Crestron TMK-4L & WMKT-4L
Trim Ring Mount Kits:
TMK-4L & WMKT-4L
Description
Installation Guide – DOC. 6390A
Trim Ring Mount Kits are the preferred method of mounting the Crestron Isys
TPS-4L wall mounted touchpanel when a finished appearance within a neatly
trimmed cutout is required. This application is perfect for wallpapering.
NOTE: If mounting into a material other than drywall (for example, wood lectern,
concrete, or rock) use the cutout template, available in the post-construction kit
WMKT-4L. For concrete and rock mounting material, allow for proper ventilation
before mounting the touchpanel.
There are two Trim Ring Mount Kits. The TMK-4L is a pre-construction accessory.
Pre-construction refers to framed walls prior to hanging drywall. This accessory
must be used with either the Pre-Construction Mount Kit (PMK-4L) or Back Box Kit
(BB-4L).
The WMKT-4L is a post-construction kit. Post-construction refers to framed walls
with drywall hung. This accessory is designed with a mounting plate so that it can be
placed anywhere on a wall without the support of a stud. The mounting plate is also
ideal for installing the touchpanel in a lectern.
NOTE: If necessary, consult the latest revision of the TPS-4L Installation and
Operations Guide (Doc. 6449) for a complete list of mounting options. The
document is available from the Crestron website (http://www.crestron.com/manuals).
Trim Ring Mount Kits
Trim Ring Mount Kits: TMK-4L & WMKT-4L • 1
®
