Figure 5. The curves above left show the effect of the 'bass tilt', 'bass
level' and 'bass roll-off' controls on the free field response. The curves
to the right show the effect of the treble and midrange 'level' controls.

SYSTEM SPECIFICATIONS

Lower cut-off frequency, -3 dB:
Upper cut-off frequency, -3 dB: >20 kHz
Free field frequency response
of system: 35 Hz - 20 kHz (±2.5 dB)
Maximum short term sine wave acoustic
output on axis in half space, averaged
from 100 Hz to 3 kHz:
@1m
@0.5m
Maximum long term RMS acoustic output in
same conditions with IEC-weighted noise
(limited by driver unit protection circuit):
@1m
@0.5m
Maximum peak acoustic output per pair on
top of console, @ 2m from the engineer
with music material:
Self generated noise level in free field @1m
on axis: <15 dB (A weighted)
Harmonic distortion at 95 dB SPL at 1m
on axis: freq. 50...100 Hz
freq. >100 Hz
Drivers: Bass 385mm (15") cone
Midrange 130mm (5") cone
Treble 25mm (1") metal dome
Weight:
Dimensions:
Height
Width 480 mm (18 9/10")
Depth 420 mm (16 1/2")
Genelec Oy, Olvitie 5
FIN - 74100 IISALMI, FINLAND
Phone: +358 17 83881
Telefax: +358 17 812 267
Email: genelec@genelec.com
Web: www.genelec.com

AMPLIFIER SECTION

<33 Hz
Bass amplifier output power with a 8 Ohm
load:
Midrange amplifier output power with
a 8 Ohm load:
Treble amplifier output power with
a 8 Ohm load:
Long term output power is limited by driver
unit protection circuitry.
>120 dB SPL
>126 dB SPL
Slew rate:
Amplifier system distortion at nominal
output:
>116 dB SPL
>122 dB SPL
Signal to Noise ratio, referred to full output:
>124 dB
Mains voltage:
Voltage operating range: nominal ±10%
<1%
Power consumption:
<0.5%
60 kg (130 lb)
Note! All frequency response curves were measured in a cali-
810 mm (32")
brated, 12 m cube, anechoic chamber at 1 m using grade 1
measuring equipment. Input signal levels were set at -20 dBu.
The anechoic chamber error in the free field response is less than
0.5 dB down to 60 Hz.
Genelec Inc., 7 Tech Circle
NATICK, MA 01760, U.S.A.
Phone: +1 508 652 0900
Fax: +1 508 652 0909
Email: genelec.usa@genelec.com
Figure 6. The upper curve group shows the horizontal directivity
characteristics of 1038A in its vertical configuration measured at 1m.
The lower curve is a 1/3 octave band power response, measured in an
IEC approved reverberation chamber.
Short term 400W
Short term 120W
Short term 120W
80V/µs
THD <0.05%
SMPTE-IM <0.05%
CCIF-IM <0.05%
DIM 100 <0.05%
Bass >100 dB
Midrange >100 dB
Treble >100 dB
100/200V or 115/230V
Idle 60W
Full output 500W
CROSSOVER SECTION
Input connector: XLR female
pin1
pin2
pin3
Input impedance:
Input level for 100 dB SPL output @1m:
variable from +6 to -6 dBu
Input level for maximum short term output
of 120 dB SPL @1m:
variable from +26 to +14 dBu
Subsonic filter below 33 Hz :
18 dB/octave
Ultrasonic filter above 25 kHz:
12 dB/octave
Crossover frequency:
Bass/Mid
Mid/Treble
Crossover acoustical slopes:
24 - 32 dB/octave
Crossover level control operating range in
1 dB steps: Bass from 0 to -6 dB
Mid from 0 to -6 dB
Treble from 0 to -6 dB
Bass roll-off control in 2 dB steps:
from 0 to -8 dB @33 Hz
Bass tilt control in 2 dB steps:
from 0 to -8 dB @80 Hz
The 'CAL' position is with all tone controls
set to 'off' and input sensitivity control to
maximum.
Genelec document DR1038001
COPYRIGHT GENELEC OY 9/2000
All data subject to change without prior notice
gnd
+
-
10 kOhm
410 Hz
3 kHz
