MQ Power EGC-750C Specifications

Model
EGC-750C
750 KW

Standard Features

Cummins Heavy Duty Diesel Engine
4-cycle design, turbocharged, aftercooled, direct injection
Polymide blade cooling fan
Engine coolant heater
Meets EPA emissions standards for mobile off-highway
Fuel System
1000 gallon, single wall fuel tank
Fuel priming system
Fuel/water separators and drip pan
Electric fuel pump
External fuel fill
®
30 micron Racor fuel filter system
Alternator
Brushless, 4-pole, synchronous, WYE connection
Class H insulation system conforms to NEMA MG1-22, BS5000,
CSA-C22-2, IEC-34-1 standards for temperature rise
Drip-proof, self-venting, amortisseur windings
Epoxy impregnated windings with tropical insulation for increased
environmental protection and long life
Electronic Voltage Regulator
■ Electronic automatic voltage regulator provides precise regulation
■ ■ ■ ■ ■ Separate three-phase excitation for fast recovery from block loads
and motor starting
750kW Containerized
Diesel Generator Set
Emissions
EPA Certified
(Shown with 40 ft. container and optional ISO trailer chassis)
Standby Rating
60 Hertz
750kW (937kVA)
Full Load Acceptance
Accepts 100% of standby nameplate rating in one step, in compliance
with NFPA, para 5-13.2.6
Generator Control Panel
TM
Inteligen vibration-isolated controller
Manual or remote engine start/stop
RS232/Modbus communication support
Safety shutdowns
Externally mounted emergency stop switch
Generator mainline circuit breaker, 100% rated electronically
operated, UL listed
Specially Designed Container
■ 40 ft. ISO container, sound-attenuated, foam-lined for extremely
quiet operation
■ Isolated operator control room
Solidly mounted battery rack and cooling system
Intregral vibration isolators
Exterior polyurethane coating system provides long life in extreme
operating conditions
Interior DC lights and timer switch
Critical grade silencer with heat blankets
Warranty
Engine-generator sets are covered by an express written, one-year
limited warranty
Prime Rating
600kW (750kVA)
