Pro-Form 410 Ce Elliptical Manual page 12

13. Untie and discard the wire tie on the Wire
Harness (60).
While a second person holds the Console (33)
near the Upright (5), connect the wires on the
Console to the Wire Harness (60) and to the
Sensor Wires (34).
Insert the excess wire into the Console (33) or
into the Upright (5).
Tip: Avoid pinching the wires. Attach the
Console (33) to the Upright (5) with four M4 x
16mm Screws (93).
14. Attach the Front Upright Cover (25) by pressing
the tabs on the Front Upright Cover into the Rear
Upright Cover (24).
13
33
60
14
24
12
Avoid pinching
the wires
34
5
93
25
