MQ Power EGC-500C Specifications

Model
EGC-500C

Standard Features

Cummins Heavy Duty Diesel Engine
4-cycle design, turbocharged, aftercooled, direct injection
Polymide blade cooling fan
Engine coolant heater
Meets EPA Tier 2 emissions standards
Fuel System
800 gallon, single wall fuel tank
Fuel priming system
Fuel/water separators and drip pan
Electric fuel run pump
External fuel fill
®
30 micron Racor fuel filter system
Alternator
Brushless, 4-pole, synchronous, WYE connection
Class H insulation system conforms to NEMA MG1-22, BS5000,
CSA-C22-2, IEC-34-1 standards for temperature rise
Drip-proof, self-venting, amortisseur windings
Epoxy impregnated windings with tropical insulation for increased
environmental protection and long life
Electronic Voltage Regulator
Electronic automatic voltage regulator provides precise regulation
Separate three-phase excitation for fast recovery from block loads
and motor starting
500kW Containerized
Diesel Generator Set
Emissions
EPA Certified
Standby Rating
60 Hertz
500kW (625kVA)
(Shown with optional ISO trailer chassis)
Full Load Acceptance
Accepts 100% of standby nameplate rating in one step, in compliance
with NFPA, para 5-13.2.6
Generator Control Panel
Basler vibration-isolated controller
Manual or remote engine start/stop
RS485/Modbus communication support
Safety shutdowns
Externally mounted emergency stop switch
Generator mainline circuit breaker, 100% rated, electronically
operated, UL listed
Specially Designed Container
20 ft. ISO container, sound-attenuated, foam-lined for extremely quiet
operation
Solidly mounted battery rack and cooling system
Intregral vibration isolators
Exterior polyurethane coating system provides long life in extreme
operating conditions
Interior DC lights and timer switch
Crankcase filtration system
Critical grade silencer with heat blankets
Warranty
Engine-generator sets are covered by an express written, one-year
limited warranty
Prime Rating
450kW (562.5kVA)
EGC500C Rev 0
