- Page 1 READ AND SAVE THESE INSTRUCTIONS LOFT ™ 60” Damp Location Ceiling Fan Owner's Manual Model Numbers CF765BQ00 - Barbeque Black CF765BS00 - Brushed Steel CF765WW00 - Appliance White 16.7 Net Weight: Lbs. Part No. F40BP73780000 Form No. BP7378 U.L. Model No.: CF765...
-
Page 2: Safety Instructions
WARNING: To reduce the risk of fire or electric shock, this fan should only be used with fan speed control SW46, manufactured by Rhine Electric Co., Ltd. WARNING: To avoid fire, shock or injury, do not use an Emerson or any other brand of control not specifically approved for this fan. -
Page 3: Tools Needed For Assembly
Emerson Electric Co. Substitution of parts or accessories not designated for use with this product by Emerson Electric Co. could result in personal injury or property damage. 1. Unpack the items carefully to avoid damage to any of the components. -
Page 4: Electrical Requirements
2. Remove the two setscrews from the top of the Electrical Requirements motor coupler (Figure 1). Retain the setscrews for future use. Your new ceiling fan will require a grounded electrical supply line of 120 volts AC, 60 Hz, 15 amp circuit. 3. -
Page 5: How To Hang Your Ceiling Fan
HANGER WARNING BALL SETSCREW It is critical that the clevis pin in the motor coupling is properly installed and the setscrews securely CEILING COVER tightened. Failure to verify that the pin and setscrews are properly installed (as shown in Figure 4) could result in the fan falling. - Page 6 How To Wire Your Ceiling WARNING Fan and Install the Hanger bracket must seat firmly against outlet box. If the outlet box is recessed, remove wall board until Control bracket contacts box. If bracket and/or outlet box are not securely attached, the fan could wobble or fall. If you feel that you do not have enough electrical wiring knowledge or experience, have your fan installed by a licensed electrician.
- Page 7 3. Screw the two 1-1/4” threaded studs (supplied) into 9. Slide the Fan Control to the OFF position (0). the tapped holes in the hanger bracket (Figure 11). 10. Connect one BLACK wire from the Fan Control to 4. Lift the ceiling cover up to the threaded studs and the fan/motor lead with a wire connector turn until studs protrude through the holes in the (provided).
-
Page 8: Using Your Ceiling Fan
The use of any other control not specifically accessories not designated for use with this product approved for this fan could result in fire, shock and by Emerson Electric Co. could result in personal personal injury. injury or property damage. -
Page 9: Energy Efficient Use Of Ceiling Fans
If ceiling height allows, install the fan 8 - 9 feet above the floor for optimal airflow. Consult your Emerson Turn Off When Not in the Room. Ceiling fans cool Retailer for optional mounting accessories. -
Page 10: Repair Parts
Repair Parts U.L. Model No.: CF765... -
Page 11: How To Order Repair Parts
Repair Parts Listing Part Numbers Model No. Model No. Model No. Description CF765BQ00 CF765BS00 CF765WW00 Hanger Ball Assembly, 761655-78 761655-27 761655-79 Consisting of: Hanger Bracket — — — Hanger Ball — — — Downrod — — — Parts Bag Containing:... -
Page 12: Limited Warranty
If repair of the motor or blades is not practical or possible within a reasonable time and no replacement can be provided, Emerson Electric Co. will refund the actual purchase price of your fan. We will ship the repaired product or replacement to you at no charge, but you are responsible for all costs or removal, reinstallation and shipping of the product to Emerson Electric Co.
