Summary of Contents for Delphi xm2go MyFi SA10113

Page 1 Satellite Radio Receiver · User Guide Model SA10113 Warning: This manual contains important safety and operating information. Please read, understand, and follow the instructions in this manual. Failure to do so could result in personal injury, death, and/or damage to your MyFi receiver,...
Page 2 Changes or modifications to the unit not expressly approved by Delphi can void your authority to operate this equipment. Important: The FCC and FAA have not certified the Delphi XM MyFi Satellite Radio Receiver for use in any aircraft (neither portable nor permanent installation). Therefore, Delphi cannot support this type of application or installation.
Page 3: Table Of Contents
A Brief History ....... 4 About Delphi....... . 5 About XM .
Page 4: A Brief History
A Brief History Ever since XM Satellite Radio signed up its first subscriber in 2001, Delphi and XM have been working constantly to create the best satellite radio receiver. We imagined a radio that works not only in a vehicle, a home, or an office, but something you can take with you virtually anywhere you go.
Page 5: About Delphi
About Delphi Delphi is a worldwide leader in mobile electronics, vehicle components, and audio technology. Delphi created the first in-dash car radio in 1936 and continues its strong tradition of innovation in the audio industry. Now Delphi technology has helped make satellite radio a reality, and Delphi continues to expand its in-vehicle and consumer electronics technologies.
Page 6: Let's Get Started
Let’s Get Started First, some important reminders We know you’re eager to turn on your brand new MyFi and listen to XM. Please take a moment to remember the following: Warning: This manual contains important safety and operating information. Please read, understand, and follow the instructions in this manual.
Page 7 Warning: If you use your MyFi in a moving vehicle or watercraft, keep your eyes on the road or water, and hands on the wheel or controls. Not doing so could result in personal injury, death, and/or damage to your MyFi receiver, accessories, and/or to your vehicle or other property.
Page 8: Remote Control
REMOTE CONTROL search button – search by scanning presets or by scanning all channels 2go button – store up to five hours of XM programming using the “MY XM” Time- shifting Memory Mode jump button – switch to previous channel arrow buttons –...
Page 9: On The Flip Side
power button – press to turn your MyFi on and off mode button – switch between “LIVE” XM and “MY XM” Time-shifting Memory Mode channel buttons – preview channels (“LIVE”); preview songs (“MY XM”) menu button – customize options and access advanced features XM button –...
Page 10: What's In The Box
What’s in the box? Your MyFi includes these components: MyFi receiver belt clip/stand remote control wearable antenna with two clip options home stand protective case home antenna home power audio cable adaptor...
Page 11 rechargeable lithium ion battery headphones vehicle antenna cassette adaptor vehicle cradle vehicle power adaptor swivel mount (with extra adhesive pad) flush mount vent mount cleaning kit Velcro ® pads...
Page 12: Setting Up
Setting Up Assembly Insert the battery and assemble your MyFi and its home stand as shown; plug the AC adaptor into an outlet. Let the battery charge for at least three hours. Insert battery Important! You will need to fully charge your MyFi battery for at least three hours to have sufficient battery power for portable use.
Page 13: Connecting To A Stereo
Connecting to a stereo Plug the AC adaptor into an outlet. Connect the home antenna and connect the line out to either your home stereo or powered (PC type) speakers. 5V DC LINE OUT Connect to stereo Receiving the XM signal Turn your MyFi on by pressing the power button.
Page 14: Activating Your Myfi
Activating Your MyFi Turn the dial to highlight channel 0, and press the dial in to select it. You should see an 8-character XM Radio ID in the display. (The XM Radio ID should also be on your MyFi’s package and under the battery.) Write the ID here: The XM Radio ID does not use the letters I, O, S, and F.
Page 15: Listening To Xm
Listening To XM Changing channels 1. Rotate the dial to preview a list of channels. 2. When your desired channel is highlighted, press the dial in to select that channel. -OR- 1. Press the “pre/dir” button until the word “DIRECT” flashes in the display. 2.
Page 16: Saving Favorite Channels Into Presets
Saving favorite channels into presets Your MyFi can store up to 30 of your favorite channels as presets. The presets are organized into three banks (A, B, or C) that each contain 10 presets. TO SAVE A CHANNEL INTO A PRESET: 1.
Page 17: Storing Song Information In Memory
Storing song information in memory Ever hear a song and later forget the artist’s name or song title? Let your MyFi remember for you. TO STORE A SONG’S INFORMATION IN MEMORY: Press and release the “mem” button while the song or program is playing.
Page 18: My Xm Time-Shifting Memory Mode
My XM Time-shifting Memory Mode 2go: Store and play back Your MyFi lets you store up to five hours of programming and play it back at a later time or where live signal reception is limited. Listen to XM wherever you are, whenever you prefer.
Page 19: Scheduling A Session
Scheduling a session You can set your MyFi to store XM programming at a specific time using the “MY XM” Time-shifting Memory Mode. 1. Press the “menu” button and use the dial to select “MY XM.” 2. Select “Schedule MY XM.” 3.
Page 20: Personalizing Your Myfi
Personalizing Your MyFi You can easily adapt your MyFi to the way you listen and use the satellite radio. You can change how the display appears, track stocks and other information, adjust your MyFi’s audio output, and change how you use the display. Simply press the “menu”...
Page 21: Changing Display Information
TO CHANGE THE AUDIO LEVEL of the cassette adaptor, FM transmitter, or line-level audio output: 1. Press the “menu” button and use the dial to select “Set Audio.” 2. Select “Line Out Level.” Your MyFi can detect when you’re using the FM transmitter or cassette adaptor and will make the appropriate changes to the settings.
Page 22 TO CHANGE THE APPEARANCE OF THE SCREEN, press the “menu” button and select “Change Display.” You can change the brightness and contrast, set how long the backlight remains on, flip the screen between positive (black characters on white background) or negative (white characters on black background) modes, and set the way the Stock Ticker and Info Extras appear on the screen.
Page 23: Make Any Fm Radio An Xm Radio
FM transmitter. TIP: In the rare situation that you cannot find an open FM frequency, consult a professional car audio installer. You can improve the audio performance in your vehicle by using the Delphi FM Direct Adaptor (model SA10112, sold separately).
Page 24: Stock Ticker
Stock Ticker With your MyFi, you can track up to 20 stock symbols and see their prices and movements right on the screen.* TO ADD A STOCK SYMBOL: 1. Using the “menu” button and dial, select “Stock Ticker.” 2. Rotate the dial to highlight “Add Stocks” and press the dial in to select.
Page 25: Direct Tune: Select Channels Faster
Direct Tune: Select channels faster Normally as you rotate the dial, you can preview what’s playing on other XM channels before you push the dial in to select a channel. To automatically tune to the channel without pressing the dial, you can set the following option: 1.
Page 26: Skipping Channels
Skipping channels You can simplify the list of channels that you see when you rotate the dial. To skip over a channel: 1. Use the “menu” button and dial to select “Channel Access.” 2. Choose the “Channel Skip/Add” option. 3. You will see a list of channels.
Page 27: Using Myfi At Home
Using MyFi At Home Turn off your MyFi and your audio system. Connect your MyFi to your audio system in either way illustrated below. If you use the home stand and connect it to a stereo, you must plug in the AC adaptor and home antenna. Your MyFi’s audio output will not work if these are not connected.
Page 28: Aiming The Home Antenna
Aiming the home antenna Your MyFi can help you aim the home antenna to pull in the strongest signal available. 1. Using the “menu” button and dial, choose “Antenna Aiming.” 2. Slowly turn and tilt the antenna. The signal bars on the display will change.
Page 29: Using Myfi In Your Vehicle
Using MyFi In Your Vehicle Because every vehicle is different, we can only provide some general guidelines. If you need help, consult a professional installer. 1. Decide which method (cassette adaptor, wireless FM transmitter, or wired connection) is best for your vehicle and location.
Page 30 Made in Malaysia TO FM TO FM RADIO For a neat, fully integrated installation, use the DELPHI FM DIRECT ADAPTOR (model SA10112, sold separately). We recommend that you consult a professional installer. The WIRELESS FM TRANSMITTER is the easiest and quickest way to hear XM programming in your vehicle.
Page 31: Placing The Antenna
Placing the antenna Your XM antenna should be mounted on the vehicle’s metallic roof, at least 6" from any window or sunroof. It can be placed in the front, middle, or rear of the roof. (Two optional locations) Avoid crimping, twisting, or chafing the XM antenna cable.
Page 32: Mounting Your Myfi On The Dash
Mounting your MyFi on the dash We’ve included three types of mounts to help you install your MyFi in your vehicle’s interior. FLUSH MOUNT: Attach the included Velcro pads or adhesive pad to the ® back of your MyFi’s vehicle cradle. Stick the vehicle cradle onto a flat surface in your vehicle, preparing the surface as described below.
Page 33: Using Myfi On The Go
Using MyFi On The Go Your MyFi contains a built-in antenna that works best when your MyFi receiver is upright. Use the belt clip to hold your MyFi in the proper position; laying your MyFi down flat may weaken reception. TIP: If you carry your MyFi in a bag or use it while exercising, you can lock the buttons and dial and prevent something from accidentally pressing the...
Page 34: Signal Reception Guidelines
Signal reception guidelines Your MyFi’s antenna should have an unobstructed view of the XM satellites in the southern sky. In large cities, XM also has a network of ground repeaters to help increase the signal coverage.
Page 35: Other Things You Should Know
Other Things You Should Know Care You should be able to take your MyFi along with you during most of your daily activities. Still, you should remember: • Your MyFi is not waterproof. Avoid splashing it with liquids and never submerge it. •...
Page 36: Accessories (Sold Separately)
TIP: Both the home and vehicle power adaptors can be used independently from the home stand and vehicle cradle, plugging directly into the MyFi power connector. This feature provides a convenient alternative for battery charging and powered operation when traveling or for using your MyFi away from home.
Page 37: Troubleshooting
Troubleshooting Your MyFi should provide you with trouble-free performance without needing any servicing. If it does not appear to be working properly, first try to remedy the problem by following these steps: 1. Attach all connections firmly and securely. 2. Make sure the battery is fully charged. 3.
Page 38 If this happens: You should: There is no power, or your Insert your MyFi into its home MyFi shuts off quickly. stand and plug the AC adaptor into the wall to charge the battery. Your MyFi’s battery is low (see page 12). You do not receive all XM Contact XM Satellite Radio channels you have sub-...
Page 39 If this happens: You should: Your MyFi’s controls do not Check whether the lock indicator respond. is being displayed. If so, unlock the controls by pressing and holding the “mute/pause/lock” button until the lock indicator disappears (see page 33). If you have unlocked the controls and they still do not respond, reset your MyFi by carefully inserting the tip of a paper clip into the “RESET”...
Page 40: Contacting Technical Support
Contacting technical support and customer service For additional information in solving problems with your MyFi, contact Delphi Technical Support at 1.877.GO.DELPHI (1.877.463.3574) 8:00 a.m. to 8:00 p.m. Eastern Time, Monday—Friday. Technical Support is also available at www.delphi.com. Technical information DIMENSIONS MyFi receiver: 4.5 in.
Page 41: Warranty
This warranty is not transferable and applies only to the original consumer purchaser of the Product. Delphi will, as its sole obligation under this warranty, replace or repair, at its option, any Product that does not conform to this warranty. Products may be repaired or replaced with new or with refurbished items.
Page 42: How You (The Customer) Can Get Service
So the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights. You may also have other rights that may vary from state to state. NO PERSON IS AUTHORIZED BY DELPHI TO MODIFY OR ADD TO THIS LIMITED WARRANTY.
Page 44 1441 West Long Lake Road Troy, Michigan 48098-5090 U.S.A. Customer Service: [1] 877.GO DELPHI www.delphi.com MyFi is a registered trademark of Delphi Corporation. Printed on Recycled Paper The XM name, XM2Go, TuneSelect, and related ©2004 Delphi Corporation. All rights reserved.
