RE-ASSIGNING DEVICE KEYS

The Millennium 4 can be set up to control a second TV
or VCR, or any combination of four home entertainment
components. For example, to have the Millennium 4
control a TV, a Cable Converter, and two VCRs, you will
need to re-assign the unused AUDIO key to operate the
second VCR as follows:
On the Millennium 4, press and hold SETUP
1.
until the LED blinks twice, then release SETUP.
Enter 9 - 9 - 2. The LED will blink twice.
2.
3. Press VCR once, then press AUDIO once.
The AUDIO key is now ready to be programmed
4.
for your second VCR. See Programming VCR
Control on page 12.
To re-assign other device keys, repeat steps 1 through 4 by
substituting the key sequence from the following chart for
a desired component:
To Re-Assign Perform Key Sequence
TV as 2nd VCR key: SETUP - 9 - 9 - 2 - VCR - TV
TV as 2nd Audio key: SETUP - 9 - 9 - 2 - AUDIO - TV
TV as 2nd Cable key: SETUP - 9 - 9 - 2 - CBL - TV
TV back to TV: SETUP - 9 - 9 - 2 - TV - TV
VCR as 2nd TV key: SETUP - 9 - 9 - 2 - TV - VCR
VCR as 2nd Audio key: SETUP - 9 - 9 - 2 - AUDIO - VCR
VCR as 2nd Cable key: SETUP - 9 - 9 - 2 - CBL - VCR
VCR back to VCR: SETUP - 9 - 9 - 2 - VCR - VCR
AUDIO as 2nd TV key: SETUP - 9 - 9 - 2 - TV - AUDIO
AUDIO as 2nd VCR key: SETUP - 9 - 9 - 2 - VCR - AUDIO
AUDIO as 2nd Cable key: SETUP - 9 - 9 - 2 - CBL - AUDIO
AUDIO back to AUDIO: SETUP - 9 - 9 - 2 - AUDIO - AUDIO
Upon completion of a re-assignment, the LED will blink
twice to confirm your selection.At that time, you will also
need to program the Millennium 4 to control the new
component (see previous sections on Programming TV
Control, Programming VCR Control, Programming Cable
Control, or Programming Audio Control).
30
