  • Page 1 VideoJet X10 SN Network Video Server Installation and Operating Manual...
  • Page 2 VideoJet X10 SN...

  • Page 3: Table Of Contents

    VideoJet X10 SN Table of Contents | en Table of Contents Preface About this Manual Conventions in this Manual Intended Use EU Directives Rating Plate Safety Information Electric Shock Hazard Installation and Operation Maintenance and Repair Product Description Scope of Delivery...
  • Page 4 | Table of Contents VideoJet X10 SN 5.19 Advanced Mode: Encoder Profile 5.20 Advanced Mode: Audio 5.21 Advanced Mode: Storage Management 5.22 Advanced Mode: Remote Video Device 5.23 Advanced Mode: Recording Profiles 5.24 Advanced Mode: Retention Time 5.25 Advanced Mode: Recording Scheduler 5.26...
  • Page 5 VideoJet X10 SN Table of Contents | en Malfunctions with iSCSI Connections LEDs Processor Load Network Connection Serial Interface Terminal Block Communication with Terminal Program 8.10 Copyrights Specifications Unit Protocols/Standards Glossary Index Bosch Security Systems Installation and Operating Manual DOC | V4.0 | 2009.06...
  • Page 6 | Table of Contents VideoJet X10 SN DOC | V4.0 | 2009.06 Installation and Operating Manual Bosch Security Systems...

  • Page 7: Preface

    Intended Use The VideoJet X10 SN network video server transfers video, audio and control signals over data networks (Ethernet LAN, Internet). There are various memory options for recording the images captured by the connected camera. The unit is intended for use with CCTV systems.

  • Page 8: Eu Directives

    | Preface VideoJet X10 SN EU Directives The VideoJet X10 SN network video server complies with the requirements of EU Directives 89/336 (Electromagnetic Compatibility) and 73/23, amended by 93/68 (Low Voltage Directive). Rating Plate For exact identification, the model name and serial number are inscribed on the bottom of the housing.

  • Page 9: Safety Information

    Maintenance and Repair – Never open the housing of the VideoJet X10 SN. The unit does not contain any user- serviceable parts. – Never open the housing of the power supply unit. The power supply unit does not contain any user-serviceable parts.
  • Page 10 | Safety Information VideoJet X10 SN DOC | V4.0 | 2009.06 Installation and Operating Manual Bosch Security Systems...

  • Page 11: Product Description

    Adobe Acrobat Reader NOTICE! Check that the delivery is complete and in perfect condition. Arrange for the unit to be checked by Bosch Security Systems if you find any damage. Bosch Security Systems Installation and Operating Manual DOC | V4.0 | 2009.06...

  • Page 12: System Requirements

    Additional Operational Requirements – Microsoft Internet Explorer (version 6.0 or higher) – Receiver software, for example VIDOS (version 3.11 or higher) or Bosch Video Management System (version 2.02 or higher) – MPEG-4 compatible hardware decoder from Bosch Security Systems (for example VIP XD) as a receiver and connected video monitor –...

  • Page 13: Overview Of Functions

    Two units, for example a VideoJet X10 SN as a sender and a VIP XD as a receiver, can create a standalone system for data transfer without a PC. Video images from a single sender can be received simultaneously on multiple receivers.
  • Page 14 Recordings Various local memory options enable the VideoJet X10 SN to be used as a digital VCR. The VideoJet X10 SN supports ANR technology, which guarantees seamless recording without gaps via VIDOS-NVR, even during network failures.
  • Page 15 VideoJet X10 SN Product Description | en Summary The VideoJet X10 SN provides the following main functions: – Video and data transmission over IP data networks – Dual Streaming function for the encoder for simultaneous encoding with two individually definable profiles –...

  • Page 16: Connections On The Front Panel

    | Product Description VideoJet X10 SN Connections on the Front Panel USB interface for future expansion of functions Video In video input BNC socket for connecting the video source Audio In audio line input 3.5 mm stereo socket for connecting an audio line input signal Audio Out audio line output 3.5 mm stereo socket for connecting an audio line output signal...

  • Page 17: Connections On The Rear Panel

    VideoJet X10 SN Product Description | en Connections on the Rear Panel ETH RJ45 socket for connecting to an Ethernet LAN (local network), 10/100 MBit Base-T ETH LED lights up yellow when the unit is connected to the network via ETH...
  • Page 18 | Product Description VideoJet X10 SN DOC | V4.0 | 2009.06 Installation and Operating Manual Bosch Security Systems...

  • Page 19: Installation

    The ambient temperature must be between 0 and +50 °C (+32 and +122 °F). The relative humidity must not exceed 95%. The VideoJet X10 SN generates heat during operation, so you should ensure that there is adequate ventilation and enough clearance between the unit and heat-sensitive objects or equipment.

  • Page 20: Connections

    Connections Camera You can connect a video source to the VideoJet X10 SN. Any cameras and other video sources that produce a standard PAL or NTSC signal are suitable. Connect the camera or another video source to the BNC Video In socket using a video cable (75 Ohm, BNC plug).
  • Page 21 To remove the CF card, simply pull it out. Data Interface The bidirectional data interface is used to control units connected to the VideoJet X10 SN, such as a dome camera with a motorized lens. The connection supports the RS-232, RS-422 and RS-485 transmission standards.
  • Page 22 Remote Indication of the Connection Status When the VideoJet X10 SN is connected to a video, the Connect LED on the front panel of the unit flashes. The LED also provides information on the operational state of the unit and signals a unit defect (see Section 8.4 LEDs, page 107).
  • Page 23 Installation | en Backup Power Supply If the VideoJet X10 SN does not have a permanent power supply, it may be necessary to supply the internal clock separately. To do this, you can connect the VideoJet X10 SN directly to a battery via the BP and GND contacts. The correct time is crucial for evaluating local recordings.

  • Page 24: Power On/Power Off

    The VideoJet X10 SN does not have a power switch. Power is supplied via a separate unit. Connect the VideoJet X10 SN to the power supply unit and plug this into the mains. The unit is now ready for use. The VideoJet X10 SN does not come supplied with a power supply unit.
  • Page 25 You can start the configuration if a VideoJet X10 SN is shown in the list in the left section of the window. To do this, right-click the entry for the unit.
  • Page 26 | Installation VideoJet X10 SN DOC | V4.0 | 2009.06 Installation and Operating Manual Bosch Security Systems...

  • Page 27: Configuration Using A Web Browser

    Configuration Using a Web Browser Connecting The integrated HTTP server in the VideoJet X10 SN provides you with the option to configure the unit over the network with a Web browser. This option is an alternative to configuration using the Configuration Manager program and is considerably richer in function and more convenient than configuration using the terminal program.
  • Page 28 VideoJet X10 SN Establishing the Connection Before you can operate the VideoJet X10 SN within your network, it must have a valid IP address for your network and a compatible subnet mask. The following default address is preset at the factory: 192.168.0.1 Start the Web browser.

  • Page 29: Configuration Menu

    The settings in the advanced mode should only be processed or modified by expert users or system support personnel. All settings are backed up in the VideoJet X10 SN memory so they are not lost even if the power fails.
  • Page 30 | Configuration Using a Web Browser VideoJet X10 SN Starting Configuration Click the SETTINGS link in the upper section of the window. The Web browser opens a new page with the configuration menu. Navigation Click one of the menu items in the left window margin. The corresponding submenu is displayed.

  • Page 31: Basic Mode: Unit Access

    Basic Mode: Unit Access Device name You can give the VideoJet X10 SN a name to make it easier to identify. The name makes the task of administering multiple units in larger video monitoring systems easier, for example using the VIDOS or Bosch Video Management System programs.

  • Page 32: Basic Mode: Date/Time

    VideoJet X10 SN. Time server IP address The VideoJet X10 SN can receive the time signal from a time server using various time server protocols, and then use it to set the internal clock. The unit polls the time signal automatically once every minute.

  • Page 33: Basic Mode: Network

    MAC address, and must be appropriately set up so that, once an IP address is assigned, it is retained each time the system is rebooted. IP address Enter the desired IP address for the VideoJet X10 SN in this field. The IP address must be valid for the network. Subnet mask Enter the appropriate subnet mask for the selected IP address here.

  • Page 34: Basic Mode: Encoder Profile

    | Configuration Using a Web Browser VideoJet X10 SN Basic Mode: Encoder Profile Active profile You can select a profile for encoding the video signal. You can use this to adapt the video data transmission to the operating environment (for example network structure, bandwidth, data load).

  • Page 35: Basic Mode: Audio

    CF cards (see Section CF Slot, page 20) are the ideal solution for shorter storage times. if the VideoJet X10 SN has a USB hard drive, this is suitable for longer, local recordings. For long-term, authoritative images, it is essential that you use an appropriately sized iSCSI system.

  • Page 36: Basic Mode: System Overview

    Device name You can give the VideoJet X10 SN a name to make it easier to identify. The name makes the task of administering multiple units in larger video monitoring systems easier, for example using the VIDOS or Bosch Video Management System programs.
  • Page 37 Camera 1 parameters. The window will close. Initiator extension You can attach your own text to the initiator name of the VideoJet X10 SN to make the unit easier to identify in large iSCSI systems. This text is added to the initiator name, separated from it by a full stop.

  • Page 38: Advanced Mode: Password

    VideoJet X10 SN 5.11 Advanced Mode: Password A VideoJet X10 SN is generally protected by a password to prevent unauthorized access to the unit. You can use different authorization levels to limit access. NOTICE! Proper password protection is only guaranteed when all higher authorization levels are also protected with a password.

  • Page 39: Advanced Mode: Date/Time

    – it is added automatically. Enter the current time or click the Sync to PC button to copy your computer's system time to the VideoJet X10 SN. Unit time zone Select the time zone in which your system is located.

  • Page 40: Advanced Mode: Display Stamping

    Now click the OK button to save and activate the table. Time server IP address The VideoJet X10 SN can receive the time signal from a time server using various time server protocols, and then use it to set the internal clock. The unit polls the time signal automatically once every minute.

  • Page 41: Advanced Mode: Appearance

    Internet/Intranet). When accessing via the Internet/Intranet, ensure that a connection is always available to display the image. The image file is not stored in the VideoJet X10 SN. Website language Select the language for the user interface here.

  • Page 42: Advanced Mode: Livepage Functions

    | Configuration Using a Web Browser VideoJet X10 SN NOTICE! There are always two languages to choose from: English and another language. If the language you require is not available for selection, you can download the current firmware with another language combination from the website www.boschsecurity.com.
  • Page 43 Bilinx control Next to the field for view control at the top left of the LIVEPAGE, an additional field is displayed for the special Bosch Security Systems Bilinx control. Lease time (s) The lease time in seconds determines the time beyond which a different user is authorized to control the camera after no further control signals are received from the current user.

  • Page 44: Advanced Mode: Logging

    You can activate the 75 Ohm terminating resistance for the video input of the VideoJet X10 SN. The terminating resistance must be deactivated for the video signal to be looped through. Every video input is closed at the time of delivery.

  • Page 45: Advanced Mode: Picture Settings

    VideoJet X10 SN Configuration Using a Web Browser | en for the internal PLL as a result of jitter effects caused by the mechanical components of a VCR. NOTICE! In some cases, selecting the VCR option can lead to an improvement in the video image even with a camera connected.

  • Page 46: Advanced Mode: Encoder Profile

    You can adapt the video data transmission to the operating environment (for example network structure, bandwidth, data load). To this end, the VideoJet X10 SN simultaneously generates two data streams (Dual Streaming), which compression settings you can select individually, for example one setting for transmissions to the Internet and one for LAN connections.
  • Page 47 VideoJet X10 SN Configuration Using a Web Browser | en – High resolution (4CIF/D1) High resolution for high bandwidth connections, resolution 704 × 576/480 pixels – For DSL connections with 500 kbps, resolution 352 × 288/240 pixels – ISDN (2B) For ISDN connections via two B-channels, resolution 352 ×...
  • Page 48 VideoJet X10 SN Target data rate You can limit the data rate for the VideoJet X10 SN to optimize utilization of the bandwidth in your network. The target data rate should be set according to the desired picture quality for typical scenes with no excessive motion.

  • Page 49: Advanced Mode: Audio

    VideoJet X10 SN Configuration Using a Web Browser | en Video quality This setting allows you to adjust the image quality. The Auto option automatically adjusts to the optimum combination of movement and image definition (focus). Alternatively, you can use the slide control to select a value between 1 and 100. A value of 100 results in a very high refresh rate and lower image quality.

  • Page 50: Advanced Mode: Storage Management

    VideoJet X10 SN has a USB hard drive, this is suitable for longer, local recordings. For long-term, authoritative images, it is essential that you use an appropriately sized iSCSI system.
  • Page 51 Each storage medium can only be associated with one user. If a storage medium is already being used by another user, you can decouple the user and connect the drive with the VideoJet X10 SN. Before decoupling, make absolutely sure that the previous user no longer needs the storage medium.

  • Page 52: Advanced Mode: Remote Video Device

    5.22 Advanced Mode: Remote Video Device You can allow a remote video device to use the VideoJet X10 SN storage media. This means you can record video images from a camera that does not have its own storage media, for example.

  • Page 53: Advanced Mode: Recording Profiles

    VideoJet X10 SN Configuration Using a Web Browser | en IP Address Enter the IP address for the remote video device. If you do not know the IP address, click the Network Scan button. The search for possible devices in the network is started. A small arrow is then displayed next to the IP Address field.
  • Page 54 Section 5.35 Advanced Mode: Alarm Inputs, page 73). The numbering of the checkboxes for the alarm inputs corresponds to the labeling of the alarm inputs on the VideoJet X10 SN. Virtual alarm Here you can select the virtual alarm sensors that are to trigger a recording, via RCP+ commands or alarm scripts, for example.

  • Page 55: Advanced Mode: Retention Time

    VideoJet X10 SN Configuration Using a Web Browser | en NOTICE! For more information, please see the Alarm Task Script Language document and the RCP+ documentation. These documents can be found on the product CD supplied. Recording includes You can specify whether, in addition to video data, audio data and metadata (for example alarms, VCA data and serial data) should also be recorded.

  • Page 56: Advanced Mode: Recording Scheduler

    | Configuration Using a Web Browser VideoJet X10 SN 5.25 Advanced Mode: Recording Scheduler The recording scheduler allows you to link the created recording profiles with the days and times at which the camera's images are to be recorded in the event of an alarm.
  • Page 57 Click the Stop button to deactivate the recording scheduler. Running recordings are interrupted and the configuration can be changed. Recording status The graphic indicates the recording activity of the VideoJet X10 SN. You will see an animated graphic while recording is taking place. Bosch Security Systems Installation and Operating Manual DOC | V4.0 | 2009.06...

  • Page 58: Advanced Mode: Recording Status

    5.27 Advanced Mode: Alarm Connections You can select how the VideoJet X10 SN responds to an alarm. In the event of an alarm, the unit can automatically connect to a pre-defined IP address. You can enter up to ten IP addresses to which the VideoJet X10 SN will connect in sequence in the event of an alarm, until a connection is made.
  • Page 59 VIDOS or Bosch Video Management System, you can store a general password here. The VideoJet X10 SN can use this general password to connect to all remote stations protected with the same password. In this case, proceed as follows: Select 10 from the Number of destination IP address list field.
  • Page 60 Please note that the SSL encryption must be activated and configured at both ends of a connection. This requires the appropriate certificates to be uploaded onto the VideoJet X10 SN (see Section Maintenance log, page 85). You can activate and configure encryption of the media data (video, audio and metadata) on the Encryption page (see Section 5.42 Advanced Mode: Encryption, page 83).

  • Page 61: Advanced Mode: Vca

    5.28 Advanced Mode: VCA The VideoJet X10 SN contains an integrated video content analysis (VCA), which can detect and analyze changes in the signal on the basis of image processing. Such changes can be due to movements in the camera's field of view.

  • Page 62: Advanced Mode: Vca Profiles

    | Configuration Using a Web Browser VideoJet X10 SN 5.29 Advanced Mode: VCA Profiles You can configure two profiles with different VCA configurations. You can save profiles on your computer's hard drive and load saved profiles from there. This can be useful if you want to test a number of different configurations.
  • Page 63 NOTICE! Additional analysis algorithms with comprehensive functions such as IVMD and IVA are available from Bosch Security Systems. If you select one of these algorithms, you can set the corresponding parameters here directly. You can find information on this in the relevant documents on the product CD supplied.
  • Page 64 | Configuration Using a Web Browser VideoJet X10 SN Sensitivity (MOTION+ only) The basic sensitivity of the motion detector can be adjusted for the environmental conditions to which the camera is subject. The sensor reacts to variations in the brightness of the video image. The darker the observation area, the higher the value that must be selected.
  • Page 65 VideoJet X10 SN Configuration Using a Web Browser | en Global change You can set how large the global change in the video image must be for an alarm to be triggered. This setting is independent of the sensor fields selected under Select Area. Set a high value if fewer sensor fields need to change to trigger an alarm.

  • Page 66: Advanced Mode: Vca Scheduled

    | Configuration Using a Web Browser VideoJet X10 SN Left-click the fields to be activated. Activated fields are marked yellow. If necessary, click Select All to select the entire video frame for monitoring. Right-click any fields you wish to deactivate.
  • Page 67 VideoJet X10 SN Configuration Using a Web Browser | en Click the profile you want to link in the Time periods field. Click in a field in the table, hold down the mouse button and drag the cursor over all the periods to be assigned to the selected profile.

  • Page 68: Advanced Mode: Vca Event Triggered

    | Configuration Using a Web Browser VideoJet X10 SN 5.31 Advanced Mode: VCA Event Triggered This configuration allows you stipulate that the video content analysis is only to be activated when triggered by an event. As long as no trigger is activated, the Silent MOTION+ configuration in which metadata is created is active;...

  • Page 69: Advanced Mode: Audio Alarm

    5.32 Advanced Mode: Audio Alarm The VideoJet X10 SN can create alarms on the basis of audio signals. You can configure signal strengths and frequency ranges in such a way that false alarms, for example due to machine noise or background noise, are avoided.

  • Page 70: Advanced Mode: Alarm E-Mail

    VideoJet X10 SN Name The name makes it easier to identify the alarm in extensive video monitoring systems, for example with the VIDOS and Bosch Video Management System programs. Enter a unique and clear name here. CAUTION! Do not use any special characters, for example &, in the name.
  • Page 71 VideoJet X10 SN Configuration Using a Web Browser | en Mail server IP address Enter the IP address of a mail server that operates on the SMTP standard (Simple Mail Transfer Protocol). Outgoing e-mails are sent to the mail server via the address you entered.

  • Page 72: Advanced Mode: Alarm Task Editor

    | Configuration Using a Web Browser VideoJet X10 SN 5.34 Advanced Mode: Alarm Task Editor CAUTION! Editing scripts on this page overwrites all settings and entries on the other alarm pages. This procedure cannot be reversed. In order to edit this page, you must have programming knowledge and be familiar with the information in the Alarm Task Script Language document.

  • Page 73: Advanced Mode: Alarm Inputs

    Configuration Using a Web Browser | en 5.35 Advanced Mode: Alarm Inputs You can configure the alarm inputs of the VideoJet X10 SN. Alarm input Select Active high if the alarm is to be triggered when the contact closes. Select Active low if the alarm is to be triggered when the contact opens.
  • Page 74 | Configuration Using a Web Browser VideoJet X10 SN Operating mode Select an operating mode for the relay. For example, if you want an alarm-activated lamp to stay on after the alarm ends, select Bistable. If you wish an alarm-activated siren to sound for ten seconds, for example, select 10 s.

  • Page 75: Advanced Mode: Com1

    NOTICE! If the VideoJet X10 SN is working in multicast mode (see Section 5.40 Advanced Mode: Multicasting, page 81), the first remote location to establish a video connection to the unit is also assigned the transparent data connection. However, after about 15 seconds of inactivity the data connection is automatically terminated and another remote location can exchange transparent data with the unit.

  • Page 76: Advanced Mode: Network

    5.38 Advanced Mode: Network The settings on this page are used to integrate the VideoJet X10 SN into an existing network. Some changes only take effect after the unit is rebooted. In this case, the Set button changes to Set and Reboot.
  • Page 77 MAC address, and must be appropriately set up so that, once an IP address is assigned, it is retained each time the system is rebooted. IP address Enter the desired IP address for the VideoJet X10 SN in this field. The IP address must be valid for the network. Subnet mask Enter the appropriate subnet mask for the selected IP address here.
  • Page 78 You can specify a higher MSS value for a connection to the iSCSI system than for the other data traffic via the network. The potential value depends on the network structure. A higher value is only useful if the iSCSI system is located in the same subnet as the VideoJet X10 SN. Enable DynDNS DynDNS.org is a DNS hosting service that stores IP addresses in a database ready for use.

  • Page 79: Advanced Mode: Advanced

    Only use this function when necessary and no more than once a day, to avoid the possibility of being blocked by the service provider. To transfer the IP address of the VideoJet X10 SN, click the Register button. Status The status of the DynDNS function is displayed here for information purposes.
  • Page 80 The RADIUS server must also contain the corresponding data. To configure the unit, you must connect the VideoJet X10 SN directly to a computer using a network cable. This is because communication via the network is not enabled until the Identity and Password parameters have been set and successfully authenticated.

  • Page 81: Advanced Mode: Multicasting

    In addition to a 1:1 connection between an encoder and a single receiver (unicast), the VideoJet X10 SN can enable multiple receivers to receive the video signal from an encoder simultaneously. The device either duplicates the data stream itself and then distributes it to multiple receivers (Multi-unicast) or it sends a single data stream to the network, where the data stream is simultaneously distributed to multiple receivers in a defined group (Multicast).

  • Page 82: Advanced Mode: Jpeg Posting

    | Configuration Using a Web Browser VideoJet X10 SN NOTICE! Duplication of data places a heavy demand on the unit and can lead to impairment of the image quality under certain circumstances. Port Assign a different port to each data stream if there are simultaneous data streams at the same multicast address.

  • Page 83: Advanced Mode: Encryption

    VideoJet X10 SN Configuration Using a Web Browser | en File name You can select how file names will be created for the individual images that are transmitted. – Overwrite The same file name is always used and any existing file will be overwritten with the current file.

  • Page 84: Advanced Mode: Maintenance

    Advanced Mode: Maintenance Firmware The VideoJet X10 SN is designed in such a way that its functions and parameters can be updated with firmware. To do this, transfer the current firmware package to the unit via the selected network. It will then be automatically installed there.
  • Page 85 To be able to work with an SSL encrypted data connection, both ends of a connection must hold the relevant certificates. You can upload the SSL certificate, comprising one or multiple files, onto the VideoJet X10 SN. If you wish to upload multiple files onto the VideoJet X10 SN, you must select them consecutively. NOTICE! The certificate must be created in the format *.pem so that it can be accepted by the unit.

  • Page 86: Advanced Mode: Licenses

    | Configuration Using a Web Browser VideoJet X10 SN 5.44 Advanced Mode: Licenses You can enter the activation key to release additional functions or software modules. NOTICE! The activation key cannot be deactivated again and is not transferable to other units.

  • Page 87: Function Test

    The VideoJet X10 SN offers a variety of configuration options. You should therefore check that it is functioning correctly after installation and configuration. The function test is the only way to ensure that the VideoJet X10 SN operates as expected in the event of an alarm.
  • Page 88 | Configuration Using a Web Browser VideoJet X10 SN DOC | V4.0 | 2009.06 Installation and Operating Manual Bosch Security Systems...

  • Page 89: Operation

    Operation | en Operation Operation with Microsoft Internet Explorer A computer with Microsoft Internet Explorer (version 6.0 or higher) can receive live images from the VideoJet X10 SN, control cameras or other peripherals and replay stored video sequences. System Requirements –...
  • Page 90 VideoJet X10 SN Establishing the Connection Before you can operate the VideoJet X10 SN within your network, it must have a valid IP address for your network and a compatible subnet mask. The following default address is preset at the factory: 192.168.0.1 Start the Web browser.

  • Page 91: The Livepage

    If you do not connect, the unit may have reached its maximum number of connections. Depending on the unit and network configuration, each VideoJet X10 SN can have up to 25 Web browser connections or up to 50 connections via VIDOS or Bosch Video Management System.
  • Page 92 Control options for peripherals (for example a pan/tilt head or dome camera) depend on the type of unit installed and on the configuration of the VideoJet X10 SN. If a controllable unit is configured and connected to the VideoJet X10 SN, the controls for the peripheral are displayed next to the video image.
  • Page 93 Depending on the configuration, the VideoJet X10 SN can send and receive audio signals. All users who are connected by browsers receive the audio signals sent by the VideoJet X10 SN. Audio signals can only be sent to the VideoJet X10 SN by the user who connects to the unit first.

  • Page 94: Saving Snapshots

    Click the icon to start recording. The storage location depends on the configuration of the VideoJet X10 SN (see Section Path for JPEG and MPEG files, page 44). A red dot in the icon indicates that recording is in progress.

  • Page 95: The Recordings Page

    VideoJet X10 SN Operation | en The RECORDINGS Page The RECORDINGS page for playing back recorded video sequences can be accessed from the LIVEPAGE and from the SETTINGS menu. The RECORDINGS link is only visible if a storage medium has been selected (see Section 5.21 Advanced Mode: Storage Management, page 50).
  • Page 96 | Operation VideoJet X10 SN The time bar offers various options for navigation. Red bars indicate the points in time where alarms were triggered. Drag the green arrow to navigate to these points quickly. You can change the time interval by clicking the zoom keys (magnifying glass icons). The display can span a range from two months to a few seconds.

  • Page 97: Installing The Player

    Configuration Manager program. Installing the Player You can play back saved video sequences using the Player from Bosch Security Systems, which can be installed from the product CD supplied (see Section 3.1 Scope of Delivery, page 11).

  • Page 98: Hardware Connections Between Video Servers

    Hardware Connections Between Video Servers A VideoJet X10 SN with a camera connected to it can be used as a sender and a compatible MPEG-4 hardware decoder (such as the VIP XD) with a connected monitor as a receiver using an Ethernet network connection.
  • Page 99 VideoJet X10 SN Operation | en Connecting with a Terminal Program Various requirements must be met in order to operate with a terminal program (see Section 8.9 Communication with Terminal Program, page 110). Start the terminal program and enter the command 1 in the main menu to switch to the IP menu.

  • Page 100: Operation Using Software Decoders

    The VideoJet X10 SN video server is also designed for use with the DiBos 8 digital recorder. DiBos 8 records up to 32 video and audio streams and is available as IP software or hybrid DVR with additional analog camera and audio inputs.

  • Page 101: Maintenance And Upgrades

    Connect LED flashes red (see Section 3.4 Connections on the Front Panel, page 16). All settings will revert to their defaults. Change the IP address of the VideoJet X10 SN if necessary. Configure the unit to meet your requirements.

  • Page 102: Repairs

    (electrical engineers or network technology specialists). In case of doubt, contact your dealer's technical service center. Transfer and Disposal The VideoJet X10 SN should only be passed on together with this installation and operating manual. Your Bosch product is designed and manufactured with high-quality materials and components which can be recycled and reused.

  • Page 103: Appendix

    If you are unable to resolve a malfunction, please contact your supplier or systems integrator, or go directly to Bosch Security Systems Customer Service. You can view a range of information about your unit version on the System Overview page (see Section 5.45 Advanced Mode: System Overview, page 86).

  • Page 104: General Malfunctions

    104 en | Appendix VideoJet X10 SN General Malfunctions Malfunction Possible causes Recommended solution No connection between Incorrect cable connections. Check all cables, plugs, the unit and terminal contacts, terminals and program. connections. The computer's serial interface Check the other serial interface.
  • Page 105 VideoJet X10 SN Appendix | en 105 Malfunction Possible causes Recommended solution The unit does not report Alarm source is not selected. Select possible alarm sources on an alarm. the Alarm Inputs configuration page. No alarm response specified. Specify the desired alarm...

  • Page 106: Malfunctions With Iscsi Connections

    106 en | Appendix VideoJet X10 SN Malfunctions with iSCSI Connections Malfunction Possible causes Recommended solution After connecting to the Incorrect LUN mapping during Check the iSCSI system iSCSI destination, no iSCSI system configuration. configuration and reconnect. LUNs are displayed.

  • Page 107: Leds

    VideoJet X10 SN Appendix | en 107 LEDs The VideoJet X10 SN network video server has a number of LEDs on its front and rear panels that show the operating status and can give indications of possible malfunctions: ETH LED Does not light up: No network connection.

  • Page 108: Processor Load

    VideoJet X10 SN Processor Load If the VideoJet X10 SN is accessed via the Web browser, you will see the processor load indicator in the top right of the window next to the manufacturer's logo. You can obtain additional information to help you when troubleshooting or fine tuning the unit.

  • Page 109: Terminal Block

    VideoJet X10 SN Appendix | en 109 Terminal Block The terminal block has several contacts for: – 4 alarm inputs – 4 relay outputs – Serial data transmission Pin Assignment The pin assignment of the serial interface depends on the interface mode used (see Section 5.37 Advanced Mode: COM1, page 75).

  • Page 110: Communication With Terminal Program

    Communication with Terminal Program Data Terminal If a VideoJet X10 SN cannot be found in the network or the connection to the network is interrupted, you can connect a data terminal to the VideoJet X10 SN for initial setup and setting of important parameters.
  • Page 111 Appendix | en 111 Assigning an IP Address Before you can operate a VideoJet X10 SN in your network you must first assign it an IP address that is valid for your network. The following default address is preset at the factory: 192.168.0.1 Start a terminal program such as HyperTerminal.

  • Page 112: Copyrights

    112 en | Appendix VideoJet X10 SN 8.10 Copyrights The firmware 4.0 uses the fonts "Adobe-Helvetica-Bold-R-Normal--24-240-75-75-P-138- ISO10646-1" and "Adobe-Helvetica-Bold-R-Normal--12-120-75-75-P-70-ISO10646-1" under the following copyright: Copyright 1984-1989, 1994 Adobe Systems Incorporated. Copyright 1988, 1994 Digital Equipment Corporation. Permission to use, copy, modify, distribute and sell this software and its documentation for...

  • Page 113: Specifications

    VideoJet X10 SN Specifications | en 113 Specifications Unit Operating voltage 10 to 30 V DC, power supply via external unit Power consumption Approx. 11 W with full equipment LAN interface 1 × Ethernet 10/100 Base-T, automatic adjustment, half/full duplex, RJ45 Data interfaces 1 ×...

  • Page 114: Protocols/Standards

    114 en | Specifications VideoJet X10 SN Protocols/Standards Video standards PAL, NTSC Video coding protocols H.264 Baseline Profile, MPEG-4, M-JPEG, JPEG Video data rate 9.6 kbps to 6 Mbps Image resolutions (PAL/NTSC) 704 × 576/480 pixels (4CIF/D1) 704 × 288/240 pixels (2CIF) 464 ×...

  • Page 115: Glossary

    Unit of measurement for the speed of data transmission Bits per second, the actual data rate BVIP Bosch Video over IP unit CompactFlash; interface standard, for digital storage media amongst other things. Used in computers in the form of CF cards, digital cameras and Personal Digital Assistants (PDA).
  • Page 116 116 en | Glossary VideoJet X10 SN HTTP Hypertext Transfer Protocol: protocol for transmitting data over a network HTTPS Hypertext Transfer Protocol Secure: encrypts and authenticates communication between Web server and browser ICMP Internet Control Message Protocol Identification: a machine readable character string...
  • Page 117 VideoJet X10 SN Glossary | en 117 MPEG-4 A further development of MPEG-2 designed for transmitting audiovisual data at very low transfer rates (for example over the Internet) Maximum Segment Size; maximum byte figure for the user data in a data packet...
  • Page 118 118 en | Glossary VideoJet X10 SN SNTP Simple Network Time Protocol; a simplified version of NTP (see NTP) Secure Sockets Layer; an encryption protocol for data transmission in IP-based networks Subnet mask See Net mask Transmission Control Protocol Telnet Login protocol with which users can access a remote computer (Host) on the Internet Transport Layer Security;...

  • Page 119: Index

    VideoJet X10 SN Index | de 119 Index Display stamping 40 Dome camera 21 Activating the recording 57 Dual Streaming 13 Activation key 86 DynDNS 78 Alarm 17 Alarm e-mail 70 Alarm input 21 Echo 110 Alarm inputs 73 Electromagnetic compatibility 8...
  • Page 120 120 de | Index VideoJet X10 SN Recording video sequences 94 Reflections of light 63 Main functions 15 Regulations 7 Maintenance 9 Relay 17 Manufacturer logo 41 Relay output 73 Media-replay 95 Relay outputs 22 Milliseconds 41 Remote control 14...
  • Page 121 VideoJet X10 SN Index | de 121 Transmission parameters 110 Transmission protocol 59 Transmission rate 75 Transmission standards 21 Transparent 75 Traps 80 Trick mode 96 Trigger 21 Trigger relay 74 TTL 82 UDP 59 Unicast 81 Unit date 39...
  • Page 122 122 de | Index VideoJet X10 SN DOC | V4.0 | 2009.06 Installations- und Bedienungshandbuch Bosch Security Systems...
  • Page 124 Bosch Sicherheitssysteme GmbH Robert-Koch-Straße 100 85521 Ottobrunn Germany Telefon 089 6290-0 089 6290-1020 www.boschsecurity.com © Bosch Sicherheitssysteme GmbH, 2009...

Table of Contents
