Environment
Power
Weight
Software

PPT-5300

This camera captures a 640 by 480 pixel size color image with square
pixels. It can partially scan the image vertically and horizontally.
PPT-5300 Spectral Response (excludes lens and light source characteristics)
Part #
Pick-up Device
Image Size
Capture Rate
Optical Fill
PPT-5200 Specifications
Temperature: -5°+45° C (+23°∼114° F)
Humidity: 20~80% (non-condensed)
12 VDC provided by link (3 Watts)
0.31 pounds (140 grams); 0.44 pounds (200 grams)
with mounting bracket
Impact Software V3.0 or greater
PPT-5300 Specifications
661-0364
Interline Transfer type CCD with 640 (H) x 480 (V)
pixel color image
Type ⅓ (5.92 mm diag) – 4.74 (H) x 3.55 (V) mm
64 fps full-resolution; higher with partial scan
30%
Page 13
C-Series Camera Users Guide
