In Windows Vista, deactivate protected mode on the Security tab under Internet Options. To play back live video images, an appropriate ActiveX must be installed on the computer. If necessary, install the Bosch Video Client. Bosch Security Systems Software manual...
If you do not connect, the camera may have reached its maximum number of connections. Depending on the device and network configuration, each camera can have up to 25 web browser connections, or up to 50 connections via Bosch Video Client or Bosch Video Management System. 1.2.1...
The LIVEPAGE is used to display the live video stream and control the camera. Recordings The RECORDINGS page is used for playing back recorded sequences. Settings The SETTINGS page is used to configure the camera and the application interface. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
The items shown depend on the settings on the LIVEPAGE Functions page. Figure 3.1 Livepage 3.1.1 Image selection Click a tab below the video image to display a camera image stream. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
Indicates a gap in the recorded video. Watermark flag Watermark is set on media item. Invalid watermark flag Indicates that the watermark is not valid. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
Click and hold for far focus; click and hold for near focus. Click and hold to close the iris; click and hold to open the iris. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
To view, filter and save these messages to a file, click in the top right-hand corner. To clear the log, click in the top right-hand corner of the relevant field. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
Click the recording icon again to stop recording. Play back saved video sequences using the Player from Bosch Security Systems. 3.1.8 Running recording program The hard drive icon below the camera images on the Livepage changes during an automatic recording.
When accessing the camera with a browser, the processor load and network information is available in the upper right of the window next to the Bosch logo. Move the mouse cursor over the icons to display numerical values. This information can help with problem solving or when fine tuning the device.
Click Export to FTP to send the current track to the FTP server. If required, change the times within the selected range. Note: The FTP server address is set on the Network/FTP Posting page. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
Jump to start of active sequence or to previous sequence Jump to start of the next video sequence in the list Slide control Select the playback speed using the speed regulator: Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
Page 22
Jump to the following bookmark Bookmarks are only valid while in the Recordings page; they are not saved with the sequences. All bookmarks are deleted when you leave the page. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
You can access all device parameters in this mode. Settings that affect the fundamental functionality of the device (such as firmware updates) can only be changed in this mode. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
All settings are backed up in the device memory so they are not lost even if the power fails. The exception is the time settings, which are lost after 1 hour without power if no central time server is selected. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
The advanced mode configuration menu contains all camera parameters that can be configured. Advanced Mode > General > Web Interface > Encoder > Camera > Recording > Alarm > Interfaces > Network > Service Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
When assigning passwords, always start from the highest authorization level, service, and use different passwords. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
Page 27
Re-enter the new password to ensure that there are no typing mistakes. The new password is only saved after clicking Set. Therefore, click Set immediately after entering and confirming the password, even if assigning a password at another level. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
Select Time server if the server uses the RFC 868 protocol. Note: It is important that the date/time is correct for recording. An incorrect date/time setting could prevent correct recording. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
Enter the appropriate subnet mask for the set IP address. Gateway address Enter the IP address of the gateway to establish a connection to a remote location in a different subnet. Otherwise, this field can remain empty (0.0.0.0). Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
This page provides general information on the hardware and firmware system, including version numbers. No items can be changed on this page but they can be copied for information purposes when troubleshooting. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
Initiator extension Add text to an initiator name to make identification easier in large iSCSI systems. This text is added to the initiator name, separated from it by a full stop. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
Re-enter the new password to ensure that there are no typing mistakes. The new password is only saved after clicking Set. Therefore, click Set immediately after entering and confirming the password, even if assigning a password at another level. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
Note: If a table is not created, there is no automatic switching. When editing the table, note that values occur in linked pairs (DST start and end dates). Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
It is recommended to select the SNTP server protocol. This protocol provides high accuracy and is required for special applications and future function extensions. Select Time server if the server uses the RFC 868 protocol. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
Custom option, or it can be set to Off for no overlay information. If the Custom option is selected, enter values in the X and Y position fields. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
Select On in the drop-down box for the transmitted video images to be watermarked. After activation, all images are marked with an icon. The icon indicates if the sequence (live or saved) has been manipulated. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
8.1.3 Device logo To replace the device name in the top-left part of the window, enter the path to a suitable image in this field. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
8.2.6 Show event log The event messages are displayed with the date and time in a field next to the video image. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
Path for JPEG and video files Enter the path for the storage location of individual images and video sequences saved from the Livepage. If necessary, click Browse to find a suitable folder. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
File for system log Enter the path for saving the system log here. If necessary, click Browse to find a suitable folder. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
Click Restore all defaults to restore the factory defaults for the camera. A confirmation screen appears. Allow 5 seconds for the camera to optimize the picture after a mode reset. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
– The motorised automatic back focus process runs. – The focus position, state and indicator are shown. If necessary, manually adjust the focus position with the slider. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
In Manual white balance mode, adjust the green gain from -50 to +50 to offset the factory white point alignment. It is only necessary to change the white point offset for special scene conditions. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
The values available depend on the value set for the ALC mode. 9.4.2 Day/night Auto - the camera switches the IR cut-off filter on and off depending on the scene illumination level. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
Page 45
A low (negative) value means that the camera switches to monochrome at a lower light level. A high (positive) value means that the camera switches to monochrome at a higher light level. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
9.5.2 Backlight Compensation Select On to capture details in high-contrast and extremely bright-dark conditions. 9.5.3 Contrast enhancement Select On to increase the contrast in low contrast conditions. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
Refer to Section 10.1 Encoder Profile, page 50 for more information on setting up the encoder profile. Refer to Section 10.2 Encoder Streams, page 53 for more information on setting up the encoder streams. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
80 kbps to 640 Kbps, depending on type of audio compression selected, for each connection. If you do not want any audio data to be transmitted, select Off. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
Encoder Streams page. The maximum frame rate and quality of the JPEG stream is also selected here. The streams and profiles for recording are selected on the Recording Profiles page. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
To change a profile, select it by clicking its tab, then change the parameters within that profile. If a setting outside the permitted range for a parameter is entered, the nearest valid value is substituted when the settings are saved. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
352 × 240 pixels (displayed as 432 x 240) – 480p 704 × 480 pixels (displayed as 854 x 480) Note: These resolutions are not used by a HD stream. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
51. The encoder delivers the best possible quality within this control range while maintaining the maximum bit rate. 10.1.9 Default Click Default to return the profile to the factory default values. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
Click Preview << to close the preview displays. Note: Deactivate the display of the video images if the performance of the computer is adversely affected by the decoding of the data stream. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
M-JPEG image quality from Low to High. Note: The JPEG resolution follows the highest resolution setting of either stream 1 or stream 2. The M-JPEG frame rate can vary depending on system loading. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
The VRM is an external program for configuring recording tasks for video servers. For further information, contact your local customer service at Bosch Security Systems. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
An SD card inserted in the camera can be used for local recording. If the SD card is password protected, enter the password into the Password field. The Storage overview field displays the local media. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
If older recordings are not allowed to be overwritten when the available memory is full, the recording in question is stopped. Specify limitations for overwriting old recordings by configuring the retention time. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
It is then no longer used for recordings. Click a storage medium in the Managed storage media list to select it. Click Remove below the list. The storage medium is deactivated and removed from the list. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
(for example alarms or VCA data) should also be recorded. Including metadata could make subsequent searches of recordings easier but it requires additional memory capacity. Without metadata, it is not possible to include video content analysis in recordings. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
Select a period for the Post-alarm time from the list box. Alarm stream Select the stream to be used for alarm recordings: – Stream 1 – Stream 2 – I-frames only AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
Page 61
Select the alarm type that is to trigger an alarm recording: – Alarm input – Motion/Audio alarm – Video loss alarm Select the Virtual alarm sensors that are to trigger a recording, via RCP+ commands or alarm scripts, for example. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
Enter the required retention time in hours or days for each recording track. Make sure that the retention time does not exceed the available recording capacity. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
Assign the defined holidays to the recording profile as described above. Delete user-defined holidays as follows: Click Delete in the Holidays tab. A new window opens. Click the date to be deleted. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
Recordings that are currently running are interrupted and the configuration can be modified. 11.4.5 Recording status The graphic indicates the recording activity. An animated graphic is displayed when recording is taking place. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
Camera Browser Interface Recording | en 11.5 Recording Status Details of the recording status are displayed here for information. These settings cannot be changed. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
If the remote station is password protected, enter the password here. Only ten passwords can be defined here. Define a general password if more than ten connections are required, for AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
Alarm | en example, when connections are initiated by a controlling system such as the Bosch Video Client or the Bosch Video Management System. The camera connects to all remote stations protected by the same general password. To define a...
Select On to automatically re-established a connection to one of the previously specified IP addresses after each reboot, connection breakdown, or network failure. 12.1.11 Audio Select On to transmit the audio stream with an alarm connection. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
This can lead to impairment of the VCA system. Observe the processor load and optimize the encoder settings or the VCA settings if necessary, or turn off VCA completely. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
Select On for the device to generate audio alarms. 12.3.2 Name The name makes it easier to identify the alarm in extensive video monitoring systems, for example with the Bosch Video Client and the Bosch Video Management System. Enter a unique and clear name here. 12.3.3 Signal Ranges Exclude particular signal ranges in order to avoid false alarms.
Obtain information on operating your mobile phone from your mobile phone provider. 12.4.6 Attach JPEG from camera Check the box to specify that JPEG images are sent from the camera. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
This makes it easier to identify the origin of the e-mail. 12.4.9 Test e-mail Click Send Now to test the e-mail function. An alarm e-mail is immediately created and sent. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
If the transfer was successful, the message Script successfully parsed. is displayed over the text field. If it was not successful, an error message is displayed with further information. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
In the VCA configuration drop-down list, select Silent MOTION+. No parameters can be changed for this selection. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
No further alarm is triggered during the aggregation time. The post-alarm time set for alarm recordings only starts once the aggregation time has expired. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
Note: Additional analysis algorithms with comprehensive functions, such as IVMD and IVA, are available from Bosch Security Systems. 13.2.3 Motion detector Motion detection is available for the Motion+ analysis type. For the detector to function, the following conditions must be met: –...
Page 77
Right-click any fields to deactivate. Click OK to save the configuration. Click the close button (X) in the window title bar to close the window without saving the changes. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
Global change Activate this function if the global change, as set with the Global change slide control, should trigger an alarm. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
Page 79
The area selected in the reference image should contain a prominent structure. If this structure is concealed or moved, the reference check triggers an alarm. If the selected area is too homogenous, so that concealing and moving the structure Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
Page 80
Right-click any fields to deactivate. Click OK to save the configuration. Click the close button (X) in the window title bar to close the window without saving the changes. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
These will later be displayed as a single entry in the table. Click OK to accept the selection. The window closes. Assign the individual holidays to the VCA profiles, as described above. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
Page 82
Click Delete. A new window opens. Click the date to delete. Click OK. The item is deleted from the table and the window closes. The process must be repeated for deleting additional days. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
A delay period may be useful in avoiding false alarms or frequent triggering. During the delay period, the Silent MOTION+ configuration is always enabled. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
Closed if the relay is to operate as an N.C. contact. 14.2.2 Operating mode Select the way the relay works. 14.2.3 Relay follows Select the event that triggers the relay. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
Stop bits Select the number of stop bits per character. 14.3.6 Parity check Select the type of parity check. 14.3.7 Interface mode Select the desired protocol for the serial interface. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
If a DHCP server is employed in the network for the dynamic assignment of IP addresses, activate acceptance of IP addresses automatically assigned to the device. Certain applications (VIDOS, Bosch Video Management System, Archive Player, Configuration Manager) use the IP address for the unique assignment of the device. If using these...
The camera uses the TLS 1.0 protocol. Ensure that the browser has been configured to support this protocol. Also ensure that Java application support is activated (in the Java Plug-in Control Panel of the Windows Control Panel). Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
The potential value depends on the network structure. A higher value is only useful if the iSCSI system is located in the same subnet as the camera. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
To transfer the IP address of the device, click the Register button. 15.1.19 Status The status of the DynDNS function is displayed here for information purposes; these settings cannot be changed. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
On to activate authentication to communicate with the device. Enter the user name that the Radius server uses for the camera in the Identity field. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
RTSP port If necessary, select a different port for the exchange of the RTSP data from the list. The standard RTSP port is 554. Select Off to deactivate the RTSP function. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
With a 0.0.0.0 setting, the encoder for the stream operates in multi-unicast mode (copying of data stream in device). The camera supports multi-unicast connections for up to five simultaneously connected receivers. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
A value can be entered to specify how long the multicast data packets are active on the network. If multicast is to be run via a router, the value must be greater than 1. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
Enter your login name for the FTP server. FTP server password Enter the password that gives access to the FTP server. Path on FTP server Enter an exact path to post the images on the FTP server. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
Camera Browser Interface Network | en 15.5 Encryption If an encryption license is installed, this submenu gives access to the encryption parameters. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
The latest firmware can be obtained from your customer service center or from the Bosch Security Systems download area. To update the firmware: First, store the firmware file on your hard disk.
Enter the full path of the file to upload or click Browse to locate the file. Click Upload to start the file transfer. Bosch Security Systems Software manual AM18-Q0605 | v5.0 | 2011.07...
Keep this information at hand when seeking technical support. Select the text on this page with a mouse and copy it so that it can be pasted into an e-mail if required. AM18-Q0605 | v5.0 | 2011.07 Software manual Bosch Security Systems...
