Dsl-5000 - PPT Vision C series User Manual

PPT Vision
Camera
Imager
Model
Sony
1
7200
ICX204AL
Sony
9200
ECX274AL
1
The 7200 camera has 2.5 times as many pixels as the 5200, so each pixel
is smaller and gathers less light.
2
The color camera models will have the same relative sensitivity to each
other (with the 5300 sensitivity as 1).
3
Super HAD CCDs are twice as sensitive as normal HAD CCDs.

DSL-5000

Note: Reference only. This camera has an older style body. Mounting
dimensions are in the Digital Camera Users Guide (843-0085).
This camera captures a 640 by 480 pixel size image with square pixels. It
can partially scan the image horizontally. In half-resolution mode the
camera scans every other line to acquire the image twice as fast with half
the vertical resolution and twice the gain.
DSL-5000 Spectral Response (excludes lens and light source characteristics)
CCD
Pixel Area
Technology
21 sq um HAD
Super
19 sq um
HAD™ (2x)
Page 8
Relative
2
Sensitivity
21/55 = 0.38
2 * 19/55 = 0.7
3
