Page 1: Table Of Contents
Table of Contents Before You Begin ............2 Package Contents . -
Page 2: Before You Begin
Improper installation may result in damage to the screen, other property, or personal injury. Package Contents Verify that you have received all of the parts listed below: Mounting Plate Screen Arms K2 Series K3 Series K2-F-S K2-T-S K3-F-S K3-T-S... -
Page 3: What You Will Need
What You Will Need You will need these tools to install your wall mount bracket: • Measuring tape • Level • Stud finder (for wood stud wall installation) • Pencil or pen • Electric drill • 3/16 inch Drill bit (for wood stud wall installation) •... -
Page 4: Installation
Installation Installing your Screen Wall Mount bracket involves the following steps: 1. Determine the Wall Mounting Location 2. Attach the Mounting Plate to the Wall 3. Attach the Mounting Brackets to the screen 4. Hang the screen on the Mounting Plate 5. -
Page 5: Attach The Mounting Plate To A Wood Stud Wall
Locate different studs that run continuously from floor to ceiling. The K2 series mounts require the wall studs to be 16 inches apart (16 inches on center). These mounts cannot be used if the wall studs are spaced farther apart. - Page 6 Determine Mounting Hole Locations 1. Using the level and measuring tape, make a mark 2 7/8” directly above and 2 7/8” directly below the Mounted screen Center Point. These marks are the Upper and Lower Center Points. 2. Using the level, draw a horizontal (side-to-side) line through the Upper Center Point that connects all stud centerlines.
-
Page 7: Attach The Mounting Plate To A Concrete Or Concrete Block Wall
Attach the Mounting Plate to a Concrete or Concrete Block Wall If you are mounting your screen on a drywall or plaster wall with wood studs, do not use this section. Go to “Attach the Mounting Plate to a Wood Stud Wall” on page 5. Warning: Attaching the wall mount to a brick wall could result in property damage or personal injury. - Page 8 Anchor Mounting Plate to Wall 1. Hold the Mounting Plate against the wall, then align the marked Mounting Plate slots with the Concrete Anchors in the wall. Using the ratchet and 7/16” socket, attach the Mounting Plate into the anchors with the six 1/4”...
-
Page 9: Attach The Screen Arms To The Screen
Attach the Screen Arms to the Screen 1. Unplug all cables from your screen, and then lay the screen screen-down on a flat, soft surface, such as a table covered with a blanket. Make sure that the surface is not abrasive, so you do not damage the screen or bezel. -
Page 10: Hang The Screen On The Mounting Plate
Hang the Screen on the Mounting Plate Warning: Make sure to “hook” the screen onto the mounting plate before you release the screen. Failure to do so could result in property damage or personal injury. 1. Using two or more people, pick up the screen and hang the screen and mount on the top edge of the wall plate. -
Page 11: Adjust The Screen Angle (K2-T-S And K3-T-S)
Adjust the Screen Angle (K2-T-S and K3-T-S) You can adjust the screen angle using the knobs located on the outside edge of each Screen Mounting Bracket. 1. Loosen the knobs on both Screen Arms by turning each knob counter-clockwise one full turn. 2. -
Page 12: Specifications
Notices Caution: This mounting bracket is intended for use only with the maximum weight indicated. Use with products heavier than the maximum weights indicated may result in instability and possibly cause injury. Specifications Model Tilt Range Screen Size Max. Load Weight K2-F-S 23-37 inches 175 lbs. - Page 13 www.k2mounts.com...
-
Page 14: K2Mounts Warranty
K2Mounts Warranty K2Mounts warrants to the original purchaser of its mounting brackets for the life of the bracket, that the bracket shall be free from defects in assembly, material, or workmanship and will repair or replace, at its sole discretion, a defective bracket free of charge, provided the bracket is returned to K2Mounts prepaid by purchaser. - Page 15 not protect against acts of God such as flood, earthquake, war, vandalism, theft, normal-use wear and tear, corrosion or abuse. Any damage caused by failure to observe instructions for installation, or product limitations specified in the product manual or product specification sheet, or mounting on unsuitable surfaces will not be covered by the K2Mounts warranty.
