner Installing S Hook 1. Insert valve assembly through side panel right Align 4 S hooks into 4 holes in condiment holder, (Fig. 5-a). Remove 4(four) screws & washers from and close (Fig.10) the “U” brackets on the side burner. (Fig. 5-b). Insert valve stem assembly into burner tube (FIG Installing Side Handle 5-c).
  • Page 10 Installing Condiment Rack Assembly Tips Attach condiment rack to inside door panel. (Fig.12) Ignitor Battery Installation Installing Cooking Components Important: Before cooking on your grill the first time, 1. Unscrew the ignitor cap located on control panel wash cooking grids and cooking rack with warm , and remove the contact and spring from the ignitor soapy water.
  • Page 11 • Ignitor AA battery not installed properly. • Ignitor wires may be loose. Remove AA battery, inspection the ignitor junction box found behind 3 0 0 4 0 0 5 0 0 6 0 0 2 0 0 control panel, and connect any loose wires. 1 0 0 7 0 0 8 0 0...

  • Page 12: Lighting Instructions

    Manually Lighting Your Grill by Match Grill Lighting Instruction 1. Open the doors and take out the manual lighting stick Basic Lighting Procedures from back of right door. (Fig.16) 1. Familiarize yourself with the safety guidelines at the front of this manual. Do not smoke while lighting 2.
  • Page 13 If the grill fails to light: WARNING 1. Turn gas off at source and turn the control knob to Should a “FLASH-BACK” fire occur in/or OFF, wait at least 5 minutes for gas to clear, then try around the burner tubes, follow the again.

  • Page 14: Cleaning And Maintenance

    Cleaning Exterior Stainless Steel Surfaces Cleaning and Maintenance • Weathering and extreme heat can cause To ensure a proper working unit the following exterior stainless steel surfaces to turn tan proper care and maintenance is suggested. in color. Machine oils used in manufacturing process of stainless steel can also cause Cleaning Cooking Grids this tanning color.
  • Page 15 Cleaning and Maintenance Regardless of which burner cleaning procedure you use, we recommend you also complete the following steps to help prolong burner life. 1. Use a fiber pad or nylon brush to clean the entire outer surface of each burner until free of food residue and dirt.

  • Page 16: Trouble Shooting

    TROUBLE SHOOTING SPIDER AND INSECT WARNING!!! Spiders and insects can nest in the burners of this or any other grill, and cause the gas to flow from the front of the burner. This is a very dangerous condition which can cause a fire to occur behind the valve panel, thereby damaging the grill and making it unsafe to operate.

  • Page 17: Getting Started With Your Grill

    Getting Started with Your Grill Cooking Instructions Indirect Cooking WARNING To cook indirectly, the food should be placed on the Do not leave the grill unattended. left or right side of your grill with the burner lit on the Your grill will get very hot. Never lean over opposite side.

  • Page 18: Rotisserie Kit Assembly/Use Instruction

    Rotisserie Kit Assembly and Use Instructions Attaching Rotisserie Bracket to Grill Tool required to assemble the product: Philips screwdriver(not provided) Estimated time for assembly: 5 minutes Fig. 1 1. Using screwdriver to screw (2) 14 x 10mm, attach the bracket to the left side of the grill in the 2 pre-drilled holes.

  • Page 19: Cooking Chart

    GRILL COOKING CHART WEIGHT OR APPROXIMATE SPECIAL INSTRUCTIONS AND FOOD THICKNESS FLAME SIZE TIME TIPS VEGETABLES Slice.Dot with butter or margarine Wrap in heavy-duty foil.Grill,turning occasionally Fresh Beets Medium 12 to 20 minutes Carrots Grill,turning once.Brush Occasionally Turnips With melted butter or margarine Onion 1/2 inch slices Medium...
  • Page 20 GRILL COOKING CHART WEIGHT OR APPROXIMATE SPECIAL INSTRUCTIONS FOOD THICKNESS FLAME SIZE TIME AND TIPS Tenderloin, Porterhouse, T-Bone, Sirloin Remove excess fat from edge. Slash remaining fat at 2-inch intervals. Rare 1 inch High 8 to 14 minutes Grill, turning once. 1-1/2 inch High 11 to 18 minutes...
  • Page 21 GRILL COOKING CHART WEIGHT OR APPROXIMATE SPECIAL INSTRUCTIONS FLAME SIZE FOOD THICKNESS TIME AND TIPS FISH AND SEAFOOD Grill,turning once.Brush with melted butter,margarine or oil Steaks To keep moist. Halibut 3/4 to 1 inch Medium to 8 to 15 minutes Salmon High Swordfish...

  • Page 22: Recipes Suggestions

    GRILL RECIPE SUGGESTIONS BBQ SALMON PORK CHOPS Half hour before cooking, turn the burner to the grill on full. Drain 4 Pork chops 2 large salmon steaks seafood reserving marinade. On Marinade 2 tbs. Oil each of twelve 10” skewers, 1 large onion Salt &...
  • Page 23 GRILL RECIPE SUGGESTIONS Preheat grill. Combine cheese, Pound flank steak to ¼ inch In blender, process 1/3 c. water, condensed soup, milk, BBQ thickness or flatten chicken onion, soy sauce, 2 tsp. oil and sauce, oregano, salt and pepper breasts. Mix oil, lime juice and the next 8 ingredients until in a large mixing bowl.

  • Page 24: Knob 6

    GRILL RECIPE SUGGESTIONS CHICKEN TANDOORI STYLE Marinade ribs for 3 hours. Use TURKEY marinade for basting by adding 8 large chicken thighs or 12 lb. turkey drumsticks beer to it. Place pan under the Beer basting sauce: ribs and baste frequently. To 1 c.

  • Page 25: Ow Ner's Manual

    Back cover Get it fixed, at your home or ours! Just Call: ® 1-800-4-MY-HOME (1-800-469-4663) 24 hours a day, 7 days a week For the repair of major brand appliances in your own home … no matter who made it, no matter who sold it! For your nearest Sears Parts and Service location, to bring in products like vacuums, lawn equipment and electronics.
