  • Page 2: Package Contents

    Keep the Network Camera away from Do not place the Network Camera in direct sunlight. high humidity environments. Package Contents FD8163 Alignment Sticker T10 Torx Screwdriver/ Screws / DC Software CD connector / Plastic Anchors / AV Cable...

  • Page 3: Physical Description

    Physical Description Remove foam pad. Camera Front View IR LEDs (8 units, effective up to 15m) Black Cover Lens Light Sensor Auto Focus Button Built-in Microphone PIR Sensor Camera Rear View NOTE: The max. output load from pins #7 and 8 is 50mA. Micro SD/SDHC/ SDXC Card Slot Reset Button...

  • Page 4: Hardware Installation

    You should then jot down the MAC address at the bottom of the camera. Dome Cover Bottom of the Camera FD8163 NOTE: You may use the included AV cable to connect a camera tester for initial configuration at the installation site.

  • Page 5: Network Deployment

    Wall Mount Ceiling Mount 1. Attach the alignment sticker to the ceilling/wall. 2. Through the two circles on the sticker, drill two pilot holes into the ceilling/wall. 3. The Network Camera can be mounted with the cable routed through the ceiling/wall or from the side.

  • Page 6: Power Over Ethernet (Poe)

    Power over Ethernet (PoE) When using a PoE-enabled switch This Network Camera is PoE-compliant, allowing transmission of power and data via a single Ethernet cable. Follow the below illustration to connect the Network Camera to a PoE-enabled switch via Ethernet cable. NOTE: 1.

  • Page 7: Assigning An Ip Address

    2. The program will conduct an analysis of your network environment. After your network is analyzed, please click on the “Next” button to continue the program. 3. The program will search for VIVOTEK Video Receivers, Video Servers, and Network Cameras on the same LAN.

  • Page 8: Adjusting The Lens

    Adjusting the Lens Based on the live image retrieved from the camera, adjust the camera lens to the desired view angle: 1. Turn the lens module left and right. 2. Loosen the tilt adjustment screws on both sides of the camera and then turn the lens module up and down.
  • Page 9 3. You may also push the Auto Focus button on the camera to obtain the same results especially when you are using camera tester for onsite adjustment. NOTE: When mounting the camera, you can use the key hole slot at the bottom. The key hole slot helps facilitate installation and a safe mounting.
  • Page 10 Completion 1. If you choose to feed the cable through the ceiling/wall, arrange the cables neatly through the cable hole A (not shown in the drawing). If you choose to feed the cable from the side, remove plate B. 2. Attach the dome cover to the camera as the direction shown below. Tighten two screws from the sides of the dome cover.
