- Page 1 Crestron TMK-3100L & WMKT-3100L Trim Ring Mount Kits Installation Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2004 Crestron Electronics, Inc.
-
Page 3: Supplied Hardware
(Doc. 6291) for a complete list of mounting options. Supplied Hardware The TMK-3100L consists of a metal trim ring that attaches to the PMK-3100L or BB-3100L. The WMKT-3100L consists of the trim ring found in the TMK-3100L as well as a mounting plate. The mounting plate is the part that provides the necessary support for post-construction applications. - Page 4 Trim Ring Mount Kits The dimensions of the TMK-3100L/WMKT-3100L are shown below. Dimensional Drawing MOUNTING PLATE (WMKT-3100L ONLY) Drywall Cutout Dimensions 2 • Trim Ring Mount Kits: TMK-3100L & WMKT-3100L Crestron TMK-3100L & WMKT-3100L 9.19 in (23.35 cm) 8.15 in (20.71 cm)
-
Page 5: Installation
TMK-3100L Procedure The procedure in this section provides the necessary steps for the assembly of the TMK-3100L to either the PMK-3100L or BB-3100L. It is assumed that the PMK-3100L or BB-3100L has been secured to the stud according to the procedures in the latest revisions of their respective Installation Guides (Doc. - Page 6 Crestron Mud Mount Kit, MMK-3100L. It and the mounting plate supplied with the WMKT-3100L provide a cost-effective means of correction. Essentially, The combination of these two kits makes up the Crestron Mud Mount Kit for the Wall, WMKM-3100L. Simply follow the “WMKM-3100L Procedure” in the latest revision of the Mud Mount Kits Installation Guide (Doc.
- Page 7 6. When the mounting plate is in position, bend the top two flanges of the trim ring upward (approximately 90 degrees) and the bottom two flanges downward (approximately 90 degrees). Refer to the following diagram. Trim Ring Mount Kits: TMK-3100L & WMKT-3100L • 5 Trim Ring Mount Kits MOUNTING PLATE IMPORTANT: MAKE DRYWALL CUTOUT AS LEVEL AND CLEAN AS POSSIBLE.
- Page 8 NOTE: The mounting plate will have slight play; this is normal. It allows for minor adjustments to the TPS-3100L during installation. 6 • Trim Ring Mount Kits: TMK-3100L & WMKT-3100L Crestron TMK-3100L & WMKT-3100L 7. Run the necessary cables for the touchpanel and secure them behind the drywall.
-
Page 9: Further Inquiries
(www.crestron.com) to ask questions about Crestron products. First-time users will need to establish a user account to fully benefit from all available features. As of the date of manufacture, the TMK-3100L and WMKT-3100L have been tested and found to comply with specifications for CE marking. -
Page 10: Return And Warranty Policies
CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures. - Page 11 Crestron TMK-3100L & WMKT-3100L Trim Ring Mount Kits This page intentionally left blank. Trim Ring Mount Kits: TMK-3100L & WMKT-3100L • 9 Installation Guide – DOC. 6295...
- Page 12 Crestron Electronics, Inc. Installation Guide – DOC. 6295 15 Volvo Drive Rockleigh, NJ 07647 09.04 Tel: 888.CRESTRON Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
