  • Page 3 Table of Contents Hardware ....................2 Exploded View ..................4 Parts List ....................5 Assembly Instructions ................6 Important Contact Numbers ...............21...
  • Page 4 Note: Please verify you have all correct parts and quantities before assembling unit. If you are missing items, are short quantities, or have damaged components, please contact Schwinn at 1.800.864.1270...
  • Page 5 Note: Please verify you have all correct parts and quantities before assembling unit. If you are missing items, are short quantities, or have damaged components, please contact Schwinn at 1.800.864.1270...

  • Page 6: Exploded View

    EXPLODED VIEW � ��� ��� ��� � ���� ��� ��� � ��� ��� ��� ��� � ��� ��� ��� ��� ��� ��� ��� ��� ��� ��� ��� ��� ��� ��� � ��� ��� � ��� � ���� ���� ��� ���� ����...

  • Page 7: Parts List

    PARTS LIST Ref. Description Computer Computer bracket Screw M5x14L Handlebar Handlebar mast Screw M8x1.25X16 Curved Washer Upper heart rate wire Upper Computer Wire Main frame Lower heart rate wire Lower computer wire D-17 AC Adaptor D-18 Screw M8x1.25x16L D-22 Seat rail bracket Front stabilizer Pedal pair Rear stabilizer...

  • Page 8: Basic Assembly Principles

    Basic Assembly Principles Here are a few basic tips that will aid in the assembly process . By using these principles, you can simplify each process and save yourself extra time and effort. 1. To make the assembly process go faster, gather the pieces you need for each step and thoroughly read the assembly instructions for that step prior to starting assembly for the step.

  • Page 9: Install Front/Rear Stabilizers

    Step 1 Install Front and Rear Stabilizers Parts: • Front Stabilizer (Ref. E ) • Rear Stabilizer (Ref. G ) • M8x16 Screws (Ref. I-6) Tools: • Supplied Allen Wrench 1-1 Attach the Rear Stabilizer (G) to the rear of the Main Unit using two M8 X 16mm screws (I-6).

  • Page 10: Step 2 Install Pedals

    Step 2 Install Pedals Parts: • Right Pedal (F-R) • Right Pedal (F-L) Tools: • Supplied Pedal Wrench 2-1 Screw the Left Pedal ( has an “L” stamped into the end of the pedal ) into the Left Crank Arm. Note: The Left Pedal has a left handed thread and screws in counter clockwise.

  • Page 11: Step 3 Install Handlebar

    Step 3 Install Handlebar Parts: • Seat Frame (Ref. L) • Handlebar (Ref. J) • Four M8x16 screws (Ref. I-5) • Four 8x16x2 Washers (Ref. I-3) Tools: • Supplied Allen Wrench 3-1 Align Handlebar with holes in Seat Frame. 3-2 Install and completely tighten the hardware.
  • Page 12 Bottom Step 4 Install Seat Parts: • Seat Bottom (Ref. K-1) • Four M8x1x45 Screws (Ref. I-7) • Four 8x16x2 Washers (Ref. I-3) Tools: • Supplied Allen Wrench 4-1 Align the Seat Bottom (K-1) with the Seat Frame. 4-2 Install and completely tighten the hardware.
  • Page 13 Step 5 Install Seat back Parts: • Seat Bottom (Ref. L-1) • Four M8x1x45 Screws (Ref. I-7) • Four 8x16x2 Washers (Ref. I-3) Tools: • Supplied Allen Wrench 5-1 Align the Seat Back (L-1) with the Seat Frame. 5-2 Install and completely tighten the hardware. Note: There are two sets of holes in the Seat Back.
  • Page 14 Step 6 Install Bottle Holder Parts: • Water Bottle Holder (Ref. K-2) • Four M5x16 Screws (Ref. I-8) Tools: • Supplied Phillips Head Screwdriver 6-1 Align the Water Bottle Holder under the left side of the Seat Bottom. 6-2 Install and completely tighten the hardware.
  • Page 15 Step 7 Prepare to Install Seat Assembly Tools: • Supplied Allen Wrench 7-1 Unscrew the the seven screws and washers (D-18) that secure the Seat Rail (H) and remove the Seat Rail from the unit. (Figure A) Note: You will have to disconnect the Heart Rate Wire (M). Do not let the Heart Rate Wire fall into the frame.

  • Page 16: Step 8 Install Seat Assembly

    Step 8 Install Seat Assembly Parts: • Seat Assembly (From step 3-6) • Seat Rail (Ref. H) • Seat Rail Bracket (Ref. D-22) Tools: • Supplied Allen Wrench 8-1 Pull out on the Seat Adjustment Knob (K-3) while sliding the Seat Assembly onto the Seat Rail (H).

  • Page 17: Step 9 Install Handlebar Mast

    Step 9 Install Handlebar Mast Parts: • Handlebar Mast (Ref C) Tools: • Supplied Allen Wrench 9-1 Remove the four Allen Bolts (C-1) and Curved Washers (C-2) from the frame . 9-2 Connect the Upper and Lower Computer Wires and Heart Rate Wires.
  • Page 18 Step 10 Install Handlebar Parts: • Handlebar (Ref B) • Washer (Ref I-3) • Screw M8x16 (Ref I-5) 10-1 Tuck the Computer Wires into the Mast to allow insertion of the Handlebar . 10-2 Slide the Handlebar (B) into the Mast and secure with the Console M8x16 Screw (I-5) and Washer (I-3) .
  • Page 19 Step 11 Install Computer Bracket Parts: • Computer Bracket (Ref. A-1) • Angle Adjust Knob (Ref. I-2) • Carriage Bolt M8x1.25x85 (Ref. I-10) • Screw M8x85 (Ref. I-1) • 2 Washers (Ref. I-3) • Hex Nut (Ref. I-4) Tools: • Supplied Socket and Flat Wrenches 11-1 Align the Computer Bracket (A-1) with the holes in the Mast.

  • Page 20: Step 12 Install Computer

    Step 12 Install Computer Parts: • Computer (Ref. A ) Tools: • Supplied Phillips Head Screwdriver 12-1 Remove the four screws from the back of the Computer. 12-2 Connect the Computer Wire and Heartrate Wire to the connectors on the back of the Computer as shown. 12-3 Align the Computer with the holes in the Computer Bracket.

  • Page 21: Step 13 Plug In Ac Adapter

    Step 13 Plug in AC Adapter Parts: • AC Adapter (Ref. D-17) 13-1 Plug the AC Adapter (P) into the recepticle on the front right of the unit and into a 110 volt outlet. D-17...
  • Page 22 Assembly is complete! Please reference the Owner’s Manual for information regarding computer operation, product maintenance, Warranty information, and general fitness and exercise guidelines.
