- Page 1 Crestron TMK-4L & WMKT-4L Trim Ring Mount Kits Installation Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2007 Crestron Electronics, Inc.
-
Page 3: Table Of Contents
Crestron TMK-4L & WMKT-4L Trim Ring Mount Kits Contents Trim Ring Mount Kits: TMK-4L & WMKT-4L Description..........................1 Setup ............................2 Supplied Hardware ...................... 2 Installation ........................4 Resources..........................10 Industry Compliance ....................10 Reference Documents....................10 Further Inquiries ......................10 Future Updates ...................... -
Page 5: Trim Ring Mount Kits: Tmk-4L & Wmkt-4L
WMKT-4L. For concrete and rock mounting material, allow for proper ventilation before mounting the touchpanel. There are two Trim Ring Mount Kits. The TMK-4L is a pre-construction accessory. Pre-construction refers to framed walls prior to hanging drywall. This accessory must be used with either the Pre-Construction Mount Kit (PMK-4L) or Back Box Kit (BB-4L). -
Page 6: Setup
Supplied Hardware The TMK-4L consists of a metal trim ring that attaches to the BB-4L or PMK-4L. The WMKT-4L consists of the trim ring found in the TMK-4L as well as a mounting plate. The mounting plate provides the necessary support for post-construction applications. - Page 7 FOR WMKM-4L OR WMKT-4L ONLY 1 OF 2 3 13/16 in 4 1/16 in (97 mm) (103 mm) 1 5/16 in (33 mm) 4 5/16 in (110 mm) Trim Ring Mount Kits: TMK-4L & WMKT-4L • 3 Installation Guide – DOC. 6390A...
-
Page 8: Installation
Be sure to review each procedure before starting. TMK-4L Procedure This section provides the necessary steps for the assembly of the TMK-4L with either the BB-4L or PMK-4L. It is assumed that the BB-4L or PMK-4L has been secured to the stud according to the instructions in the latest revisions of their Installation Guides (Doc. - Page 9 BB-4L. Refer to the latest revision of the TPS-4L Operations and Installation Guide (Doc. 6449) for details. Refer also to the comprehensive illustration on the following page. Trim Ring Mount Kits: TMK-4L & WMKT-4L • 5 Installation Guide – DOC. 6390A...
- Page 10 Crestron Mud Mount Kit, MMK-4L. Together with the mounting plate supplied with the WMKT-4L, it provide a cost-effective means of correction. Essentially, the combination of these two kits makes up the Crestron Mud Mount Kit for the wall, WMKM-4L. Simply follow the “WMKM-4L Procedure” in the latest revision of the Mud Mount Kits Installation Guide (Doc.
- Page 11 (approximately 90 degrees). Refer to the illustration on the following page. NOTE: The mounting plate will have a slight play; this is normal. It allows for minor adjustments to the touchpanel during installation. Trim Ring Mount Kits: TMK-4L & WMKT-4L • 7 Installation Guide – DOC. 6390A...
- Page 12 Refer to the latest revision of the TPS-4L Operations and Installation Guide (Doc. 6449) for details. Refer also to the comprehensive illustration on the following page. 8 • Trim Ring Mount Kits: TMK-4L & WMKT-4L Installation Guide – DOC. 6390A...
- Page 13 Trim Ring Mount Kits Touchpanel Mounting Using WMKT-4L – Exploded View MOUNTING PLATE (2013242) DRYWALL TRIM RING (2013241) TPS-4L TPS-4L MOUNTING SCREW (4) #04-40 X 2" (2018793) Trim Ring Mount Kits: TMK-4L & WMKT-4L • 9 Installation Guide – DOC. 6390A...
-
Page 14: Resources
Crestron TMK-4L & WMKT-4L Resources Industry Compliance As of the date of manufacture, the TMK-4L and WMKT-4L have been tested and found to comply with specifications for CE marking. Reference Documents The latest version of all documents mentioned within the guide can be obtained from the Crestron website (www.crestron.com/manuals). -
Page 15: Return And Warranty Policies
Purchasers should inquire of the dealer regarding the nature and extent of the dealer's warranty, if any. CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended or if it has been subjected to misuse, accidental damage, modification or improper installation procedures. - Page 16 Crestron Electronics, Inc. Installation Guide – DOC. 6390A 15 Volvo Drive Rockleigh, NJ 07647 (2013262) Tel: 888.CRESTRON 11.07 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
