Goodmans GCE 7355 MP3 Instruction Manual

Goodmans GCE 7355 MP3 Instruction Manual

In car radio compact disc player
Hide thumbs
Table of Contents

Advertisement

Quick Links

INSTRUCTION
MANUAL
Model GCE 7355 MP3
In Car Radio
Compact Disc Player
022475

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GCE 7355 MP3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Goodmans GCE 7355 MP3

Summary of Contents for Goodmans GCE 7355 MP3

  • Page 1: Instruction Manual

    INSTRUCTION MANUAL Model GCE 7355 MP3 In Car Radio Compact Disc Player 022475...

  • Page 2: Table Of Contents

    +12 volt antenna wire of your radio. If you are in any doubt of this connection please contact the vehicle dealer or Goodmans installation helpline. IMPORTANT: Do not forget to remove the transit screws on top of the unit, before removing the fixing cage and installing the unit.

  • Page 3: Accessories

    1 x 15 Amp fuse (spare for memory). 15A Fuse 0.5A Fuse (2) 2 x ISO Plug Connector For use when ISO plugs are not used on your vehicle Main Unit ISO Socket (3) 2 x Release key P. 3 Goodmans Product Information Helpline (0870) 873 0080...

  • Page 4: Important Notes

    When connecting your car stereo’s black ground wire, be sure to connect the wire to a metal part of your vehicle or preferably to the negative (–) terminal of the car battery. P. 4 Goodmans Product Information Helpline (0870) 873 0080...

  • Page 5: Precautions And Maintenance

    RESET Caution Vauxhall owners: Vauxhall do not follow normal ISO wiring convention which will cause Goodmans radios’ to lose the radio preset memories each time the ignition switch is turned off. To prevent such occurrences swap over the Red ignition and Orange Memory wires in the bullet connectors attached to the wiring harness of the car radio.

  • Page 6: Installation/Precautions

    Bend these claws, if necessary Car aerial Insert radio into car slot Note: Keep the release keys in a safe place as you may need them in future to remove the unit from the car. P. 6 Goodmans Product Information Helpline (0870) 873 0080...

  • Page 7: Removing And Attaching The Trim Ring

    Ensure that the keys are fully pressed into the slots. • Pull on both of the release keys to remove the unit from the fixing bracket/car slot. Insert keys into key holes and pull to remove unit. P. 7 Goodmans Product Information Helpline (0870) 873 0080...

  • Page 8: Using The Detachable Front Panel

    Front panel pressure to the control buttons of the front panel when attaching it to the unit. Note: When the detachable panel is removed the red anti theft LED will flash. P. 8 Goodmans Product Information Helpline (0870) 873 0080...
  • Page 9 5. Do not expose the front panel to high temperatures or direct sunlight. 6. Keep any volatile agents (e.g. benzene, thinner, or insecticides) from touching the surface of the front panel. 7. Do not attempt to disassemble the front panel. P. 9 Goodmans Product Information Helpline (0870) 873 0080...

  • Page 10: Wiring Identification

    Try the unit again it should power up and can be used normally. Note this phenomenon is most frequent in Volkswagen/Audi vehicles. P. 10 Goodmans Product Information Helpline (0870) 873 0080...

  • Page 11: Iso Plug Connections

    White with black stripe Speaker right front – Grey Speaker left front Grey with black stripe Speaker left front – Brown Speaker left rear Brown with black stripe Speaker left rear – P. 11 Goodmans Product Information Helpline (0870) 873 0080...

  • Page 12: Recommended Minimum Loudspeaker Power Ratings

    ISO plugs into the ISO socket of the car radio. The plugs are handed and will only fit one way. Connect the bare wires ends in accordance with the instructions given on page 10. P. 12 Goodmans Product Information Helpline (0870) 873 0080...

  • Page 13: Identification Of Controls And Functions

    19. Disc Pause Button Volume Knob 20. Disc Scan Button Power Button 21. Disc Repeat Button 10. Select Button 22. Disc Shuffle Button 11. Equalization Button 23. Liquid Crystal Display 12. Reset Button P. 13 Goodmans Product Information Helpline (0870) 873 0080...
  • Page 14 3. SOUND ADJUSTMENT Press SEL button (10) briefly to select the desired adjustment mode. The adjustment mode will change in the following order: VOLUME SELECT BASS SELECT TREBLE SELECT BALANCE SELECT FADER SELECT P. 14 Goodmans Product Information Helpline (0870) 873 0080...
  • Page 15 FLAT CLASSICS POP M ROCK M DSP OFF • SELECT MODE Press MOD button (6) to select required listening mode. [e.g. radio mode or CD mode] • LIQUID CRYSTAL DISPLAY (23) P. 15 Goodmans Product Information Helpline (0870) 873 0080...

  • Page 16: Manual Tuning

    ) (17) for more than 2 seconds until “Manual”. is shown in the display. Repeatedly press MANU/SKIP ( ) (16) or MANU/SKIP ( ) (17) to tune to the desired station. P. 16 Goodmans Product Information Helpline (0870) 873 0080...
  • Page 17 BND/LOU button (13) and then press the desired preset 1-6 button (14). To Hear a Preset Station Select desired band and press the appropriate preset button 1-6 (14) into which the station has been stored. P. 17 Goodmans Product Information Helpline (0870) 873 0080...

  • Page 18: Overview Of The Rds Function

    By this function, the unit automatically monitors the station and changes its mode to the traffic information reception when the broadcast starts even whilst listening to CD playback or an External source. P. 18 Goodmans Product Information Helpline (0870) 873 0080...
  • Page 19 Clock Frequency display Program type display If the RDS station is not transmitting the PTY (program type) or CT (Clock) data, programme type or clock will not show in the display. P. 19 Goodmans Product Information Helpline (0870) 873 0080...
  • Page 20 Press DSP x 1-CT displayed; DSP x 2-Programme type; DSP x 3 -Frequency display. After 5 seconds the display will revert to station name display. Note: Some stations do not transmit PTY or CT information and therefore the clock display may not be available. P. 20 Goodmans Product Information Helpline (0870) 873 0080...

  • Page 21: Traffic Information Reception

    TA button, until EON TA LO shows in the display for local + long distance press and hold until EON TA DX shows in the display. P. 21 Goodmans Product Information Helpline (0870) 873 0080...
  • Page 22 1. Press TA button (2) while playing back a CD. “TA” appears on the display window, while playback continues. When a traffic information broadcast starts. “TA” starts blinking. The CD playback stops and the traffic information will be heard. P. 22 Goodmans Product Information Helpline (0870) 873 0080...
  • Page 23 CHILDREN SOCIAL RELIGION PHONE IN TRAVEL LEISURE DOCUMENT Figure 4 PTY code is always enabled. The radio will always respond to a PTY message even when the PTY is not selected. P. 23 Goodmans Product Information Helpline (0870) 873 0080...
  • Page 24 • Press the SHF button (22). The display will show S-SHF and the current disc will be played in random mode continuously. • Press SHF button to return player to normal mode. P. 24 Goodmans Product Information Helpline (0870) 873 0080...

  • Page 25: Mp3 Operation

    Press the Skip Up or Down buttons to locate and play other tracks on the disc. Note: The Preset buttons 5 & 6 on the front panel of the player can be used to skip up/down directories. P. 25 Goodmans Product Information Helpline (0870) 873 0080...
  • Page 26 TAG exists on the files which have been previously entered when the disc was compiled on a PC. The display button will also show the Radio frequency and Clock time etc. P. 26 Goodmans Product Information Helpline (0870) 873 0080...

  • Page 27: Wma Operation

    CAUTION: VBR of WMA can be played back if the bit rate is 48 kbps or higher. If a bit rate of less than 48 kbps exists in a stream, that stream will not play correctly. This is normal and is not a fault with the player. P. 27 Goodmans Product Information Helpline (0870) 873 0080...
  • Page 28 If the interference is severe, retuning to an alternate frequency (BBC often use more than 1 frequency) or selecting and tuning into a different waveband may be necessary. P. 28 Goodmans Product Information Helpline (0870) 873 0080...
  • Page 29 The alternator/dynamo should be fitted with a 2.2 MFD capacitor which should be connected between the +B lead (usually the thickest lead) and the car chassis or body of the alternator. P. 29 Goodmans Product Information Helpline (0870) 873 0080...

  • Page 30: Trouble Shooting

    The temperature in the car is Cool off the inside of the car, then try too high. again. Condensation. Leave the disc player off for an hour or so, then try again. P. 30 Goodmans Product Information Helpline (0870) 873 0080...
  • Page 31 The aerial cable is not Insert the aerial cable solidly. does not connected. work. The radio The signals are too weak. Select a station manually. station automatic selection does not work. P. 31 Goodmans Product Information Helpline (0870) 873 0080...

  • Page 32: Specifications

    : 522 to 1620 KHz : 450 Khz Sensitivity (S/N = 20 dB) : 32 dBu Frequency Coverage : 144 to 288 KHz : 450 Khz Sensitivity (S/N = 20 dB) : 35 dBu P. 32 88-C2001-41 Goodmans Product Information Helpline (0870) 873 0080...
