Flash Cache Module - HP EliteBook Folio 9470m Specification

QuickSpecs
Features

FLASH CACHE MODULE

Optional 32 GB mSATA Flash cache module support for Intel Smart Response Technology. (Available only with standard non-SED
hard drive).
STORAGE AND DRIVES
Primary Storage Bay
Hard Drives
320/500GB 7200 rpm SMART SATA II
500 GB 7200 rpm SMART SATA II Self Encrypting Drive
HP 3D DriveGuard (Windows only)
The hard drive is mounted directly to the notebook frame, reducing the transmission of shock to the hard drive.
Solid State Drive
SATA 6 Gb/s 180 GB Solid State
SATA 6 Gb/s 240 GB Solid State
SATA 6 Gb/s 256 GB Solid State
mSATA module
256 GB mSATA module
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. Actual formatted capacity is less. Up to 30 GB (for Windows 7)
and up to 36 GB (for Windows 8) of system disk is reserved for the system recovery software.
NOTE: The EliteBook Folio is available in standard thin and light configurations for customers who value the ultra-thin design but
prefer options such as a standalone HDD or require a self-encrypting hard drive. These configurations will not meet Intel's
definition of an Ultrabook.
MEMORY
Standard
DDR3 PC3-12800 SDRAM (1600 MHz)
Two SODIMM slots supporting dual-channel memory
Standard memory up to 8192 MB (2 GB, 4 GB, and 8 GB SODIMMs)
Maximum
Upgradeable to 16384 MB with optional 8192 MB SODIMMs in slots 1 and 2
Dual-channel
Maximized dual-channel performance requires SODIMMs of the same size and speed in both memory slots.
NOTE: Due to the non-industry standard nature of some third-party memory modules, we recommend HP branded memory to
ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed. With Windows Starter 32-
bit operating systems, the amount of usable memory is dependent upon your configuration, so that above 3 GB all memory may
not be available due to system resource requirements.
DA - 14317 North America — Version 10 — August 15, 2013
HP EliteBook Folio 9470m
Page 5
