Camera Link Cameras

Camera Link is an industry standard connection for digital imaging
equipment. The PPT C-Series conforms to the Camera Link specification
and can use the Camera Link compatible cameras listed here. All cameras
are configured using Impact software (V3.0 or greater).
Mfg. Model
Adimec 1000m
Adimec 1600m
Adimec 2000m
Basler A102K
PPT-9300 Specifications
CCD active pixel sensor with 1600 (H) x 1200 (V)
pixel image.
Type 1/1.8 (8.8 mm diag) – 7.04 mm (H) x 5.28
mm (V)
10.6 full-resolution fps; higher with partial scan
50%
4.4 x .4.4 micrometers
50% to 200%
77 to 161,357 microseconds
C mount
DSL cable provides power, controls, and video.
Maximum length is 25 meters
Temperature: 0°+45° C (+32°∼114° F)
Humidity: 20~80% (non-condensed)
12 VDC provided by link (4 Watts)
0.31 pounds (140 grams); 0.44 pounds (200
grams) with mounting bracket
Impact Software V6.6 or greater
Our Part #
(w x h x l)
601-0304 45 x 45 x
75 mm
601-0307 52.5 x 52.5 x 80
52.5 mm x 52.5
mm x 80 mm
601-0303 62 x 62 x 40.2
Page 25
C-Series Camera Users Guide
Size Weight Resolution
185 g 1004 x 1004
250 g 1600 x 1200
mm
250 g 1980 x 1080
222 g 1392 x 1040
mm
Speed
(w x h) (fps)
30
17
17
14.8
