PPT Vision C series User Manual page 28

PPT Vision
Mfg. Model
Basler L101K-2K
Cohu 7712
SVS- SVS4021
Vistek MFCP
NOTES: Camera specifications are provided by camera manufacturers. PPT Vision is
not responsible for changes, errors, or omissions. Refer to manufacturer's camera
documentation for current specifications. Only Camera Link cameras listed here are
supported by PPT Vision.
Camera Link cameras use one of these standard cables to connect to the
PPT device (xx is the cable length of 2, 5, or 10 meters):
Straight connector...................... Part # 606-0543-xx
Right angle connector up ........... Part # 606-0544-xx-U
Right angle connector down....... Part # 606-0544-xx-D
Our Part #
(w x h x l)
601-0306 62 x 62 x
38.1mm
601-0302 52.3 x 52 x
78.7 mm
601-0316 50 x 55 x 43
Page 26
Size Weight Resolution
285 g 2048
340 g 1004 x 1003
200 g 2048 x 2048
mm
Speed
(w x h) (fps)
9300
Linescan lines/sec
30
11.5
